Dinion IP
| Installation Manual EN | 39
Time stamping
This field sets the position of the time and date overlay. It can be displayed at the
Top, at the Bottom or at a position of your choice, which you have pre-defined
using HyperTerminal, using the Custom option. Or it can be set to Off if no
overlay of this information is to be shown.
Alarm mode stamping
Choose On if a text message should be overlaid in the event of an alarm. It can
be displayed at a position of your choice using the Custom option. Or it can be
set to Off if no overlay of this information is to be shown.
– Select the desired position from the lists.
– If you have selected the Custom option, additional fields are displayed to
specify the exact position (Position (XY):).
– In the Position (XY): fields enter the values for the desired position.
Displayed alarm message
Enter the message to be displayed for an alarm. It can contain up to
31 characters.
Video watermarking
Choose On if the video images transmitted are to be watermarked. After
activation, all images are marked with a small green rectangle. A red rectangle
indicates that the sequence (live or saved) has been manipulated.

Encoder Settings

For encoding the video signal, you can select two profiles and change the presets
for the profiles.
