The Menu System contains three primary branches, each with a differing level of access to
secondary menus or functions:
The User Menu accesses basic printer settings and functions;

The Advanced Menu accesses all operational settings, functions, and diagnostics; and,

The Test Menu accesses a menu of test, user-defined, and previous label printing

functions.
(1) Prompts may appear before menu access is granted and before changes are enacted; see
Security for details.

(2) Display contrast is adjustable: press and hold the MENU BUTTON to cycle through the contrast
range (this may take several seconds) then release the button when the desired appearance has
been achieved.
The multi-purpose Menu, Test, and Navigation Buttons allow Menu System entry, negotiation,
and parameter selection functions:
Soft Key Labels

Soft Keys

MENU Button: Enters the Menu System; returns to the previous

menu level. Press and hold to adjust display contrast.
To change printer settings or perform diagnostics, press the

MENU Button then observe the display for available selections.
(When the number of selections present is greater than can be
shown, use the UP or DOWN Buttons to view those additional
items.) Also, Soft Key Labels are dynamic and change to denote
the current associated Soft Key functions.)
UP Button: Accesses the System Window, or ascends through

branches, levels, items, and increments settings in the Menu
System. Press and hold to view printer system information.
DOWN Button: Descends through branches, levels, items, and

decrements settings.
TEST Button: Enters the Test Menu; or, if already in the Menu

System, advances to next level or item, and moves cursor
position. Press and hold to initiate the printhead cleaning routine.
