Datamax I-Class Mark II Operator's Manual page 34

Advanced Entry Calibration (continued)
Step Action
Use the buttons to increment the
Gain Number by one. Record the
J
TOF Value. Repeat this process for
each Gain Number.
Gain Number
00
01
02
...
31
Step Action
In your sample calibration table,
where both the Label Value and
TOF Value are at least 20, subtract
the amounts and record the result
as a Difference Value (see below).
K
Identify the largest Difference
Value and the corresponding Gain
Number. This Gain Number will be
used to resample the media.
Gain Number
00
01
02
...
15
16
17
18
19
...
31
Chapter 3 - Printer Operation
Displayed Message
TRAN SENSOR GAIN
yyy (0 - 31)
01
Sample Calibration Table
Label Value TOF Value
252
250
248
...
09
Displayed Message
TRAN SENSOR GAIN
yyy (0 - 31)
31
Sample Calibration Table
Label Value TOF Value
252
250
248
...
188
184
179
174
170
...
132
Comment
These are TOF Values, where
"yyy" represents the current
sensor reading.
Difference Value
248
245
234
...
14
Comment
In this example, Gain Number 18
is chosen because, where both
values are at least twenty, it has
the highest Difference Value.
Difference Value
248 4
245 5
234 14
... ...
63 125
51 133
38 141
25 149
19 N/A
... ...
14 N/A
