Specifications

Type number
Standard
Active pixels
Rated supply voltage
Min illumination
Imager
Resolution
SNR
Video output
Synchronization
Shutter
Sens Up
Auto black
BLC
White balance
Color saturation
Lens Mount
ALC lens
Power consumption
Dimensions
Weight
Tripod Mount
Operating
temperature
Controls
LAN interface
Video encoding
protocols
Video data rate
NWC-0495-10P
PAL
752x582
24 VAC or 12 VDC or Power-over-Ethernet (IEEE 802.3af)
12-28 VAC (50/60 Hz)
11-36 VDC
< 0.4 lux
< 0. 1 5 lux (in monochrome mode)
Interline CCD
540 TVL (BNC)
> 50 dB
1 Vpp, 75 Ohm
Internal or Line Lock selectable
AES (1/60 (1/50) to 1/100000), Flickerless, Fixed selectable
Adjustable from OFF to 10x
On, Off selectable (maximum level selectable up to 28dB)
BLC On or Off selectable
Automatic 2500 - 9000K (with AWB hold mode and manual
mode)
Adjustable from monochrome (0%) to 133% color
CS compatible, C-mount compatible with supplied adapter ring
Video or DC iris auto detect
< 8 W
59 x 67 x 122 mm (2.28 x 2.6 x 4.8 inch) without lens (HxWxL)
450g (0.99 lbs) without lens
Bottom (isolated) and Top ¼" 20 UNC
0° to 40° C (32° to 104° F)
OSD with softkey operation
1 × Ethernet 10/100 Base-T, automatic adaptation, half/full duplex,
RJ-45
MPEG-4, JPEG
9,600 KBit/s ... 10 MBit/s
Dinion IP
| Installation Manual
NWC-0495-20P
NTSC
768x492
