- Page 1 DINION inteox 7100i IR | FLEXIDOME inteox 7100i NBE‑7604‑AL | NBE‑7604‑AL‑OC | NDE‑7604‑AL | NDE‑7604‑AL‑OC User manual...
-
Page 3: Table Of Contents
DINION inteox 7100i IR | FLEXIDOME inteox 7100i Table of contents | en Table of contents Browser connection System requirements Establishing the connection Password protection in camera System overview Live Playback Configuration Dashboard Operation via the browser Live page Playback page 3.2.1... - Page 4 | Table of contents DINION inteox 7100i IR | FLEXIDOME inteox 7100i 4.6.5 Recording Status 4.6.6 Recording Statistics 4.6.7 Image Posting Alarm 4.7.1 Alarm Connections 4.7.2 Video Content Analysis (VCA) 4.7.3 Audio Alarm 4.7.4 Alarm E-Mail 4.7.5 Alarm Inputs 4.7.6...
-
Page 5: Browser Connection
If you cannot connect, the unit may have reached its maximum number of connections. Depending on the device and network configuration, each unit can have up to 50 web browser connections, or up to 100 connections via Bosch Video Client or BVMS. Password protection in camera The device is password-protected. - Page 6 | Browser connection DINION inteox 7100i IR | FLEXIDOME inteox 7100i When you use Configuration Manager to access your device for the first time, you must set the initial password of the device in Configuration Manager. The Users section (General > Unit Access >...
-
Page 7: System Overview
Dashboard Click this icon to see detailed system information. Links Click this icon to navigate to the Bosch download store. Logout Click this icon to log out of the device. Click this icon to get context-sensitive help for the page you are browsing. -
Page 8: Dashboard
| System overview DINION inteox 7100i IR | FLEXIDOME inteox 7100i Click the Set and Reboot button. The camera reboots and the changed settings are activated. Dashboard The Dashboard page is used to display detailed information about the device. -
Page 9: Operation Via The Browser
DINION inteox 7100i IR | FLEXIDOME inteox 7100i Operation via the browser | en Operation via the browser Live page After the connection is established, the Live page is initially displayed. It shows the live video image on the right of the browser window. Depending on the configuration, various text overlays may be visible on the live video image. - Page 10 | Operation via the browser DINION inteox 7100i IR | FLEXIDOME inteox 7100i Click the recording icon again to stop recording. Start Video Security app To start the Video Security app, click Show latest event Cick the Show latest event icon to watch the last recorded important events.
-
Page 11: Playback Page
DINION inteox 7100i IR | FLEXIDOME inteox 7100i Operation via the browser | en Watermark invalid Indicates that the watermark is not valid. Motion alarm Indicates that a motion alarm has occurred. Storage discovery Indicates that recorded video is being retrieved. -
Page 12: Track List
| Operation via the browser DINION inteox 7100i IR | FLEXIDOME inteox 7100i 3.2.4 Track list The Track list shows all the available recordings. 3.2.5 Controlling playback The time bar below the video image allows quick orientation. The time interval associated with the sequence is displayed in the bar in gray. -
Page 13: Configuration
Certificate. A check mark in this check box indicates that at least one certificate is loaded onto the device. The Trusted certificate is a root certificate for Bosch Security Systems that proves that the device meets the following criteria: –... -
Page 14: Date/Time
DINION inteox 7100i IR | FLEXIDOME inteox 7100i – It has not been tampered with. The Trusted certificate is issued by Escrypt. Escrypt is a Bosch company and Certificate Authority (CA). – Active Directory server (AD FS). A check mark in this check box indicates that the device uses an active directory server. -
Page 15: Web Interface
DINION inteox 7100i IR | FLEXIDOME inteox 7100i Configuration | en Note: It is important that the date/time is correct for recording. An incorrect date/time setting could prevent correct recording. Device time zone Select the time zone in which the system is located. - Page 16 | Configuration DINION inteox 7100i IR | FLEXIDOME inteox 7100i Company logo To replace the company's logo in the top-right part of the window, enter the path to a suitable image in this field. The image file must be stored on a web server.
-
Page 17: Live' Functions
DINION inteox 7100i IR | FLEXIDOME inteox 7100i Configuration | en Select the type of player to be used for live mode viewing. Latency mode Select the required latency mode: – Low delay: Default mode. Provides marginal buffering to display fluent video under normal network conditions. -
Page 18: Connectivity
This field identifies any cloud-based services with which the camera communicates. – If you have registered the device on a cloud-based service such as Bosch Remote Portal, then this field identifies this fact (“Connected”). Note: The button () to connect to the device with that service is active. -
Page 19: Dyndns
DINION inteox 7100i IR | FLEXIDOME inteox 7100i Configuration | en Account name Enter an account name to be shown as the target name. FTP server IP address For an FTP server, enter the IP address. FTP server login Enter your login name for the account server. -
Page 20: User Apps
| Configuration DINION inteox 7100i IR | FLEXIDOME inteox 7100i User Apps 4.4.1 App Management User apps are purchased from the Security & Safety Things app store, available at https:// store.securityandsafetythings.com/shop/. Follow these steps to install or manage a user app: Connect the device to Remote Portal, available at https://remote.boschsecurity.com... - Page 21 DINION inteox 7100i IR | FLEXIDOME inteox 7100i Configuration | en Global configuration Notice! These options can also be configured individually for all stamping settings. Any changes to the global configuration settings will be applied to all stamping settings! –...
-
Page 22: Positioning
| Configuration DINION inteox 7100i IR | FLEXIDOME inteox 7100i Stream security Select from the Video authentication drop-down box a method for verifying the integrity of the video. If you select Watermarking, all images are marked with an icon. The icon indicates if the sequence (live or saved) has been manipulated. - Page 23 DINION inteox 7100i IR | FLEXIDOME inteox 7100i Configuration | en The focal length is determined by the lens. The shorter the focal length, the wider the field of view. The longer the focal length, the narrower the field of view and the higher the magnification.
- Page 24 | Configuration DINION inteox 7100i IR | FLEXIDOME inteox 7100i – Remove a line or angle. To do this, select the line or angle, then click the trash can icon. Note: Blue lines indicate calibration elements added by you.
-
Page 25: Image Settings
DINION inteox 7100i IR | FLEXIDOME inteox 7100i Configuration | en Azimuth [°] The orientation of the camera in a counter-clockwise angle starting with 0° in the east (WGS 84) or on the X-axis (Cartesian). If the camera is directed towards the north (WGS 84) or the Y-axis (Cartesian), the azimuth is 90°. -
Page 26: Encoder Streams
| Configuration DINION inteox 7100i IR | FLEXIDOME inteox 7100i 4.5.5 Encoder Streams When this menu is accessed while the device is recording, the following message appears at the top of the page: “Recording is currently active. At ‘Active profile’ the stream profile used for recording is displayed, and overrules the ‘Non-recording profile’.”... -
Page 27: Encoder Statistics
DINION inteox 7100i IR | FLEXIDOME inteox 7100i Configuration | en 4.5.6 Encoder Statistics This section gives the user information about the bit rate of the device. For each scene, it is possible to determine the best target/max bit rate through the graphic shown. -
Page 28: Audio
| Configuration DINION inteox 7100i IR | FLEXIDOME inteox 7100i 4.5.9 Audio You can set the gain of the audio signals to suit your specific requirements. The live video image is shown in the window to help you check the audio source. Your changes are effective immediately. -
Page 29: Storage Management
DINION inteox 7100i IR | FLEXIDOME inteox 7100i Configuration | en For long-term authoritative images use an appropriately sized iSCSI system. Two recording tracks are available (Recording 1 and Recording 2). The encoder streams and profiles can be selected for each of these tracks for both standard and alarm recordings. -
Page 30: Recording Profiles
| Configuration DINION inteox 7100i IR | FLEXIDOME inteox 7100i In the Storage overview section, double-click a storage medium, an iSCSI LUN or one of the other available drives. – The medium is added as a target in the Managed storage media list. - Page 31 DINION inteox 7100i IR | FLEXIDOME inteox 7100i Configuration | en Settings for selected recordings Recording includes Select what is to be included in the recordings: – Audio: If audio is not enabled, Off is shown. Click on Off and the page is redirected to the Audio section.
-
Page 32: Maximum Retention Time
| Configuration DINION inteox 7100i IR | FLEXIDOME inteox 7100i Configure accounts Sends you to the Accounts page. Copy Settings You can copy the settings from one profile to another with the Copy Settings button. Select the target profile and click OK. -
Page 33: Recording Status
DINION inteox 7100i IR | FLEXIDOME inteox 7100i Configuration | en Activating recording After completing configuration, activate the recording schedule and start scheduled recording. Once activated, the Recording Profiles and the Recording Scheduler are deactivated and the configuration cannot be modified. Stop scheduled recording to modify the configuration. -
Page 34: Alarm
| Configuration DINION inteox 7100i IR | FLEXIDOME inteox 7100i Notice! You must configure an account in order to have functionality for Image Posting. Click on Configure accounts to do so. Click Set to apply the changes. Alarm 4.7.1 Alarm Connections In the event of an alarm, the unit can automatically connect to a pre-defined IP address. -
Page 35: Video Content Analysis (Vca)
DINION inteox 7100i IR | FLEXIDOME inteox 7100i Configuration | en Remote port Select an appropriate browser port depending on the network configuration. The ports for HTTPS connections are only available if SSL encryption is set to On. Video output If a hardware receiver is used, select the analog video output to which the signal should be switched. -
Page 36: Alarm E-Mail
| Configuration DINION inteox 7100i IR | FLEXIDOME inteox 7100i Signal Ranges Exclude particular signal ranges in order to avoid false alarms. For this reason the total signal is divided into 13 tonal ranges (mel scale). Check or uncheck the boxes below the graphic to include or exclude individual ranges. -
Page 37: Alarm Inputs
DINION inteox 7100i IR | FLEXIDOME inteox 7100i Configuration | en Test e-mail Click Send Now to test the e‑mail function. An alarm e-mail is immediately created and sent. Click Set to apply the changes. 4.7.5 Alarm Inputs Active Configure the alarm triggers for the unit. -
Page 38: Network
| Configuration DINION inteox 7100i IR | FLEXIDOME inteox 7100i As an alternative to the alarm settings on the various alarm pages, enter the desired alarm functions in script form here. This will overwrite all settings and entries on the other alarm pages. - Page 39 DINION inteox 7100i IR | FLEXIDOME inteox 7100i Configuration | en Automatic address Displays the automatic address. Prefix length Enter the appropriate prefix length for the set IP address. Gateway address For the device to establish a connection to a remote location in a different subnet, enter the IP address of the gateway here.
-
Page 40: Advanced
| Configuration DINION inteox 7100i IR | FLEXIDOME inteox 7100i Network MSS [Byte] Set the maximum segment size for the IP packet's user data here. This gives the option to adjust the size of the data packets to the network environment and to optimize data transmission. -
Page 41: Multicast
DINION inteox 7100i IR | FLEXIDOME inteox 7100i Configuration | en Click Set to apply the changes. Some changes only take effect after the unit is rebooted. In this case, the Set button changes to Set and Reboot. 4.8.5 Multicast The device can enable multiple receivers to receive the video signal simultaneously. -
Page 42: Ipv4 Filter
| Configuration DINION inteox 7100i IR | FLEXIDOME inteox 7100i Multicast packet TTL A value can be entered to specify how long the multicast data packets are active on the network. If multicast is to be run via a router, the value must be greater than 1. -
Page 43: Licenses
DINION inteox 7100i IR | FLEXIDOME inteox 7100i Configuration | en Configuration Save configuration data for the device to a computer and load saved configuration data from a computer to the device. To load configuration data from the computer to the device: Click Browse.. -
Page 44: Logging
| Configuration DINION inteox 7100i IR | FLEXIDOME inteox 7100i Click Set to apply the changes. 4.9.4 Logging Event Logging Current log level Select the level of event for which to display log entries or to log. Number of displayed entries Select the number of entries to display. -
Page 45: Troubleshooting
Search again for the IP address. Access the camera using the web browser. Set the initial password for the camera. For DINION inteox 7100i IR, the reset button is in a slot in the back of the camera, next to the SD card slot. To access the reset button, remove the cover. -
Page 46: Appendices
– Repair & Exchange – Product Security Bosch Building Technologies Academy Visit the Bosch Building Technologies Academy website and have access to training courses, video tutorials and documents: www.boschsecurity.com/xc/en/support/training/ 2021-08 | V01 | DOC Bosch Security Systems B.V. User manual... - Page 47 DINION inteox 7100i IR | FLEXIDOME inteox 7100i Appendices | Bosch Security Systems B.V. 2021-08 | V01 | DOC User manual...
- Page 48 | Appendices DINION inteox 7100i IR | FLEXIDOME inteox 7100i 2021-08 | V01 | DOC Bosch Security Systems B.V. User manual...
- Page 50 Bosch Security Systems B.V. Torenallee 49 5617 BA Eindhoven Netherlands www.boschsecurity.com © Bosch Security Systems B.V., 2021 202108131455...
