Microscan Symbol Quality Output
Static Validation Report
Matchcode
Matchcode Type
Number of Master Symbols
New Master Pin
Enter Master Symbol Data
Request Master Symbol Data
Delete Master Symbol Data
Match Replace
Mismatch Replace
Camera and IP Setup
IP Threshold
Mirrored Image
Window of Interest
Hollow Mode
Number of Symbols in Field of View
Damaged Symbol
Focal Distance
Increment Focus Position
Decrement Focus Position
Focal Distance Table (Read-Only)
IP Mode
Illumination Brightness
Camera
Pixel Sub-Sampling
Configuration Database
Number of Active Indexes
Configuration Database Status
Save Current Settings to Database
Load Current Settings from Database
Request Selected Index Settings
Request All Database Settings
Database Mode
Quadrus MINI Imager User's Manual
<K710,percent cell damage,total read time,capture time,locate
time,decode time,pixels per element,ECC level,matrix size,quiet
zone>
<VAL>
<K223,matchcode type,sequential matching,match start position,match
length,wild card character,sequence on No Read,sequence on
mismatch>
<K224,number of master symbols>
<K225,status>
<K231,master symbol number,master symbol data>
<K231?,>[for all] or <K231?,master symbol number>
<K231,master symbol number,>
<K735,status,match replacement string>
<K736,status,mismatch replacement string>
<K512,threshold mode,fixed threshold value,cycle min,cycle
max,cycle step,adaptive contrast percent>
<K514,mirrored image>
<K516,row pointer,column pointer,row depth,column width>
<K517,hollow mode status>
<K518,number of symbols in field of view>
<K519,damaged symbol status>
<K525,focal distance>
<525+>
<525–>
<K526,number of focal distances,focal distance>
<K527,IP Mode,FLM direction>
<K536,brightness>
<K541,shutter speed,gain>
<K542,sub-sampling>
<K252,number of active database settings,database sort>
<K255,index,shutter speed,gain,focal distance,digital zoom,row
pointer,column pointer,row depth, column width,threshold
mode,fixed threshold value,processing mode, narrow margins,
background color,symbology type>
<K255+,index>
<K255-,index>
<K255?,index>
<K255?>
<K256,switch mode,frame count/time,image process looping,image
dimensions>
Appendices
A-11
