OCR User Template

Length
Length defines the number of hex values in the template string.
Definition:
Important: The template string must include a NULL (00) terminator.
<K462,length,template string>
Serial Cmd:
Default:
11
Options: 0 - 190
Template String
Definition: A Template String defines an arrangement of OCR characters that will be
decoded when they are in the field of view. User templates must be a
NULL-terminated data string made up of various control codes along with
standard ASCII values. The control codes are assigned to ASCII values
less than 32. The default template defines a string of eight alphanumeric
OCR-A or OCR-B characters.
Serial Cmd: <K462,length,template
Default:
0103070707070707070700
Options: A string of Hex values. Each value can range from 00 - FF.
Examples:
DGOPQUVW
<K462,11,0103070707070707070700>
123457
<K462,9,010307070707070700>
<K462,9,010105050505050500>
<K462,5,0101050E0600>
ABDEFGHI
<K462,11,0101070707070707070700>
JKLMIOP
<K462,10,01010707070707070700>(seven OCR-A characters)
QRSUVW
<K462,9,010107070707070700>
12345
<K462,8,0101070707070700>
Quadrus MINI Imager User's Manual
string>
(eight OCR-A or OCR-B characters)
(six alphanumeric OCR-A or OCR-B characters)
(six numeric OCR-A characters)
(six numeric OCR-A characters, repeating)
(eight OCR-A characters)
(six OCR-A characters)
(five OCR-A characters)
Symbologies
6-45
