9 Exploded Views and Parts List
9-2 Printer (STM-210)
9-2-2 Parts List(Continued)
No. Parts No.
C-18 JK72-20005A
C-19 JK72-20007A
C-20 JK72-20008A
C-21 JK70-50006A
C-22 JK72-20006A
C-23 6002-000147
C-24 JK68-40002A
C-25 JK70-20004A
C-26 JK96-01233A
C-27 JK70-50007A
C-28 JK59-40001A
C-29 JK96-01231A
C-30 JK70-50009A
C-31 JK97-10004A
C-32 JK39-40554A
JK97-10004B
JK47-10001A
C-33
JK70-50005A
JK70-20006A
C-34 JK70-30002A
C-35 JK70-20005A
C-36 6001-000665
C-37 JK72-20002A
C-38 JK92-01224A
C-39 6002-000175
C-40 JK39-00012A
C-41 JK72-20009A
C-42 6002-000147
C-43 6003-000198
C-44 JK72-20114A
9-10
Description / Specification
PMO-SIDE COVER: POM,BLK
PMO-GEAR REDUCTION 17_39: POM
PMO-GEAR REDUCTION 21_41: POM
SCREW-MACHINE: RH,+,2,M1.7,L2,WHITE
PMO-GEAR REDUCTION 13_43: POM
SCREW TAPPING: PH,+,2,M3,L10,ZPC(YEL)
LABEL(P)-WARNING HOT: ART-PAPER
IPR-MAIN FRAME
ELA-LEVER SENSOR
SCREW-MACHINE: RH,+,2,M1.7,L8,WHITE
MOTOR ASS'Y: STM-210
ELA-P/END SENSOR
SCREW-MACHINE: RH,+,2,M2,L4,WHITE
ASS'Y TPH: STM-210
CBF SIGNAL-PRINTER FFC: 21P,120MM
ASS'Y TPH,HEAT-SINK: STM-210
TPH: ROHM
TPH TAPE: 3M
HEAT-SINK: ZNDC
SPRING-TPH: SWP
IPR-BRACKET-REAR: SECC T1.0
SCREW-MACHINE: PWH,+,2,M3,L4,ZPC(YEL)
PMO-PAPER SUPPLY: ABS+GF 20%
PBA-SUB PRT CONN BOARD: STM-210
SCREW-TAPPING: PWH,+,2,M3,L8,ZPC(YEL)
CBF-HARNESS-KEY OPTION: 200mm
PMO-COVER FRONT: HIPS(HB);NON AUTO CUTTER
SCREW TAPPING: PH,+,2,M3,L10,ZPC(YEL)
SCREW TAPPING: PWH,+,2,M3,L12,ZPC(YEL)
PMO-SEPARATOR;STM-210,ABS+GF20%,BLACK
Q`ty Design-Location
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
2
1
1
1
1
1
1
4
1
Serviceable Remark
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
N
N
N
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
