Bosch NWD-495 User Manual

Video | NWD‑495 FlexiDomeDN IP Cameras
NWD‑495 FlexiDomeDN IP Cameras
www.boschsecurity.com
The NWD-495 FlexiDome
1/3-inch CCD Day/Night network camera, designed to
ensure the highest possible image quality at all times.
This ultra-compact and vandal-resistant camera
provides DVD-like quality MPEG-4 video at up to 25
and 30 images per second (for PAL and NTSC
respectively) or H.264 encoding. Network video signals
are sent over IP networks and can be received and
displayed on a PC web browser, viewed and recorded
using the DiBos hybrid recording system, or managed
as part of a VIDOS or BVMS video management
system. Moreover, send the stream to a BOSCH Video
over IP (BVIP) decoder for viewing on a CVBS or VGA
monitor.
The camera combines 15-bit digital video processing
(which enhances sensitivity) and XF-Dynamic (which
extends the dynamic range) to provide a sharper, more
detailed image with outstanding accuracy in color
reproduction. Depending on the available light, the
NWD-495 automatically switches from color to
monochrome, enhancing sensitivity for IR illumination
to provide high-quality images even in challenging low-
light conditions.
FlexiDome IP uses H.264 or MPEG-4 compression,
bandwidth throttling, and multicasting capabilities to
manage bandwidth and storage requirements
IP is a high-performance
DN
High-impact, vandal-resistant enclosure
u
Advanced Day/Night camera with mechanically
u
switching IR filter
15-bit DSP technology with XF-dynamic extended
u
dynamic range
High-performance H.264, MPEG-4, and M-JPEG
u
Direct-to-iSCSI recording
u
efficiently while delivering the best image quality and
resolution. The analog video service output and the on-
screen displays (OSD) simplify focus adjustment and
Network configuration, leading to lower installation
and support costs. Power over Ethernet (PoE) makes
installation easier and more cost-effective because
cameras no longer need AC power

Functions

Day/Night Mode

In Night Mode, the NWD-495 provides enhanced night
viewing by increasing the IR sensitivity. The IR filter
can switch automatically from color to monochrome by
sensing the illumination level or be remotely switched
via a web browser. An internal, through-the-lens IR
detector enhances monochrome mode stability by
preventing the camera from returning to the color
mode when IR illumination is dominant.

XF-Dynamic

The highly accurate 15-bit digital signal is
automatically processed to reveal every detail of the
image in both the highlight and low-light areas of the
scene simultaneously.
