Camera and IP Setup Serial Commands

IP Threshold
Mirrored Image
Window of Interest
Hollow Mode
Number of Symbols in Field of View <K518,number of symbols in field of view>
Damaged Symbol
Focal Distance
Increment Focus Position
Decrement Focus Position
Focal Distance Table (Read-Only)
IP Mode
Illumination Brightness
Skew Correction
Camera
Pixel Sub-Sampling
Quadrus MINI Imager User's Manual
<K512,threshold mode,fixed threshold value,cycle
min,cycle max,cycle step,adaptive contrast percent>
<K514,mirrored image>
<K516,row pointer,column pointer,row depth,column
width>
<K517,hollow mode status>
<K519,damaged symbol status>
<K525,focal distance>
<K525+>
<K525–>
<K526,number of focal distances,focal distance>
<K527,IP Mode,FLM direction>
<K536,brightness>
<K537,line speed,symbol direction>
<K541,shutter speed,gain>
<K542,sub-sampling>
Camera and IP Setup
10-3
