6 Reference Information
6-1 Semiconductor Base Diagram
6-1-4 Other ICs
Figure 6-15 KA393

6-1-5 TR , Diode

TO-220
1
1.Base 2.Collector 3.Emitter
[KSA1010-Y]
SOT-23
3
1
2
1:B ase 2:E mitter 3:C ollector
[KSA1182-Y]
6-8
PIN CONNECTIONS
Switch
1
Collector
Switch
2
Emitter
Timing
3
Capacitor
4
Gnd
Figure 6-16 KA34063
TO-220
1
1.Base 2.Collector 3.Emitter
[KSD288-Y]
SOT-23
3
1
2
1:B ase 2:E mitter 3:C ollector
[MMBT2222A]
Figure 6-18 Transistor & Diode
Driver
8
Collector
7
I Sense
pk
6
V
CC
Comparator
5
Inverting
Input
(T o p V iew)
TO-92
1
1. Emitter 2. Base 3. Collector
[KSA708-Y]
SOT-23
3
1
2
1:A node 2:N.C 3:C athode
[MMBD6050]
5
OUTPUT
M
4
DELAY CAPACOTOR
5
1
3
GND
9
5
3
2 N.C
1
SUPPLY VOLTAGE
Figure 6-17 M51953
TO-92
1
1. Emitter 2. Base 3. Collector
[KSC945-G]
SAM4S ER-5200 Series
