Mainboard Overview - Bottom (Connectors)

12
20
19
18
17
16
15
14
13
9 9
8
11 10
6
21
23
22
1
1
2
3
7
5
4
Mainboard Overview - Bottom (Connectors) 1 - 11
Introduction
Figure 8
Mainboard Bottom
Connectors
1. USB 3.0 Ports
2. HDMI-In Port
3. HDMI-Out Port
4. RJ-45 Lan Jack
5. USB 3.0 Port
6. DC-In Jack
7. PS/2 Port (keyboard)
8. PS/2 Port (mouse)
9. Serial Ports
10. Power Switch Cable
Connector
11. Speaker Cable
Connector
12. Battery Connector
13. CN1 Connector
14. SATA Connector 1
15. SATAP Connector
16. TP Connector
17. SATAP1 Connector
18. SATA Connector 2
19. Inverter Connector
20. CPU Fan Cable
Connector
21. CCD Cable
Connector
22. MIC Cable Connector
23. LCD Cable
Connector
