EUROCOM LP300 User Manual

Lcd pc
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LP300 and is the answer not in the manual?

Questions and answers

Related Manuals for EUROCOM LP300

Summary of Contents for EUROCOM LP300

  • Page 2 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no re- sponsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 3: Trademarks

    Preface Trademarks This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intel- lectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home or other limited viewing uses only unless otherwise authorized by Mac- rovision Corporation.

  • Page 4: Federal Communications Commission (Fcc) Statement

    Preface Federal Communications Commission (FCC) Statement This equipment has been tested and found to comply with the limits Warning for a Class B digital device, pursuant to Part 15 of the FCC Rules. Use only shielded ca- These limits are designed to provide reasonable protection against bles to connect I/O de- harmful interference in a residential installation.

  • Page 5: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swim- ming pool.
  • Page 6 Preface IMPORTANTES MESURES DE SÉCURITÉ Certaines mesures de sécurité doivent être prises pendant l’utilisa- tion de matérial téléphonique afin de réduire les risques d’incendie, de choc électrique et de blessures. En voici quelquesunes: Ne pas utiliser l’appareil près de l’eau,, p.ex., près d’une baignoire, d’un lavabo, d’un évier de cuisine, d’un bac à...

  • Page 7: Instructions For Care And Operation

    Preface Instructions for Care and Operation The computer is quite rugged, but it can be damaged. To ensure that does not happen, follow these suggestions: 1. Don’t drop it. Make sure it’s on a stable surface. If the compu- ter falls, the case and other components could be damaged. Do not expose it to any shock or vibration.
  • Page 8 Preface 5. Follow the proper working procedures for computer. Shut- down the computer properly, and close all programs (don’t for- get to save your work). Do not turn off any peripheral devices when the computer is on. Do not disassemble the computer by yourself.

  • Page 9: Power Safety

    Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC adapter may be designed for international travel but it still requires a steady, uninterrupted power supply. If you are unsure of your local power specifications, consult your service representative or local power company.

  • Page 10: Servicing

    Preface Servicing Do not attempt to service the computer yourself. Doing so may vio- late your warranty and expose you and the computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer from the power supply. Then refer servicing to quali- fied service personnel under any of the following conditions: •...

  • Page 11: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer, use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer.

  • Page 12: Table Of Contents

    Preface Contents Notice ....................I Trademarks ..................II Federal Communications Commission (FCC) Statement .....III Instructions for Care and Operation ..........VI Power Safety ................VIII Servicing ..................IX Cleaning ..................X Introduction ........... 1-1 Overview ..................1-1 In the Box ..................1-2 The Manual ..................1-3 Advanced Users ................1-3 Beginners and Not-So-Advanced Users ........1-3 Warning Boxes ................1-4...
  • Page 13 Preface Front View ................... 1-8 LCD Panel ................... 1-9 Power Button ................1-9 Set Button .................. 1-10 Scroll Buttons ................1-10 LED Status Indicators ............... 1-10 Device Bay Left & Right ............1-11 Infrared Receiver ............... 1-11 Stereo Speakers ................1-11 Left View ...................
  • Page 14 Preface Video-In Port ................1-19 S/PDIF Out Port .................1-19 RJ-11 Phone Jack ...............1-19 RJ-45 LAN Jack .................1-20 Dual USB Ports .................1-20 Unpowered - IEEE 1394 Port .............1-20 Printer/Parallel Port ..............1-21 External Monitor (CRT) Port .............1-21 S-Video Connector ..............1-21 Vent ....................1-21 Wireless Network Card ..............1-22 Using The Computer ......
  • Page 15 Preface The Hard Disk Drive ..............2-7 The Floppy Disk Drive (FDD) ............ 2-8 Inserting/Removing Floppy Disks ..........2-8 The CD/DVD Device ..............2-9 Loading Compact Discs ............. 2-10 Handling CD’s or DVD’s ............2-11 DVD Regional Codes ..............2-12 Changing DVD Regional Codes ..........
  • Page 16 Preface Install Instructions: ..............2-25 Advanced Controls ........ 3-1 Overview ..................3-1 Advanced Video Controls ............3-2 Adjusting the On Screen Display ..........3-3 External Video Signals ..............3-5 Video Driver Controls ..............3-6 Making Adjustments for the LCD ..........3-7 Display Devices ................3-11 Attaching a Monitor (CRT) ............3-12 Display Options ................3-13 Enabling Other Displays ............3-14 Clone Mode ................3-15...
  • Page 17 Preface Standby Mode vs. Hibernate Mode ........... 3-24 Configuring the Power Button ........... 3-25 Resuming From Power Saving Modes ........3-26 Drivers & Utilities ........4-1 Overview ..................4-1 What To Install ................4-2 Authorized Driver Message ............4-3 Version Conflict Message ............4-3 Install Order .................
  • Page 18 Preface Audio (WinME) .................4-13 Video (WinME) ................4-14 LAN (WinME) ................4-15 Modem (WinME) ...............4-16 Infrared Keyboard (WinME) ............4-17 RF Keyboard & Mouse (WinME) ..........4-17 Wireless LAN (WinME) ............4-18 Windows 2000 Professional ............4-19 Chipset (Win2000) ..............4-19 Audio (Win2000) ...............4-19 Video (Win2000) ................4-20 LAN (Win2000) .................4-20 Modem (Win2000) ..............4-21 Infrared Keyboard (Win2000) ............4-22...
  • Page 19 Preface Infrared Keyboard (WinXP) ............4-27 RF Keyboard & Mouse (WinXP) ..........4-28 Wireless LAN (WinXP) ............4-28 BIOS Utilities .........5-1 Overview ..................5-1 Important BIOS Settings .............. 5-2 The Power-On Self Test (POST) ..........5-3 POST Screen ................5-4 Failing the POST .................
  • Page 20 Preface Upgrading The Computer ....6-1 Overview ..................6-1 When Not to Upgrade ..............6-2 Hard Disk Drive Upgrade ............6-3 Removing the Hard Disk ..............6-3 Installing an Upgrade HDD ............6-4 Some Things to Watch Out For ............6-5 Software ..................6-5 Setting Up a New HDD ..............6-5 Upgrading the System Memory ...........6-6 Replacing the CD-Device ............6-13 Removing the CD Device ............6-14...
  • Page 21 Preface Display ..................7-8 Hard Disk Drive (HDD) ............7-13 Boot Password ................7-13 Floppy Disk Drive (FDD) ............7-14 Audio ..................7-15 CD Device ................. 7-16 PC Card ..................7-19 The PC Card Problem in Windows 98 ........7-20 Keyboard and Mouse ..............

  • Page 22: Introduction

    Introduction Chapter 1: Introduction Overview What this chapter covers: • In the Box — the parts and pieces provided • The Manual — how to use it • Quick Start Guide — the minimum you need to know • System Map —...

  • Page 23: In The Box

    Introduction In the Box The following should be in the box. Figure 1 - 1 Box Contents 1. The LCD PC 2. Keyboard (Vari- able - see “ Keyboard Note” on page 1 - 15) 3. Power Cord 4. Device Driver’s &...

  • Page 24: The Manual

    Introduction The Manual This manual refers to the hardware and essential software required to run your computer. Depending on how your system is configured, Advanced Notes some or all of the features described may already be set up. Advanced users should check the light Advanced Users colored boxes with the...

  • Page 25: Warning Boxes

    Introduction Warning Boxes No matter what your level please pay careful attention to the warning and safety information indicated by the symbol. Also please note the safety and handling instructions as indicated in the Preface. 1 - 4 The Manual...

  • Page 26: Not Included

    Introduction Not Included Operating Systems (e.g. Windows 98 Second Edition, Window Me, Windows 2000 Professional, Windows XP etc.) have their own man- uals as do applications (e.g. word processing, spreadsheet and data- base programs). If you have questions about the operating systems or programs then please consult the appropriate manuals.

  • Page 27: Quick Start Guide

    Introduction Quick Start Guide This guide assumes that you are already familiar with computers and Peripheral Devices can tell at a glance what and where all the key components are. If you are not that comfortable with this type of device, then please refer to Please note that pe- the following pages, which give an overview of the system.

  • Page 28: System Map

    Introduction System Map Your LCD PC has a lot of built-in features. Most of these are enabled by your operating system. Further explanations of the various sub- systems are covered in the chapter or pages indicated. Getting To Know Your Computer The following graphics will help you to become familiar with the ba- sic functions, and to learn the location of the various ports and com- ponents of your computer.

  • Page 29: Front View

    Introduction Front View Figure 1 - 2 Front View 1. LCD Panel 2. Power Button 3. Set Button 4. Scroll Buttons 5. LED Status Indi- cators 6. Device Bay Left (for CD/CD-RW/ DVD device/RF module or Dummy Bay) 7. Device Bay Right (for CD/ CD-RW/DVD/ Combo drive)

  • Page 30: Lcd Panel

    Introduction LCD Panel The LCD PC comes with a 17” or 18.1” LCD (Liquid Crystal Dis- play) screen depending upon the configuration purchased. Power Button Press this button to turn your computer on or off (see “ Turning On The Computer” on page 2 - 4). This button may also be used as a suspend/resume key, once configured as such, in the power manage- ment control panel of your operating system (see “Configuring the Power Button”...

  • Page 31: Set Button

    Introduction Set Button This switch allows you to adjust the screen options, including the in- put signal (see “ Advanced Video Controls” on page 3 - 2). Scroll Buttons After enabling the menus with the set button, these buttons may be used to move through the different menu options (see “...

  • Page 32: Device Bay Left & Right

    Introduction Device Bay Left & Right There are two bays for a combination of 5.25” CD-ROM drive/CD- RW/DVD (12.7mm height) drive depending on the model you pur- chased. Alternatively you may have an RF module or a Dummy in CD Emergency Eject the left bay, or a combo drive in the right bay.

  • Page 33: Left View

    Introduction Left View Figure 1 - 3 Left View 1. Floppy Disk Drive Warning Drive 2. Hard Disk Drive Don’t try to remove the (HDD) Bay hard disk (HDD) while the system is on. This could cause data loss or damage. Unauthorized removal or tampering with the HDD may violate your...

  • Page 34: Fdd (Floppy Disk Drive)

    Introduction 3.5” FDD (Floppy Disk Drive) This is a 3.5”, 3-mode, 1.44 MB fixed floppy disk drive. For more information refer to “The Floppy Disk Drive (FDD)” on page 2 - 8. Hard Disk Drive See “Hard Disk Drive Upgrade” on page 6 - 3 for information on upgrading/replacing your hard disk drive.

  • Page 35: Right View

    Introduction Right View Figure 1 - 4 Right View 1. AC Power-In 2. Dual USB Ports 3. Kensington Lock Slot Sound Volume Ad- justment 4. Headphone-Out Jack How high the sound 5. Line-In Jack volume can be set us- 6. Microphone-In ing the volume control Jack knob depends on the...

  • Page 36: Ac Power-In

    Introduction AC Power-In To power your computer plug the supplied cable in here, then con- nect to the other end to an AC power source. Dual USB Ports These ports are hardware interfaces for low-speed peripherals such as a keyboard, mouse, joystick, scanner, printer or telephony devic- es.

  • Page 37: Security Lock

    Introduction Security Lock To prevent possible theft a Kensington-type lock can be attached to this slot. Locks can be purchased at any computer store. Headphone-Out Jack Headphones or speakers may be connected through this jack. Note: Set your system’s volume to a reduced level before connecting to this jack.

  • Page 38: Dual Pc Card Slots

    Introduction Dual PC Card Slots There are two Type-II PC card slots, or the slot may be used for one Type III PC card (PC cards were also previously referred to as PC- MCIA). Refer to “The PC Card Slot” on page 2 - 14 for more in- formation.

  • Page 39: Rear View

    Introduction Rear View Figure 1 - 5 Rear View 1. Video-In Port 2. S/PDIF Out Port 3. RJ-11 Phone Jack 4. RJ-45 LAN Jack 5. Dual USB Ports 6. Unpowered - IEEE 1394 Port 7. Printer/Parallel Port 8. External Moni- tor (CRT) Port 9.

  • Page 40: Video-In Port

    Introduction Video-In Port Plug in external video sources to this port. Examples of sources in- clude VCR’s, VCD players, TV’s, external DVD’s, video cameras etc. The cable from the source device should be plugged into the de- vice’s video out port. A standard audio/video cable is available from any electrical store.

  • Page 41: Rj-45 Lan Jack

    Introduction RJ-45 LAN Jack This port supports LAN (Network) functions. Note: Broadband (e.g. ADSL) modems usually connect to the LAN port. Dual USB Ports These ports are hardware interfaces for low-speed peripherals such as keyboard, mouse, joystick, scanner, printer and telephony devic- es.

  • Page 42: Printer/Parallel Port

    Introduction Printer/Parallel Port This port supports ECP (Extended Capabilities Port) and EPP (En- hanced Parallel Port) 1.7/1.9 modes. External Monitor (CRT) Port Connect an external CRT monitor to this port to allow dual video or simultaneous display on the LCD and external CRT monitor (see “ Display Devices”...

  • Page 43: Wireless Network Card

    Introduction Wireless Network Card Your computer may have an optional 802.11b Wireless Networking solution. If included, the antennae and other components are not ex- ternally visible (please check with your service representative). Should you need to install a driver for this card then please refer to “Drivers &...

  • Page 44: Using The Computer

    Using The Computer Chapter 2: Using The Computer Overview To learn more about your computer, please read this chapter. This chapter includes: • Ergonomics • Turning on the Computer • Switches and Indicators • The Hard Disk Drive • The Floppy Disk Drive •...

  • Page 45: Ergonomics

    Using The Computer Ergonomics We designed your LCD PC system to be functional as well as attrac- tive. To get most out of it, here are some suggestions on how to po- sition and use the computer: • Angle the LCD so that it doesn’t reflect any light into your eyes.
  • Page 46 Using The Computer • Place the keyboard and mouse so that your arms are at your sides and your forearms are roughly parallel to the floor. Your wrists should flex slightly downward as you work. Your neck and shoulders should also be relaxed.

  • Page 47: Turning On The Computer

    Using The Computer Turning On The Computer Now you are ready to begin using your new computer. To turn it on simply press the power button on the front panel. Power Button as Standby or Hibernate Button When the computer is turned on, the power button can also be used as a Standby/Hibernate/Shutdown hot-key button if pressed for If you are using an less than 4 seconds, and is appropriately configured in the OS Con-...

  • Page 48: Switches And Indicators

    Using The Computer Switches and Indicators Setting Switches Shutdown There are three set switches at the front of the computer. These are used to set the video/display options in the OSD (On Screen Display) Please note that you on your LCD PC (see “Adjusting the On Screen Display” on should always shut...
  • Page 49 Using The Computer Table 2 - 1 LED Status Indicators Icon Color Description Flashing Green Floppy/Hard disk activity. Communication is established Green between LCD PC and an infrared keyboard (optional). Scroll Lock is enabled (press the Scroll Lock key on your key- Green board).

  • Page 50: The Hard Disk Drive

    Using The Computer The Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk is accessible from the left of your computer as seen be- low “1”. Further details on removing and inserting the hard disk are available in “Hard Disk Drive Upgrade”...

  • Page 51: The Floppy Disk Drive (Fdd)

    Using The Computer The Floppy Disk Drive (FDD) The computer is equipped with a fixed 1.44 MB, 3.5” floppy disk Media Warning drive module. By default it is drive “A:” and can be used as a boot device if properly set in the BIOS (refer to “Boot Menu” on page 5 Don’t try to remove a - 19).

  • Page 52: The Cd/Dvd Device

    Using The Computer The CD/DVD Device There are two bays for a combination of 5.25” CD-ROM/CD-RW/ Sound Volume DVD/Combo (12.7mm height) drive depending on the model you Adjustment purchased (you may alternatively have an RF module or dummy in one of the bays). The CD Device is usually labeled drive “D:” and How high the sound volume can be set us- may be used as a boot device if properly set in the BIOS (“Boot...

  • Page 53: Loading Compact Discs

    Using The Computer Loading Compact Discs To insert a CD/DVD disc, press the open button and carefully place a CD/DVD disc onto the disc tray with label-side facing up (use just enough force for the disc to click onto the tray’s spindle). Gently push the CD/DVD tray in until its lock “clicks”...

  • Page 54: Handling Cd's Or Dvd's

    Using The Computer Handling CD’s or DVD’s Proper handling of your CD’s/DVD’s will prevent them from being damaged. Please follow the advice below to make sure that the data Media Warning stored on your CD-ROM / DVD-ROM discs can be accessed. When manually eject- ing a CD/DVD disc, Remember to:...

  • Page 55: Dvd Regional Codes

    Using The Computer DVD Regional Codes DVD region detection is device dependent, not OS-dependent. You can select your module’s region code 5 times. The fifth selection is permanent. This cannot be altered even if you change your operating system or you use the module in another computer. Figure 2 - 3 DVD Regional Codes (Windows XP)

  • Page 56: Changing Dvd Regional Codes

    Using The Computer Changing DVD Regional Codes Go to the Control Panel in Windows and double-click System, click Changing Region Device Manager, then click the + next to DVD/CD-ROM drives. Codes in Windows Double-click on the DVD-ROM device to bring up the Properties 98/Me menu, and select the DVD Region (tab) to bring up the control panel as seen in “DVD Regional Codes (Windows XP)”...

  • Page 57: The Pc Card Slot

    Using The Computer The PC Card Slot The computer is equipped with two PC Card slots. These are PCM- CIA 3.3V/5V/12V sockets, type II x2. The system also supports type III x1.Type III PC Cards only fit into the rear socket. Inserting And Removing PC Cards •...

  • Page 58: Keyboard (Variable)

    Using The Computer Keyboard (Variable) The keyboard supplied with your system is variable. Your keyboard Special Characters interface may be infrared, RF or USB depending upon the configu- ration purchased. The following will cover some standard model Some software appli- keyboards supplied, and general keyboard conventions.

  • Page 59: Infrared Keyboard

    Using The Computer Infrared Keyboard The following information relates to the infrared keyboard pictured below ONLY. Figure 2 - 4 The infrared keyboard communicates with the LCD PC’s infrared re- Infrared Keyboard ceiver (“Front View” on page 1 - 8) by means of “Line of Sight”. If this is blocked by any object then the keyboard will not work.
  • Page 60 Using The Computer After you have installed the keyboard driver the following icon will appear on your desktop, and the keyboard program will be available from the Start menu in Windows. Figure 2 - 5 Keyboard Program The keyboard control panel allows you to setup the hot-keys etc. Figure 2 - 6 Keyboard Control Panel...

  • Page 61: Ir Keyboard Hot-Keys

    Using The Computer IR Keyboard Hot-Keys Table 2 - 3 IR Keyboard Hot-Key Functions Hot-Key Function Application keys. Activate a preset application. Browser key. Activate the default Internet browser. E-Mail key. Activate the default e-mail pro- gram. Audio Control Keys. Reduce, mute and increase (as read from left to right).

  • Page 62: Rf Keyboard & Mouse

    Using The Computer RF Keyboard & Mouse The following information relates to the RF Keyboard and Mouse pictured below ONLY. The infrared Keyboard communicates with the LCD PC through the Figure 2 - 7 RF module installed in Device Bay Left (“Front View” on page 1 - RF Keyboard &...

  • Page 63: Rf Keyboard & Mouse Start Menu Programs

    Using The Computer RF Keyboard & Mouse Start Menu Programs After you have installed the keyboard driver, Mouseware and User’s Guide the Program Groups circled in Figure 2 - 8 will appear in your Start menu in Windows: Figure 2 - 8 Start Menu Programs The control panels allow you to setup the hot-keys for e-mail, inter- net searches, home pages and programs etc.
  • Page 64 Using The Computer Synchronizing the RF Keyboard & Mouse Communication Make sure you have installed the batteries correctly for your key- board and mouse. You can check the battery level from the control panels in the Start menu (see “RF Keyboard & Mouse Start Menu Programs”...

  • Page 65: Other Keyboards

    Using The Computer Other Keyboards If your supplied keyboard has extra features (e.g. Hot-Keys, naviga- tional buttons etc.) then you will need to install a driver to enable these features. Please see any extra documentation related to your keyboard for instructions on this. 2 - 22 Other Keyboards...

  • Page 66: Mouse

    Using The Computer Mouse You can also add a mouse to your computer. You can use a mouse Mouse Driver through one of the USB ports (two on the right and two at the rear of the computer). If you are using an ex- ternal mouse your op- erating system may be able to auto-configure...

  • Page 67: Adding A Printer

    Using The Computer Adding a Printer The most commonly used peripheral is a printer. The following will Parallel to USB help you to add a printer, however it is always best to refer to the Converter Note printer manual for specific instructions and configuration options. If you are using a Par- allel to USB converter, USB Printer...

  • Page 68: Parallel Printer

    Using The Computer Parallel Printer This is still the most common type of printer. Which Parallel? Install Instructions: The computer features 1. Set up the printer according to its instructions (unpacking, a “Plug & Play” BIOS, paper tray, toner/ink cartridge etc.) so Windows 98 SE , 2.
  • Page 69 Using The Computer 2 - 26...

  • Page 70: Advanced Controls

    Advanced Controls Chapter 3: Advanced Controls Overview This chapter covers: Drivers • Advanced video controls You are unable to use • Power management features most advanced con- trols until the neces- sary drivers utilities are properly in- stalled. If your system hasn’t been properly configured (your serv- ice representative may...

  • Page 71: Advanced Video Controls

    Advanced Controls Advanced Video Controls This section is about making adjustments for the LCD, the display options enabled by the video driver and display device options. Make sure you have installed the video driver or all the options listed on the following pages will not be available to you (see “ What To Install”...

  • Page 72: Adjusting The On Screen Display

    Advanced Controls Adjusting the On Screen Display Adjust the LCD so you can look at the screen straight on, without any glare. If necessary, you can adjust the brightness controls, the verti- cal and horizontal position etc. from the OSD (On Screen Display). These settings are adjusted by means of the Set button, and scroll buttons (Figure 3 - 1) at the front of the computer.
  • Page 73 Advanced Controls Figure 3 - 2 OSD - Panel Adjust PANEL ADJUST EXIT BRIGHTNESS CONTRAST-Z SCALING COLOR TEMP COLOR R COLOR G COLOR B EXIT   : ENTRY : UP : DOWN Once the options are enabled you may use the scroll buttons to move through items, Set to select the option, then scroll to adjust the set- ting.

  • Page 74: External Video Signals

    Advanced Controls External Video Signals If you want to view external video sources (TV tuners, camcorders, video recorders etc.) on the computer then you must first set the input signal to video. 1. Go to the On Screen Display (“OSD - Panel Adjust” on page 3 - 4) and select Input Select Option.

  • Page 75: Video Driver Controls

    Advanced Controls Video Driver Controls The video interface lets you change the screen resolution and color output to whatever is most comfortable/efficient for you. This is a matter of hardware, video memory and the driver for your operating system. The driver interface shows the available options. You can switch display devices from the Display Properties control panel in Windows as long as the video driver is installed (“What To Install”...

  • Page 76: Making Adjustments For The Lcd

    Advanced Controls Making Adjustments for the LCD With the video driver installed, the SXGA LCD is capable of sup- porting a resolution of 1280X1024 at 60Hz. The higher the resolu- Refresh Rates tion, the more information the LCD can display on screen. To change The standard refresh the LCD’s resolution and color depth go to the Display Properties rate for all LCD panels...
  • Page 77 Advanced Controls Figure 3 - 4 You can also access Display Properties by right-clicking the ATI ATI Display Settings icon in the taskbar. Point to Settings and click Display Settings, then click the ettings (tab). Note: The ATI icon will only appear in the taskbar if you have in- stalled the video driver (see “...
  • Page 78 Advanced Controls Figure 3 - 5 Advanced Display Properties Windows XP Windows 2000 When the Display Properties control panel is open click the Ad- vanced (button) to bring up the options tabs. Clicking through these tabs allows you to make any video adjustments you require. Video Driver Controls 3 - 9...
  • Page 79 Advanced Controls Access the menus from ATI icon in the taskbar to get further help on display options, TV options etc. Right-click the ATI icon in the task- bar and point to Help or Troubleshooting (Figure 3 - 6). Figure 3 - 6 ATI Help &...

  • Page 80: Display Devices

    Advanced Controls Display Devices Besides the built-in LCD, you can also use an external CRT connect- Drivers ed to the VGA port as your display device. You may also connect a TV. The following are the display options: You are unable to use most advanced con- 1.

  • Page 81: Attaching A Monitor (Crt)

    Advanced Controls Attaching a Monitor (CRT) If you prefer to use a monitor (CRT), connect it to the External Mon- itor (CRT) port on the rear panel (see “Figure 1 - 5 Rear View” on Vertical Refresh Rate page 1 - 18). The vertical refresh rate of your CRT is impor- tant.

  • Page 82: Display Options

    Advanced Controls Display Options Windows 98SE, Me & Display Mode Windows 2000 Single Multiple - Clone Mode Multiple - Extended Not Available Desktop Mode Single - Either the LCD, CRT or TV as a display device Multiple (Clone) - The LCD, CRT or TV outputting the same view (you can apply different display modes with different resolutions and refresh rates) Multiple (Extended Desktop)- In Windows 98SE, Windows Me and Windows XP only...

  • Page 83: Enabling Other Displays

    Advanced Controls Enabling Other Displays In the Advanced ATI Mobility Radeon Properties (Figure 3 - 5 on page 3-9) click on Display to get the other display options, including those for TV (different OS’s will appear with different options). Click the enable/disable button for the display device you wish to use.

  • Page 84: Clone Mode

    Advanced Controls Clone Mode Clone Mode simply shows an exact copy of the Primary display desktop on the other display(s). This mode will drive multiple dis- plays with the same content. Use this feature to display the screen through a projector for a presentation. Each display device can be configured independently as this allows you to set the options for overhead projectors etc., which require specific resolutions and re- fresh rates.

  • Page 85: Extended Desktop Mode

    Advanced Controls Extended Desktop Mode The system supports Extended Desktop (The LCD and a CRT showing different views) in multiple display environments in Win- dows 98SE, WindowsMe and WindowsXP, but this mode is NOT supported in Win2000. An Extended Desktop creates a desktop spanning multiple displays and acts as a large workspace.
  • Page 86 Advanced Controls 10. In the example shown in Figure 3 - 9 the primary monitor “1” is on the right, the other display is on the left (windows should be dragged to the left). Figure 3 - 9 Extended Desktop Monitor Arrangement 11.

  • Page 87: Enabling Tv Display

    Advanced Controls Enabling TV Display To display desktop images on a TV display, connect the TV to your TV Format LCD PC by using an S-Video cable from the TV to the connector at the rear of the computer (see “Rear View” on page 1 - 18). You will If you need to change need to enable the TV display from the control panel in (see “Figure format...

  • Page 88: Tv Tuner

    Advanced Controls TV Tuner With the optional (see sidebar) TV Tuner you may watch TV, TV Tuner Option CATV or video on your LCD PC independently of normal computer functions e.g. if your computer’s cpu has failed, as long as you can If you require the TV switch to the video input signal (see “...
  • Page 89 Advanced Controls Connect the TV tuner as per the instructions in the TV tuner manual. The example in Figure 3 - 11 shows the video-out (1) and audio-out (2) from the TV tuner connect to video-in (3) and line-in (4) on the computer.

  • Page 90: Power Management Features

    Advanced Controls Power Management Features The system supports various ACPI-compliant (Advanced Configura- Operating System tion and Power Interface) power management features. You can use Power Management them to reduce the power consumption. Windows 98 Second Edition, Windows Me and Windows 2000 Pro- Power management functions...

  • Page 91: Enabling Power Management/Options

    Advanced Controls Enabling Power Management/Options The power management/options are enabled through the Control Panel in your Windows system (Power Management in Windows 98SE, and Power Options in the Windows ME, 2000 and XP). With other operating systems you may have power management available so check your documentation.

  • Page 92: Conserving Power Through Individual Components

    Advanced Controls Conserving Power Through Individual Components Monitor Standby To conserve power, you can set the monitor to turn off after a speci- fied time. Hard Disk Standby The computer's hard disk motor will be turned off if the hard disk drive has not been accessed for a specified period of time.

  • Page 93: Conserving Power Throughout The Whole System

    Advanced Controls Conserving Power Throughout the Whole System With this function you can stop the computer’s operation and restart where you left off. This system features Standby and Hibernate Hibernate Mode in suspend mode levels (Hibernate mode will need to be enabled by Windows 98SE clicking the option in the Hibernate tab in the control panel): Hibernate mode is un-...

  • Page 94: Configuring The Power Button

    Advanced Controls Configuring the Power Button The Power button may be set to send the computer in to either Stand- by or Hibernate modes (Figure 3 - 14). In Standby mode the LED will flash green, in Hibernate mode the LED will be off. If you are in a power saving mode set to save power through individual com- ponents (e.g.

  • Page 95: Resuming From Power Saving Modes

    Advanced Controls Resuming From Power Saving Modes The system can resume from power saving through individual com- ponents such as the hard disk or monitor by either pressing a key on the keyboard, or by moving the mouse. While in these modes the power button will remain green.

  • Page 96: Drivers & Utilities

    Drivers & Utilities Chapter 4: Drivers & Utilities Overview • Windows 98 Second Edition • Windows Me • Windows 2000 Professional • Windows XP This chapter deals with installing the drivers and utilities essential to the operation or im- provement of some of the LCD PC’s sub- systems.

  • Page 97: What To Install

    Drivers & Utilities What To Install The Device Drivers & Utilities + User’s Man- ual CD-ROM contains the drivers and utilities Navigate (Browse.\.) to D: necessary for the proper operation of the LCD You will notice that many of the instructions for PC.

  • Page 98: Authorized Driver Message

    Drivers & Utilities Authorized Driver Message Important Note: Please install Microsoft Di- rectX 8.0 from the Device Drivers & Utilities If you receive a message telling you that the + User’s Manual CD-ROM before installing driver you are installing is not authorized the video drivers in Win98SE and WinME.

  • Page 99: Install Order

    Drivers & Utilities Install Order Table 4 - 1 What to Install Feature Win98SE WinME Win 2000 Win XP Chipset page 4 - 5 page 4 - 13 page 4 - 19 page 4 - 24 Audio page 4 - 6 page 4 - 13 page 4 - 19 page 4 - 24...

  • Page 100: Windows 98 Second Edition

    Drivers & Utilities Windows 98 Second Edition This section covers driver and utility installa- tion instructions for Windows 98 Second Edi- tion. What To Have Ready Chipset (Win98SE) In some cases when drivers are to be installed 1. Click Start (menu) > Run... you will need to have present your OS CD - 2.

  • Page 101: Audio (Win98Se)

    Drivers & Utilities Audio (Win98SE) the Sounds icon) and select one of the sounds marked with a speaker to preview. 1. Click Start (menu) > Run... You will see the Sound Effect Manager 2. Navigate (Browse..) to D:\DRIV- appear in the Task Bar alongside the ERS\AUDIO\Setup.exe and click OK.

  • Page 102: Video (Win98Se)

    Drivers & Utilities Video (Win98SE) driver for your device. (Recom- mended).”, then click Next again. Important Note: Please install Microsoft Di- 10. Select ONLY “Specify a location”, and rectX 8.0 from the Device Drivers & Utilities navigate (Browse...) to D:\DRIV- + User’s Manual CD-ROM before installing ERS\VIDEO\WIN9X\ATIDRIVE and the video drivers.

  • Page 103: Lan (Win98Se)

    Drivers & Utilities LAN (Win98SE) 7. Give the computer a few seconds to rec- ognize that the disk is in the drive, then 1. Click Start (menu), point to Settings and click OK. click Control Panel. Double-click Sys- 8. Click Finish > Yes to restart your com- tem (icon) and then click Device Man- puter when prompted.

  • Page 104: Modem (Win98Se)

    Drivers & Utilities Modem (Win98SE) 1. Click Start (menu), point to Settings and click Control Panel. Double-click Sys- tem (icon) and then click Device Man- Modem Country Selection ager (tab). Be sure to check if the modem country selection 2. Click “+” next to Other devices (if its is appropriate for you.

  • Page 105: Pcmcia (Win98Se)

    Drivers & Utilities PCMCIA (Win98SE) 7. When you are prompted ‘please insert the disk labeled “Windows 98 Second 1. Click Start (menu), point to Settings and Edition CD-ROM” and then click OK’ click Control Panel. Double-click Sys- eject the CD-ROM in your drive and tem (icon) and then click Device Man- insert the Windows CD.

  • Page 106: Infrared Keyboard (Win98Se)

    Drivers & Utilities Infrared Keyboard (Win98SE) RF Keyboard & Mouse (Win98SE) 1. Click Start (menu) > Run... 1. Click Start (menu) > Run... 2. Navigate (Browse..) to D:\Drivers\Key- 2. Navigate (Browse..) to board\Disk1\\Setup.exe and click OK. D:\DRIVERS\RF 3. Choose the language you wish to set your KEYBOARD_MOUSE\Setup.exe and keyboard for, then click OK.

  • Page 107: Wireless Lan (Win98Se)

    Drivers & Utilities Wireless LAN (Win98SE) 1. Click Start (menu) > Run... 2. Navigate (Browse..) to D:\DRIV- ERS\WLAN\GW-LANSETUP.EXE and click OK. 3. Click Next > Yes. 4. When the installation is finished, click Finish to restart your computer. 5. After the computer changes the system settings (allow some time for the com- puter to do this) click Yes to restart the computer again.

  • Page 108: Windows Me

    Drivers & Utilities Windows ME Audio (WinME) 1. Click Start (menu) > Run... This section covers driver and utility installa- 2. Navigate (Browse..) to D:\DRIV- ERS\AUDIO\SETUP.EXE and click tion instructions for Windows Me. 3. When the Setup window appears click Chipset (WinME) Next.

  • Page 109: Video (Winme)

    Drivers & Utilities Video (WinME) 9. Make sure that you have selected “Search for the best driver for your Important Note: Please install Microsoft Di- device. (Recommended).” rectX 8.0 from the Device Drivers & Utilities 10. Select ONLY (make sure the other boxes + User’s Manual CD-ROM before installing do not have a tick inside them) “Specify the video drivers.

  • Page 110: Lan (Winme)

    Drivers & Utilities LAN (WinME) 9. Click Finish and Yes to restart your com- puter when prompted. 1. Click Start (menu), point to Settings and 10. The network adapter is now ready for click Control Panel. Double-click Sys- configuration. tem (icon) and then click Device Man- ager (tab).

  • Page 111: Modem (Winme)

    Drivers & Utilities Modem (WinME) 9. Select “Specify the location of the driver (Advanced)” then click Next. 1. Click Start (menu), point to Settings and 10. Make sure that you have selected click Control Panel. Double-click Sys- “Search for the best driver for your tem (icon) and then click Device Man- device.

  • Page 112: Infrared Keyboard (Winme)

    Drivers & Utilities Infrared Keyboard (WinME) RF Keyboard & Mouse (WinME) 1. Click Start (menu) > Run... 1. Click Start (menu) > Run... 2. Navigate (Browse..) to 2. Navigate (Browse..) to D:\DRIVERS\KEYBOARD\DISK1\\S D:\DRIVERS\RF ETUP.EXE. KEYBOARD_MOUSE\SETUP.EXE 3. Choose the language you wish to set your and click OK.

  • Page 113: Wireless Lan (Winme)

    Drivers & Utilities Wireless LAN (WinME) 1. Click Start (menu) > Run... 2. Navigate (Browse..) to D:\DRIV- ERS\WLAN\GW-LANSETUP.EXE and click OK. 3. Click Next > Yes. 4. When the installation is finished, click Finish to restart your computer. 5. After the computer changes the system settings (allow some time for the com- puter to do this) click Yes to restart the computer again.

  • Page 114: Windows 2000 Professional

    Drivers & Utilities Windows 2000 Professional This section covers driver and utility installa- Audio (Win2000) tion instructions for Windows 2000 Profes- 1. Click Start (menu) > Run... sional. 2. Navigate (Browse..) to D:\DRIV- ERS\AUDIO\SETUP.EXE and click Chipset (Win2000) 3. When the Setup window appears press 1.

  • Page 115: Video (Win2000)

    Drivers & Utilities Video (Win2000) LAN (Win2000) Important Note: Though not a requirement, 1. Click Start (menu), point to Settings and it is recommended that you install Microsoft click Control Panel. Double-click Sys- DirectX 8.0 from the Device Drivers & Utili- tem (icon) and then click Hardware ties + User’s Manual CD-ROM before in- (tab) >...

  • Page 116: Modem (Win2000)

    Drivers & Utilities 9. Click Open (button) and click OK (but- 6. When Locate Driver Files appears, select ton), then click Next. ONLY “Specify a location” and click 10. Click Finish and close the open win- Next. dows. 7. Navigate (Browse...) to D:\DRIV- 11.

  • Page 117: Infrared Keyboard (Win2000)

    Drivers & Utilities Infrared Keyboard (Win2000) RF Keyboard & Mouse (Win2000) 1. Click Start (menu) > Run... 1. Click Start (menu) > Run... 2. Navigate (Browse..) to 2. Navigate (Browse..) to D:\DRIVERS\KEYBOARD\DISK1\\S D:\DRIVERS\RF ETUP.EXE and click OK. KEYBOARD_MOUSE\SETUP.EXE 3. Choose the language you require, then and click OK.

  • Page 118: Wireless Lan (Win2000)

    Drivers & Utilities Wireless LAN (Win2000) 1. Click Start (menu) > Run... 2. Navigate (Browse..) to D:\Driv- ers\WLAN\GW-LANSETUP.EXE and click OK. 3. Click Next > Yes. 4. When the installation is finished, click Finish to restart your computer. Windows 2000 Professional 4 - 23...

  • Page 119: Windows Xp

    Drivers & Utilities Windows XP Audio (Win XP) 1. Click Start (menu) > Run... This section covers driver and utility installa- 2. Navigate (Browse..) to D:\DRIV- ERS\AUDIO\SETUP.EXE and click tion instructions for Windows XP. 3. When the Setup window appears click Chipset (WinXP) Next (click Continue Anyway if asked if 1.

  • Page 120: Video (Winxp)

    Drivers & Utilities Video (WinXP) LAN (Win XP) Do NOT install the Microsoft DirectX 8.0 1. If you can see the My Computer icon on from the Device Drivers & Utilities + User’s your desktop (if you cannot see the My Manual CD-ROM as it is not required by Computer icon go to step 2)click on it Windows XP.

  • Page 121: Modem (Winxp)

    Drivers & Utilities 7. When the Hardware Update Wizard 2. If you cannot see the My Computer icon appears, click “Install from a specific the click Start (menu), then point to (but location (Advanced)”, then click Next. don’t click just highlight it) My Com- 8.

  • Page 122: Infrared Keyboard (Winxp)

    Drivers & Utilities Infrared Keyboard (WinXP) 9. Click Finish and close the open win- dows. 1. Click Start (menu) > Run... 10. Your modem is now ready for dial-up 2. Navigate (Browse..) to configuration. D:\DRIVERS\IRKEYBOARD\DISK1\ \SETUP.EXE and click OK. 3. Choose the language you require, then click OK.

  • Page 123: Rf Keyboard & Mouse (Winxp)

    Drivers & Utilities RF Keyboard & Mouse (WinXP) Wireless LAN (WinXP) 1. Click Start (menu) > Run... 1. Click Start (menu) > Run... 2. Navigate (Browse..) to 2. Navigate (Browse..) to D:\Driv- D:\DRIVERS\RF ers\WLAN\GW-LANSETUP.EXE and KEYBOARD_MOUSE\SETUP.EXE click OK. and click OK. 3.

  • Page 124: Bios Utilities

    BIOS Utilities Chapter 5: BIOS Utilities BIOS Settings Overview Warning This chapter gives a brief introduction to the computer’s built-in Incorrect settings can software: cause your system to malfunction. To correct mistakes, return Diagnostics: the POST (Power-On Self Test) Setup and restore the Setup Defaults with <F9>.

  • Page 125: Important Bios Settings

    BIOS Utilities Important BIOS Settings Generally speaking you should not have to adjust any of the BIOS settings as they will already be set for your computer. However the following is a quick reference to the most important settings you may need to change at some point.

  • Page 126: The Power-On Self Test (Post)

    BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds QuickBoot Mode to conduct a POST, including a quick test of the on-board RAM. choose As the POST proceeds, the computer will tell you if there is anything QuickBoot Mode (not available for all mod- wrong.

  • Page 127: Post Screen

    BIOS Utilities POST Screen Figure 5 - 1 Post Screen Phoenix Bios 4.0 Release 6.0 Copyright 1985 - 2000 Phoenix Technologies Ltd. All Rights Reserved CPU = Intel(R) Pentium(R) 4 CPU 2.00GHz 127M System RAM Passed 256K Cache SRAM Passed System BIOS shadowed Video BIOS shadowed Post Screen...

  • Page 128: Failing The Post

    BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non-fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.

  • Page 129: The Setup Program

    BIOS Utilities The Setup Program The Phoenix Setup program tells the system how to configure itself and manage basic features and subsystems (e.g. port configuration and power management). Entering Setup To enter Setup, turn on the computer and press F2 during the POST. The prompt seen in Figure 5 - 2 is usually present for a few seconds after you turn on the system.

  • Page 130: Setup Screens

    BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. The Setup interface looks like a “windows” screen: Setup Main Menu Setup menus Along the top of the screen is a menu bar with five (5) menu head- shown in this section ings.

  • Page 131: Main Menu

    BIOS Utilities Main Menu Figure 5 - 2 Main Menu PhoenixBIOS Setup Utility Main Main Advanced Security Power Boot Exit Item Specific Help System Time [22:01:05] System Date [12/23/2001] <Tab>, <Shift Tab>, or Legacy Diskette A: [1.44/1.25 MB 3 "] <Enter>...
  • Page 132 BIOS Utilities Legacy Diskette A: (Main Menu) This control “enables” the floppy disk drive. Switching Hard Disks Primary Master (Main Menu) Pressing Enter opens the sub-menu to configure the main IDE HDD Every time you install a which fits into the computer’s HDD bay. different hard disk in the computer, it should be (re)configured, un-...
  • Page 133 BIOS Utilities Note: For future use, and as a precaution, make a record the hard disk’s original configuration. LBA Warning LBA Mode Control (Main Menu >Primary Master) If your hard disk is larger than 528MB (unformatted capacity), en- If you enable LBA mode for a particular able this control.
  • Page 134 BIOS Utilities 32 Bit I/O (Main Menu >Primary Master) Most new hard disks can support this higher rate. If yours can’t, the “Enabled” setting may slow down the system. Enables 32-bit com- munication between CPU and IDE card. Requires PCI or local bus. Secondary Master &...

  • Page 135: Advanced Menu

    BIOS Utilities Advanced Menu Figure 5 - 3 Advanced Menu PhoenixBIOS Setup Utility Main Advanced Advanced Security Power Boot Exit Item Specific Help Installed O/S [Win2K] Win2K Legacy USB Support: [Enabled] QuickBoot Mode: [Enabled] Select the operating Boot-time Diagnostic Screen: [Enabled] system installed Reset Configuration Data;...
  • Page 136 BIOS Utilities Legacy USB Support: (Advanced Menu) Choose “Enabled” if you intend to use USB devices in DOS or other non Plug & Play OS’s. QuickBoot Mode: (Advanced Menu) If disabled the system will skip certain tests as it starts up, thus de- creasing the time to boot up.

  • Page 137: Advanced Menu > Advanced Chipset Control

    BIOS Utilities Advanced Menu > Advanced Chipset Control Figure 5 - 4 Advanced Chipset PhoenixBIOS Setup Utility Control Advanced Advanced Advanced Chipset Control Item Specific Help Select the size of the Graphics Aperture: 32 Mb Graphics Aperture for the AGP video device. Graphics Aperture Frequency Ratio [X 8]...
  • Page 138 BIOS Utilities Frequency Ratio (Advanced Menu > Advanced Chipset Control) This selects the internal frequency multiplier of the CPU. This should already be optimized for your system (check with your ser- vice representative if you are not sure). However if you are upgrad- ing/changing the CPU it is important to note the setting.

  • Page 139: Security Menu

    BIOS Utilities Security Menu Figure 5 - 5 Security Menu PhoenixBIOS Setup Utility Main Advanced Security Security Power Boot Exit Item Specific Help Set Supervisor Password [E E nter] Set User Password [Enter] Supervisor Password Password on boot: [Disabled] controls access to the setup utility.
  • Page 140 BIOS Utilities Supervisor Password is: (Security Menu) Set a password for access to the Setup utility (this will not affect ac- cess to the computer OS, only the Setup utility). Password Warning Password on boot: (Security Menu) If you set a boot pass- word, NEVER forget Set a password for booting the computer.

  • Page 141: Power Menu

    BIOS Utilities Power Menu Figure 5 - 6 Power Menu PhoenixBIOS Setup Utility Main Advanced Security Power Boot Exit Power Item Specific Help Power Savings [Stay Off] This is Power Loss System FAN Speed [Medium] Control CPU FAN Speed [Low] Application Note Some applications will automatically...

  • Page 142: Boot Menu

    BIOS Utilities Boot Menu Figure 5 - 7 BOOT Menu PhoenixBIOS Setup Utility Main Advanced Security Power Boot Boot Exit Item Specific Help Removable Devices Keys used to view or Hard Drive configure devices: CD-ROM Drive <Enter> expands or collapses devices with a + or - <Ctrl+Enter>...
  • Page 143 BIOS Utilities Boot devices usually are hard drives, floppy drives, CD-ROM’s, and network cards. When you specify a device as a boot device on the Boot Menu, it re- quires the availability of an operating system on that device. Most computers come with an operating system already installed on hard- drive “C:”.

  • Page 144: Exit Menu

    BIOS Utilities Exit Menu Figure 5 - 8 Exit Menu PhoenixBIOS Setup Utility Main Advanced Security Power Boot Exit Exit Item Specific Help Exit Saving Changes Exit Discarding Changes Exit System Setup and Load Setup Defaults save your changes to CMOS.
  • Page 145 BIOS Utilities 5 - 22...

  • Page 146: Upgrading The Computer

    Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains the information on upgrading the computer. Follow the steps outlined to make the desired upgrades. If you have any trouble or problems you can contact your service representative for further help.

  • Page 147: When Not To Upgrade

    Upgrading The Computer The chapter includes: • Replacing the HDD • Upgrading the System Memory • Replacing the CD Device • Installing the RF Module Please make sure that you review each procedure before you perform it. When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replacing parts.

  • Page 148: Hard Disk Drive Upgrade

    Upgrading The Computer Hard Disk Drive Upgrade The hard disk drive is used to store your data internally in the com- puter. It is mounted at the left side and can be taken out to accommo- date other 3.5” IDE hard disk drives of the same or higher capacity. Removing the Hard Disk 1.

  • Page 149: Installing An Upgrade Hdd

    Upgrading The Computer 4. Remove screws “1” - “4” from the assembly, and slide the hard disk out of the case. Installing an Upgrade HDD Just reverse the removal procedure to install the new HDD. Figure 6 - 2 HDD Screws 6 - 4 Hard Disk Drive Upgrade...

  • Page 150: Some Things To Watch Out For

    Upgrading The Computer Some Things to Watch Out For Software HDD System Warning Allow the system to auto-detect the new HDD, or if necessary, run the Setup Utility in the BIOS to customize the system (“Main Menu” New HDD’s are blank. on page 5 - 8).

  • Page 151: Upgrading The System Memory

    Upgrading The Computer Upgrading the System Memory The computer can accommodate up to 1GB of memory in two Warranty Warning DIMM sockets. It supports 128/256/512MB modules of PC800 RDRAM specification. Note that the proce- dure to upgrade or re- place memory involves extensive dis- assembly of the sys-...
  • Page 152 Upgrading The Computer 1. Turn off the computer. 2. Place the computer with its LCD display facing down on a clean, dry, level surface. 3. Remove screw “1” from the rear of the computer 4. Slide the rear cover “2” up towards the top of the computer and remove it.
  • Page 153 Upgrading The Computer 5. Remove screws “1” and “2” from the bracket “3”. 6. Carefully ease the bracket out of the computer. Figure 6 - 4 Bracket Removal 6 - 8 Upgrading the System Memory...
  • Page 154 Upgrading The Computer 7. Remove screws “1” -”10” from the rear of the LCD case. 8. Carefully ease the rear case up from the front unit. 9. Disconnect the fan cable from the mainboard at point “11”. Cables 10. Disconnect the audio cable “12” from the inside of the case. The fan cable connec- tor is located at point “11”, and is on the...
  • Page 155 Upgrading The Computer 12. Remove screws “1” - “3”. 13. Slide the mainboard cover forward and lift it up and away from the main assembly. Figure 6 - 6 Mainboard Cover 14. The memory sockets will now be visible at point “4” on the Removal mainboard.
  • Page 156 Upgrading The Computer 15. For each module you want to replace gently pull the two latches toward the sides of the socket to release the module. 16. Remove the memory module and insert the new one. The mod- Contact Warning ule will only fit one way as defined by the pin alignment.
  • Page 157 Upgrading The Computer 18. Reverse the procedures to put the computer back together, and do not forget all the screws, covers and cables. Pay particular attention to connecting the audio cable before replacing the rear cover screws. 19. When you restart the computer the new memory configuration should be registered.

  • Page 158: Replacing The Cd-Device

    Upgrading The Computer Replacing the CD-Device Your computer comes with two bays for 12.7mm high removable CD-Devices. Depending on your configuration you may have a: • CD-ROM • DVD-ROM • CD-RW • Combo At least one of these devices should already be installed depending upon the model you purchased.

  • Page 159: Removing The Cd Device

    Upgrading The Computer Removing the CD Device 1. Turn off the computer and pull the LCD up and forward to allow easier access to the latches “1” & “2”. 2. Slide the latches to unlock the drives and hold in place as you pull the drive out of the bay (the left bay latch slides to the right.

  • Page 160: Installing The Rf Module

    Upgrading The Computer Installing the RF Module If you need to install an RF module into the case follow this proce- dure. 1. Turn off the computer and pull the LCD up and forward to allow easier access to the latch “1”. 2.
  • Page 161 Upgrading The Computer 4. Turn the case over and remove screws “1” - “3”, then remove the case cover “4”. Figure 6 - 10 5. Insert the RF module into the case with the rear of the board RF Module Insertion facing upwards, then insert screws at positions “5”...
  • Page 162 Upgrading The Computer 6. Replace the case cover and 3 screws then insert the module case back into the computer. 7. Make sure the module is locked. 8. Install the driver for your RF module (see “What To Install” on page 4 - 2).

  • Page 163: Upgrading The Processor

    Upgrading The Computer Upgrading the Processor If you want to upgrade your computer by replacing the existing pro- cessor with a faster or newer one you will need to contact your cus- tomer service representative. We recommend that you do not do this yourself, since if it is done incorrectly you may damage the processor or mainboard.

  • Page 164: Troubleshooting

    Troubleshooting Chapter 7: Troubleshooting Overview Should you have any problems with your computer, before consult- ing the service center, you may want to try to solve the problem your- self. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic.

  • Page 165: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the so- lution to a problem when your computer appears not to be working. •Power: Is the computer actually plugged into a working electrical outlet? If plugged into a power strip , make sure it is actually working.
  • Page 166 Troubleshooting •Connections: Check the brightness of the screen by adjusting the On Screen Display ( “Advanced Video Controls” on page 3 - 2 ). •Display Choice: Check the settings in the On Screen Display to make sure it is not currently set to Video Signal input instead of PC Signa l ( “Advanced Video Controls”...

  • Page 167: Backup And General Maintenance

    Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial num- bers if you are storing them out of their original cases e.g. in a CD wal- let.

  • Page 168: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the definitions file updates are usually downloadable directly from the internet.

  • Page 169: Upgrading And Adding New Hardware/Software

    Troubleshooting Upgrading and Adding New Hardware/ Software Warranty The CPU is not a user • Do not be tempted to make changes to your Windows Registry unless serviceable part. you are very sure of what you are doing, otherwise you will risk Opening this compart- severely damaging your system.
  • Page 170 Troubleshooting • Make sure you have installed the drivers for any new hardware you have installed (latest driver files are usually available to download from vendor’s websites). • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs.

  • Page 171: Display

    Troubleshooting Display Nothing appears on screen. possible cause: The system is in a power saving mode. indicator: The LED power button, is blinking green ( Standby ), or is off ( Hibernate ). Press the power button for less than 4 seconds. If solution: the computer does not turn on again then it was most likely shut down, or has no power source.
  • Page 172 Troubleshooting possible cause: The computer is set for a different display. solution: Check the settings in the On Screen Display to make sure it is not currently set to Video Signal input instead of PC Signa l ( “Advanced Video Controls”...
  • Page 173 Troubleshooting The screen images aren’t clear. possible cause: The viewing angle of the LCD is bad. indicator: The screen appears shiny or too dim. solution: Adjust the position of the LCD. LCD’s are designed to be viewed “straight on”. If the angle is wrong, you may see glare from the screen’s backlight.
  • Page 174 Troubleshooting possible cause: The screen is suffering from burn-in . indicator: The screen has ghost images, even when it’s off. solution: This problem is usually associated with external CRT monitors. Use power saving options ( “Con- serving Power Throughout the Whole Sys- tem”...
  • Page 175 Troubleshooting No image appears on the external monitor or TV I have plugged in and powered on. possible cause: You haven’t enabled the other display. solution: “Enabling Other Displays” on page 3 - 14 . possible cause: You haven’t installed the video driver and con- figured it appropriately from the Control Panel .

  • Page 176: Hard Disk Drive (Hdd)

    Troubleshooting Hard Disk Drive (HDD) The computer takes longer during Startup. Password Warning possible cause: Data saved on the hard disk drive may be lost or damaged. If you choose set a solution: Please operate the scan disk or disk defragmenter boot password, NEV- ER forget your pass- to check for any lost or damaged data.

  • Page 177: Floppy Disk Drive (Fdd)

    Troubleshooting Floppy Disk Drive (FDD) The floppy disk drive will not write data to disk. Media Warning possible cause: The floppy disk is not formatted. solution: Format the disk (you may do this by right-click- Don’t try to remove a ing the disk icon in My Computer in Windows floppy disk while the and choosing Format from the menu).

  • Page 178: Audio

    Troubleshooting The message “Invalid system disk - Replace the disk, and then press any key” appears. possible cause: The computer is trying to boot from an incorrect Sound Volume Ad- floppy disk. justment solution: Remove the floppy and insert a correct one, or How high the sound boot from your hard disk or CD.

  • Page 179: Cd Device

    Troubleshooting CD Device The compact disc cannot be read. Media Warning possible cause: The compact disc is dirty. solution: Clean it with a CD-ROM cleaner kit. When manually eject- ing a CD/DVD disc, The compact disc tray will not open when there is a disc in the DO NOT use a sharp- ened pencil or similar tray.
  • Page 180 Troubleshooting A music compact disc can be read while a data disc can not. possible cause: There may be a problem with the disc hardware or software. solution: Refer to your operating system manual for more information on the software and make sure you have the correct software installed for running video compact discs/DVD’s.
  • Page 181 Troubleshooting All compact discs cannot be read. possible cause: The Windows system does not recognize the CD- ROM drive, or the CD-ROM drive is not com- patible with other devices. solution: 1. Make sure you have the CD-ROM drive prop- erly installed and configured.

  • Page 182: Pc Card

    Troubleshooting PC Card The system cannot recognize the PC card. possible cause: The PC card is not inserted into the socket or inserted incorrectly. solution: Remove the card and reinsert it aligning the PC card with the slot. Push the card in until it locks into place.

  • Page 183: The Pc Card Problem In Windows 98

    Troubleshooting The PC Card Problem in Windows 98 After installation of Windows 98 or Windows 98 Second Edition , you may find that the PC cards are not working normally and you may also notice one or more of the following: •...

  • Page 184: Keyboard And Mouse

    Troubleshooting Keyboard and Mouse Unwelcome numbers appear when typing. Other Keyboards possible cause: The NumLock is turned ON . If your keyboard is indicator: The LED is lit. damaged or you just solution: Press and release the NumLock key. want make change, you can use I have installed a new external Keyboard or mouse but cannot...
  • Page 185 Troubleshooting The Infrared keyboard doesn’t work. possible cause: The Infrared Receiver is blocked. solution: Make sure nothing is between your system’s Infrared Receiver and the keyboard. The Infra- red Receiver operates on a “Line of Sight”. The RF keyboard or mouse doesn’t work. possible cause: The keyboard or mouse need to be synchronized with the RF module.

  • Page 186: Printer

    Troubleshooting Printer The printer cannot be added to the system or will not work. possible cause: The printer power is off or the printer is not cor- rectly connected to the computer. solution: Check all connections and cables and the try to reinstall the driver.
  • Page 187 Troubleshooting possible cause: There is no paper in the printer, or the paper is incorrect for the settings designated in your soft- ware. solution: Put more paper in the printer (also fan the paper to make sure it doesn’t stick together and cause a paper jam) and check the paper size matches your software’s “print”...
  • Page 188 Troubleshooting possible cause: The operation mode for the parallel por t set in the BIOS doesn’t correspond with the mode your printer can work with. solution: Please check your printer manual to find out which mode your printer uses. Check that the settings in the BIOS ( “Advanced Menu”...
  • Page 189 Troubleshooting 7 - 26...

  • Page 190: Appendix A. Specifications

    Appendix A. Specifications Processor ® • Intel Pentium 4 1.4 ~ 2.0+GHz • Supports mPGA478 Package Memory Module Warning Core Logic There must be a mem- • Intel 850 ory module present in both DIMM sockets to Structure make sure the compu- ter will boot up.
  • Page 191 BIOS • 2MB Flash ROM Phoenix BIOS • Supports Plug and Play, ACPI 2.0 • 17"/18.1" SXGA 1280*1024 TFT LCD Display ™ • ATI M6-P Integrated AGP • Integrated 128-bit 2D/3D Graphics Accelerator Advanced HW Acceleration for DVD Playback (Motion Compen- sation engine and IDCT) Fully DirectX 8 Compliant Graphics Engine •...

  • Page 192: Pc Card Sockets

    Storage • One 3.5” 1.44MB 3-mode FDD (slim type) • One 3.5” HDD • Two slim storage bays for CD Devices Device Bay Right: Changeable with CD-ROM/CD-RW/DVD/Combo drive Device Bay Left: Changeable with CD-ROM/CD-RW/DVD/Dummy or RF module Audio • AC97’ 2.2 compatible •...

  • Page 193: Power Management

    Interface • One parallel port • One D-sub 15-pin CRT port compliant DC1.1 • Four USB ports • One IEEE 1394 port • One RJ-45 jack for 100M/10M Ethernet LAN • One RJ-11 port for Modem • One Video-in for TV-tuner (Optional TV-tuner) •...

  • Page 194: Environmental Spec

    Indicators • LED indicators (HDD/FDD activity, status indicators) Environmental Spec • Temperature Relative Humidity º º • Operating: 5 C ~ 35 Operating: 20% ~ 80% º º • Non-Operating: -10 C ~ 60 Non-Operating: 10% ~ 90% Physical Dimensions •...
  • Page 195 A - 6...

  • Page 196: Glossary

    Glossary AC ( A lternating C urrent) - The power from a standard household electrical outlet. adapter - A device that allows compatibility between different equipment. An AC adapter converts AC current to DC current which is needed to operate a computer. AGP ( A ccelerated G raphics P ort) - A high-speed graphics port that provides a direct connection between the display adapter and mem- application - A program such as a word processor, database or im-...
  • Page 197 boot - The loading of the operating system and other basic software which occurs when you start-up the computer. bus - A collection of wires through which data is transmitted from one part of a computer to another. byte ( b inar y te rm) - A unit of storage capable of holding a single character.
  • Page 198 DC ( D irect C urrent) - Power which a computer requires for opera- tion. DIP switch - A series of tiny switches built into circuit boards which enable you to configure a circuit board for a particular type of com- puter or application.
  • Page 199 flash ROM BIOS - see flash BIOS. function key - The keys F1, F2, … which have specific functions as- signed to them. By pressing one of the function keys you can execute certain commands depending on the computer and operating system you are using.
  • Page 200 change data or use a printer without a cable connection. jack - A connector used primarily to connect external devices to your computer such as a microphone, video source, phone line, etc. jumper - A metal bridge that closes an electrical circuit. They are sometimes used to configure expansion boards.
  • Page 201 puter are LEDs. load - To copy a program from some source, such as a disk or tape, into memory for execution. Lithium-Ion battery - A type of battery which is ideal for notebook computers because of its light weight and high energy density. Also, lithium-ion batteries do not use poisonous metals, such as lead, mer- cury or cadmium.
  • Page 202 when receiving a signal from the telephone line. module - Referring to hardware, a module is a self-contained com- ponent. mouse - The most popular pointing device. It was called a mouse be- cause it more or less resembled one, with the cord being the mouse’s tail.
  • Page 203 PCMCIA Card - A credit-card sized, removable module for porta- ble computers standardized by PCMCIA. Also known as PC Cards, they are 16-bit devices that are used to attach modems, network adapters, sound cards, radio transceivers, solid-state disks and hard disks to a portable computer.
  • Page 204 RAM ( R andom A ccess M emory) - The memory available to pro- grams, different programs will need more or less RAM depending on what they are doing. RAM is the most common type of memory found in computers. reboot - To restart a computer.
  • Page 205 break down. SDRAM ( S ynchronous DRAM ) - A type of DRAM that can run at much higher clock speeds than conventional memory. serial port - A socket on a computer used to connect a modem, mouse, scanner or other serial device to the computer. setup - (1) A utility program which modifies the BIOS.
  • Page 206 TFT ( T hin F ilm T ransistor) - The term typically refers to active ma- trix screens on laptop computers. Active matrix LCD provides a sharper screen display and broader viewing angle compared to pas- sive matrix. USB ( U niversal S erial B us) - Hardware interface for low-speed pe- ripherals such as the keyboard, mouse, joystick, scanner, printer and telephony devices.
  • Page 207 Zoomed Video (ZV) Port - An extension to the PC Card (PCMCIA) standard that provides a high transfer rate for video applications on portable computers. The ZV Port is built into the notebook computer and activated by plugging in an MPEG PC Card that is ZV Port-com- pliant.

Table of Contents
