Microscan Quadrus MINI Imager User Manual page 336

Request Master Symbol Data
Definition: Returns master symbol data for any enabled master symbols from 1 to 10.
For example, to request master symbol # 5, enter <K231?,5>. The imager
transmits master symbol # 5 data in brackets in the following format: <5/>.
If no master symbol data is available, the output will be: <5/>.
<K231?,master symbol
Serial Cmd:
Caution: Be sure to add the
Note: This command returns the number of master symbols if no number is
included.
ESP: 1. Click the Utilities button and the Master Database tab.
2. Click the Receive Reader's Database button.
Request All Master Symbol Data
Definition: This command will return master symbol data for all symbols enabled (up to 10).
Serial Cmd: <K231?>
13-12
number>
or you will delete the master symbol.
?
Quadrus MINI Imager User's Manual
