3
3.4
PLACING THE SENSOR
The Dexcom G4 System is a glucose-monitoring device indicated
for detecting trends and tracking patterns in persons (age 18 and
older) with diabetes.
1. Clean the area first with an alcohol wipe. Make sure the area is clean and
completely dry before you insert the sensor.
2. Using the white tabs on the adhesive backing, remove the adhesive backing
from the sensor pod one half at a time. Hold the sensor by the applicator
barrel and try not to touch the sticky adhesive patch.
3. Place the sensor flat on your selected area, to the left or right of your belly
button. Make sure the sensor is placed in the same direction shown in the
picture below. You should not place the sensor pointing in the up or down
direction.
Remove the adhesive backing
4. Press your finger firmly around the adhesive patch to make sure it is smooth.
5. Hold on to the applicator. Then pull the safety lock straight out away from the
applicator, in the direction the arrows show in the following picture.
38
|
Dexcom G4 Continuous Glucose Monitoring System
Adhere the sensor on the skin
Remove the safety lock
Hide quick links:
Advertisement
Table of Contents
Troubleshooting
Need help?
Do you have a question about the g4 and is the answer not in the manual?
Questions and answers
The mom set a high ceiling of 300. How do I get to an actual number and not a "high" reading
You can adjust the high glucose alert value on the Dexcom G4 by following these steps:
1. Press the button to select “High Alert.”
2. Press the UP or DOWN button to highlight “On/Off” and press the SELECT button to set this option.
3. Press the LEFT button to return to the previous screen.
4. Press the DOWN button to highlight “Level.”
5. Press the SELECT button and then use the UP or DOWN button to adjust the high glucose alert value.
6. The high glucose alert value can be set between 6.7 and 22.2 mmol/L in 0.1 mmol/L increments.
7. Press the SELECT button to confirm the new setting.
This adjustment allows you to set a specific threshold instead of receiving a general "high" reading.
This answer is automatically generated
