OCR Configuration by ESP
OCR Test Interface
OCR settings can be tested by clicking on the Test tab, locating the candidate OCR string
in the field of view, and then clicking the Capture and Test button.
The image can be flipped by checking or un-checking the Mirror Image box, and contrast
can be enhanced by clicking the Contrast box.
Data from the OCR string is displayed in the field under Attribute and Value.
6-48
When you move your mouse pointer
over the image display, a Window of
Interest menu will appear in the upper
left corner. The menu allows you to
Reset the Window of Interest, or to
Define the Window of Interest dimensions.
