8. GENERAL SPECIFICATIONS
TV System ...... Color – NTSC (PAL optional)
Monochrome – EIA (CCIR optional)
Video Signal Output............ 1 V p-p, 75 Ohm
Operational Range................ -50°C to +50°C
*with optional heater ............. -70°C to +50°C
Humidity Range .............Up to 85% (relative)
Power Supply..................... 12V dc or 24V ac
............................................................... 10W
Dome ......................................Polycarbonate
Base & Retaining Ring .........CNC Aluminum
Anodized
Dimensions .......................4.6" (118mm) dia.
3.25" (83mm) ht.
Weight.....................................1.0 lbs. (454g)
Line Lock ....................................... Available
Subject To Change Without Notice.
