Fuser Removal - Lexmark Optra N 4040 Service Manual

4040

Fuser Removal

1. Open the delivery cover unit.
2. Move the 2 fastened levers (1) of the fuser, slightly lift the fuser
(2), and pull it out toward you.
When you replace the fuser, be sure to position the fuser envelope
lever in the same position it was in when you removed the fuser; nor-
mal (1), or envelope (2).
4-47
