2 Product Specifications
2-2 Appearance
2-2-1 Appearance Dimensions (mm)
2-2-2 Feature Locations
2-2
Figure2-1 Dimensions
1
2
9
8
① Printer Cover
② Key Board
③ Operator VFD(10-Digit) or 2Line Character LCD
④ Customer VFD Display (10-Digit)
⑤ IRC I/F Connector
⑥ RS-232 Serial I/F Connector
⑦ Mode Key
⑧ Clerk Key(Option)
⑨ Drawer
Figure2-2 Feature Locations
305
4
3
⑤
6
7
SAM4S ER-5200 Series
