Dinion IP
| Installation Manual
Note
The storage device selected must adhere to the iSCSI specification, be
available on the network and be completely set up. Amongst other things,
it must have an IP address and be divided into logical drives (LUN).

Scan iSCSI IP address

• Enter the IP address of the required iSCSI server here.
• Click the Scan button. The connection to the IP address will be established.
The iSCSI LUN map field contains the corresponding logical drives.

iSCSI LUN map

The LUN map displays the logical drives configured for the iSCSI storage device.
The current user is displayed for each drive.
• Double-click a free drive (LUN). The associated information is called up and
automatically displayed in the fields below the map.
• If the logical drive is password protected, you must first enter the password in
the Target password field and click the Set button.
Note
In cases where the information cannot be read due to the network
topology, you must enter the data manually, so that the NWC-0495 can
access the drive. In this case you should ensure that the entries correspond
exactly with the configuration of the iSCSI device.
• After entering all the settings in the relevant fields, click Set. The NWC-0495
attempts to create a connection to the required drive using this data.
As soon as a connection has been established, the selected drive is used for
recordings.

Target IP address

Enter the IP address of the required iSCSI server here.

Target name

Enter the name of the required drive.
Bosch Security Systems | 2006-05 | V2.0
EN | 51
