Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
Page 4 Preface R&TTE Directive This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Direc- tive 1999/5/EC. This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Lux- embourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland, United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slov- enia.
Page 5: Fcc Statement
Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 6: Fcc Rf Radiation Exposure Statement
Preface FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
Page 7: Important Safety Instructions
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Page 8: Instructions For Care And Operation
Preface Instructions for Care and Operation The computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Keep it dry, and don’t overheat it.
Page 9: Power Safety
Preface Power Safety The computer has specific power requirements: • When you want to unplug the power cord, be sure to disconnect it by the plug head, not  by its wire. • Make sure the socket and any extension cord(s) you use can support the total current Power Safety load of all the connected devices.
Page 10: Cleaning
Preface Cleaning Do not apply cleaner directly to the computer, use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.
Page 11: Ergonomics
Preface Ergonomics We designed your Multimedia PC system to be functional as well as attractive. To get most out of it, here are some suggestions on how to position and use the computer: • The top third of the LCD (screen) should be at eye-level or slightly below. •...
Page 12 Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...
Page 13: Wall Mounting Information
Preface Wall Mounting Information The computer may be mounted on a wall for display. The system meets VESA (FDMI) Standard (100mm * 100mm) for wall mounting. However if you intend to wall mount the system please contact your service center for information in order to avoid personal injury, or damage to the computer.
Page 14 Preface...
Page 15: Table Of Contents
Preface Contents Notice .................I HDMI-In Port ..............1-11 FCC Statement ..............III Mode Toggle ..............1-11 FCC RF Radiation Exposure Statement: ......IV System Map: Right View ..........1-12 Instructions for Care and Operation ....... VI System Map: Rear View ..........1-13 Power Safety ..............VII Windows 7 Start Menu &...
Page 16 Preface Power Management USB 3.0 ................4-6 Intel MEI Driver ............4-6 Overview ................3-1 Audio ................4-6 Turning On the Computer ..........3-2 Windows Experience Index ...........4-7 Power Plans ..............3-3 Optional Drivers ............4-8 Power-Saving States ............3-5 PC Camera Module ............4-8 Sleep ................3-5 Wireless LAN Module ...........4-8 Hibernate ................3-6 Bluetooth Module ............4-8 Shut down ..............3-6...
Page 17 Preface Advanced Menu .............5-8 Modules & Options Advanced Chipset Control (Advanced Menu) ....5-8 Overview ................7-1 Total Graphics Memory (Advanced Menu > PC Camera Module ............7-2 Advanced Chipset Control) ...........5-9 PC Camera Driver Installation ........7-2 SATA Mode (Advanced Menu) ........5-9 PC Camera Audio Setup ..........7-3 Legacy USB Support: (Advanced Menu) ......5-9 Wireless LAN Module ...........7-9 Boot-time Diagnostic Screen (Advanced Menu) ...5-9...
Page 18 Preface Upgrading and Adding New Hardware/Software ..8-5 Intel Video Driver Controls Problems & Possible Solutions ........8-7 Intel Video Driver Installation ........B-1 Bluetooth Connection Problems ........8-10 Video ................B-1 Wake On LAN Setup ...........8-14 Dynamic Video Memory Technology ......B-1 Intel® Graphics & Media Control Panel ...... B-2 Interface (Ports &...
Page 19 Preface Communication ............. C-4 Power Management ............C-4 Power ................C-4 Security ................. C-4 Operating System ............C-4 Environmental Spec ............C-4 Physical Dimensions & Weight ........C-5 XVII...
Page 20 Preface XVIII...
Page 21: Quick Start Guide
Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...
Page 22: Advanced Users
Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...
Page 23: Not Included
Quick Start Guide Not Included Operating Systems (e.g. Windows 7) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals.  Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers listed in “Drivers &...
Page 24: System Startup
Quick Start Guide System Startup Remove all packing materials, CDs/DVDs and floppy disks etc. Securely attach any peripherals you want to use with the computer to their ports (e.g keyboard and mouse etc.) Attach the AC/DC adapter to the DC-In jack located under the LCD, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.
Page 25: System Map: Front View
Quick Start Guide System Map: Front View Optional Built-In PC Camera LCD (With Optional Touch Panel - see page Power & System Activity LED Indicators Function Buttons* Power Button* USB 2.0 Ports Microphone-In Jack Headphone/Speaker-Out Jack RJ-45 LAN Jack 10. 2 * USB Ports 11.
Page 26: Tilting The Lcd Screen
Quick Start Guide Tilting the LCD Screen It is possible to tilt the LCD screen in order to get the best possible viewing angle of the screen without glare etc. Apply pressure with one hand at the base of the computer, while carefully pushing the LCD screen to tilt it to the appropriate viewing angle.
Page 27: Keyboard Options
Quick Start Guide Keyboard Options There are two keyboard options for this computer series. These keyboards may include embedded numerical keypads for easy numeric data input and/or function keys/hot keys to allow you to change operational features instantly. Some keyboards may require a driver to access all available functions etc. ...
Page 28: Led Indicators & Buttons
Quick Start Guide LED Indicators & Buttons The buttons located under the front panel icons allow you to make screen and input adjustments. The LED indicators on the computer display helpful information about the current status of the computer. Figure 1 - 5 - Front Icons Icon Color Description...
Page 29: On Screen Display Indicators
Quick Start Guide On Screen Display Indicators Visual indicators for brightness and volume are available when the OSD AP is installed (see “On Screen Dis- play” on page 4 - 6). When the driver is installed, an icon will appear in the taskbar. Note that these indicators illustrate the volume and brightness level changes when adjusted by the buttons on the computer itself.
Page 30: System Map: Left View
Quick Start Guide System Map: Left View Figure 1 - 6 Left View  Stand Multi-in-1 Card HDMI-In Port Reader Note that the HDMI-In Port supports video ExpressCard and audio signals from attached HDMI Slot (see page devices. 1 * USB 3.0 Port Multi-in-1 Card Reader HDMI-in Port The card reader allows you to use the most...
Page 31: Hdmi-In Port
Quick Start Guide HDMI-In Port This computer features an HDMI (High-Definition Multimedia Interface) input port that allows you to display external sources such as Blu-ray players, DVDs, set top boxes and games consoles etc. on your computer screen. The computer itself does not need to be powered on to display video and audio from external sources. As long as the computer is plugged-in to a power source through the AC/DC adapter (the LED indicator will be orange if the computer is plugged-in but powered off), simply plug-in the HDMI cable from the external device to the...
Page 32: System Map: Right View
Quick Start Guide System Map: Right View Figure 1 - 8 - Right View Stand Optical Device Drive Bay (for CD/DVD Device - see page Security Lock Slot  CD Emergency Eject If you need to manually eject a CD/DVD (e.g. due to an un- expected power interruption) you may push the end of a straightened paper clip into the emergency eject hole.
Page 33: System Map: Rear View
Quick Start Guide System Map: Rear View Figure 1 - 9 Rear View  Stand Rear Component Cover The CPU is not a user serviceable Vent/Fan Intake part. Opening this compartment, or Security Lock Slot accessing the CPU in any way, Carrying Handle may violate your warranty.
Page 34: Windows 7 Start Menu & Control Panel
Quick Start Guide Windows 7 Start Menu & Control Panel Most of the control panels, utilities and programs within Windows 7 (and most other Windows versions) are ac- cessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 35: Video Features
Quick Start Guide Video Features You can configure display options from the Display (Control Panel) and Screen Resolution in Windows. For more detailed video information see Chapter B“Video Driver Controls” from page B - To access Display (Control Panel) and Screen Resolution in Windows: Click Start and click Control Panel.
Page 36 Quick Start Guide To access the Intel(R) Graphics Media Accelerator Driver for mobile control panel: Click Advanced settings (Figure 1 - 11 on page 1 - 15) in the Screen Resolution control panel in Win- dows. Click the Intel(R)... tab and click Graphics Properties (button) (Figure 1 - 12 on page 1 - 16) .
Page 37: Power Options
Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 14) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, display and sleep mode from the left menu. Note that the power saver plan may have an affect on computer performance.
Page 38 Quick Start Guide 1 - 18...
Page 39: Features & Components
Features & Components Chapter 2: Features & Components Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical (CD/DVD) Device • Multi-in-1 Card Reader • ExpressCard Slot •...
Page 40: Hard Disk Drive
Features & Components Hard Disk Drive  The hard disk drive is used to store your data in the computer. The hard disk can be Power Safety taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5 mm.
Page 41: Optical (Cd/Dvd) Device
Features & Components Optical (CD/DVD) Device  There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the module you purchased (see “Storage” on page C - 3). The Adjustment optical device is usually labeled “Drive D:”...
Page 42: Handling Cds Or Dvds
Features & Components Handling CDs or DVDs  Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed. If you need to manually eject a CD (e.g.
Page 43: Dvd Regional Codes
Features & Components DVD Regional Codes  To change the DVD regional codes: DVD Region Note Go to the Control Panel Double-click Device Manager (Hardware and Sound), then click the + next to DVD region detection is DVD/CD-ROM drives. device dependent, not Double-click on the DVD-ROM device to bring up the Properties dialog box, and OS-dependent.
Page 44: Multi-In-1 Card Reader
Features & Components Multi-in-1 Card Reader  The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Page 45: Expresscard Slot
Features & Components ExpressCard Slot  The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/ ExpressCard Slot 34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC Cover Cards). Make sure you keep the ExpressCard/54 is used for applications which cover in the Express- require a larger interface slot, e.g.
Page 46: Audio Features
Features & Components Audio Features  You can configure the audio options on your computer from the Sound control Sound Volume panel in Windows, from the HD VDeck icon on the desktop or VIA HD Audio Adjustment Deck control panel The sound volume level The volume may also be adjusted by means of the function buttons located along the is set using the volume...
Page 47 Features & Components Expert Mode will allow you to access more advanced configuration menus. Figure 2 - 7 VIA HD Audio Deck (Expert Mode) Audio Features 2 - 9...
Page 48: Adding A Printer
Features & Components Adding a Printer  The most commonly used peripheral is a printer. The following conventions will Parallel Printer help you to add a printer, however it is always best to refer to the printer manual for specific instructions and configuration options. After setting up the print- er attach the parallel ca- ble to the printer.
Page 49: Power Management
Power Management Chapter 3: Power Management  Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.
Page 50: Turning On The Computer
Power Management Turning On the Computer  Now you are ready to begin using your computer. To turn it on simply press the pow- Forced Off er button on the front panel. If the system “hangs”, When the computer is on, you can use the power button as a Stand by/Hibernate/ and the Ctrl + Alt + Del Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and key combination doesn’t...
Page 51: Power Plans
Power Management Power Plans  The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
Page 52 Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance (you may need to click Show additional plans to view the High performance plan) for maximum performance when the computer is pow- ered from an AC power source.
Page 53: Power-Saving States
Power Management Power-Saving States  You can use power-saving states to stop the computer’s operation and restart where Sleep & Touch you left off. Win 7 uses the Sleep, Hibernate and Shut Down power-saving states. Screen Sleep Note that touching the screen when the com- In Sleep all of your work, settings and preferences are saved to memory before the puter is in Sleep will...
Page 54: Hibernate
Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost.
Page 55: Configuring The Power Buttons
Power Management Configuring the Power Buttons  The power button may be set to send the computer in to either Sleep or Hibernate. Password In Sleep, the LED will blink green. In Hibernate the LED will be orange. If only Protection the display is turned off, the LED will remain green.
Page 56: Resuming Operation
Power Management Resuming Operation You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (see your keyboard documentation). Power Status To Resume Icon Color Power Off Press the Power Button Table 3 - 1 Press the Power Button Resuming...
Page 57: Drivers & Utilities
Drivers & Utilities Chapter 4: Drivers & Utilities What to Install This chapter deals with installing the drivers and utili- ties essential to the operation or improvement of some The Device Drivers & Utilities + User’s Manual disc of the computer’s subsystems. The system takes ad- contains the drivers and utilities necessary for the vantage of some newer hardware components for proper operation of the computer.
Page 58: Driver Installation
Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the disc into the DVD drive and click Install Drivers/Op- Drivers Installer menu below.
Page 59 Drivers & Utilities Manual Driver Installation Driver for Windows 7 Page # Click Browse CD/DVD (button) in the Drivers Install- er application and browse to the executable file in the Chipset Page 4 - 5 appropriate driver folder. Video Page 4 - 5 Page 4 - 5 Windows Update After installing all the drivers make sure you enable...
Page 60: Updating/Reinstalling Individual Drivers
Drivers & Utilities Updating/Reinstalling Individual Drivers User Account Control If you wish to update/reinstall individual drivers it If a User Account Control prompt appears as part of may be necessary to uninstall the original driver.To do the driver installation procedure, click Continue or this go to the Control Panel in the Windows OS and Allow, and follow the installation procedure as direct- double-click the Programs and Features icon (Pro-...
Page 61: New Hardware Found
Drivers & Utilities New Hardware Found Driver Installation Procedure If you see the message “New Hardware Found” dur- Insert the Device Drivers & Utilities + User’s Manual ing the installation procedure (other than when out- disc into your DVD drive and click Install Drivers lined in the driver install procedure), click Cancel (button).
Page 62: Expresscard/Card Reader
Drivers & Utilities ExpressCard/Card Reader Intel MEI Driver 1. Click 4.Install Cardreader Driver > Yes. 1. Click 7.Install MEI Driver > Yes. 2. Click Install > Finish. 2. Click Next > Yes > Next > Next. 3. Click Finish. On Screen Display Audio 1.
Page 63: Windows Experience Index
Drivers & Utilities Windows Experience Index  After the drivers are installed follow this procedure to ensure an accurate rating from the Windows Experi- Windows 7 Update ence Index: After installing all the drivers make sure you enable Win- dows Update in order to get all the latest security up- 1.
Page 64: Optional Drivers
Drivers & Utilities Optional Drivers PC Camera Module See the pages indicated for the driver installation pro- See the introduction in “PC Camera Module” on cedures for any modules included in your purchase op- page 7 - 2, and check the installation procedure. tion.
Page 65: Bios Utilities
BIOS Utilities Chapter 5: BIOS Utilities  Overview BIOS Screens Note that BIOS This chapter gives a brief introduction to the computer’s built-in software: screens pictured these pages are intend- Diagnostics: The POST (Power-On Self Test) ed for guidance in set- ting up your system’s BIOS.
Page 66: The Power-On Self Test (Post)
BIOS Utilities The Power-On Self Test (POST)  Each time you turn on the computer, the system takes a few seconds to conduct a POST Screen POST, including a quick test of the on-board RAM (memory). 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. If there 2.CPU type is a problem that prevents the system from booting, it will display a system summary 3.Memory status...
Page 67: Failing The Post
BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.
Page 68: The Setup Utility
BIOS Utilities The Setup Utility  The Phoenix SecureCore Setup Utility tells the system how to configure itself and BIOS Settings manage basic features and subsystems (e.g. port configuration). Warning Entering Setup Incorrect settings can cause your system to To enter Setup, turn on the computer and press F2 during the POST. The prompt malfunction.
Page 69: Setup Screens
BIOS Utilities Setup Screens  The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with menu headings. When you select a Setup menus heading, a new screen appears. Scroll through the features listed on each screen to shown in this section are make changes to Setup.
Page 70: Main Menu
BIOS Utilities Main Menu Figure 5 - 2 Main Menu System Time & Date (Main Menu) The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you can change the date and time settings in your operating system, you will also change these settings.
Page 71: Sata Port 1/2/3/4 (Main Menu)
BIOS Utilities SATA Port 1/2/3/4 (Main Menu) Pressing Enter opens the sub-menu to show the configuration of a optical Device/ HDD on the computer’s SATA Ports. Use the Auto (Type:) setting to have the items configured automatically for you. System/Extended Memory (Main Menu) This item contains information on the system memory, and is not user configurable.
Page 72: Advanced Menu
BIOS Utilities Advanced Menu Figure 5 - 3 Advanced Menu Advanced Chipset Control (Advanced Menu) The sub-menu here allows you to enable/disable the JMicron Power Saving (as used by the card reader) control, and to adjust the amount of Total Graphics Mem- ory used by the system.
Page 73: Total Graphics Memory (Advanced Menu > Advanced Chipset Control)
BIOS Utilities Total Graphics Memory (Advanced Menu > Advanced Chipset Control)  Use this menu item to set the amount of system memory to be allocated for use by ® Intel Dynamic Video Memory Technology for the graphics device. The default SATA Mode memory size allocated is MaxDVMT (up to 384MB) and this may be adjusted to Selection...
Page 74: Legacy Os Boot (Advanced Menu)
BIOS Utilities Legacy OS Boot (Advanced Menu) If “Enabled” the system will attempt to load the Legacy OS (e.g. Windows 7) first. If set to “Disabled” the system will attempt to EFI (Extensible Firmware Interface) boot before the Legacy OS. Power On Boot Beep (Advanced Menu) Use this menu item to enable/disable the beep as the computer starts up.
Page 75: Security Menu
BIOS Utilities Security Menu  Security Menu changes make here affect the access to the Setup utility itself, and also access to your ma- chine as it boots up af- ter you turn it on. These settings do not affect your machine or network passwords which will be set in...
Page 76: Set User Password (Security Menu)
BIOS Utilities Set User Password (Security Menu)  You can set a password for user mode access to the Phoenix SecureCore Setup Utility. This will not affect access to the computer OS, (only the Setup utility) unless Password Warning you choose to set a Password on Boot (see below). Many menu items in the Phoenix If you set a boot pass- SecureCore Setup Utility cannot be modified in user mode.
Page 77: Boot Menu
BIOS Utilities Boot Menu  BIOS Screens Note that BIOS screens pictured these pages are intend- ed for guidance in set- ting up your system’s BIOS. BIOS versions are sub- ject to constant change and revision, therefore your computer’s actual screens appear slightly different from...
Page 78: Exit Menu
BIOS Utilities Exit Menu Figure 5 - 6 Exit Menu Choosing to Discard Changes, or Exit Discarding Changes, will wipe out any changes you have made to the Setup. You can also choose to restore the original Set- up defaults that will return the Setup to its original state, and erase any previous changes you have made in a previous session.
Page 79: Upgrading The Computer
Upgrading The Computer Chapter 6: Upgrading The Computer Overview  This chapter contains information on upgrading the computer. Follow the steps out- lined to make the desired upgrades. If you have any trouble or problems you can con- Warranty Warning tact your service representative for further help.
Page 80: When Not To Upgrade
Upgrading The Computer When Not to Upgrade  These procedures involve opening the system’s case, adding and sometimes replac- ing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake upgrade proce- • Your system is still under warranty or a service contract dures, make sure that •...
Page 81: Removing The Rear Top Cover
Upgrading The Computer Removing the Rear Top Cover Before undertaking any upgrade procedure it is necessary to remove the rear top cover to access the components. Turn off the computer and disconnect all cables and peripherals. Carefully place the computer flat with the LCD facing down (make sure you cover the LCD to avoid scratches) so that you may access the rear cover.
Page 82 Upgrading The Computer Slide the rear top cover until the arrow is aligned with the unlock icon Figure 6 - 2 Rear Top Cover Unlock When the arrow is aligned with the unlock icon you can remove the rear top cover Figure 6 - 3 Rear Top Cover...
Page 83: Wireless Keyboard & Mouse Usb Transceiver
Upgrading The Computer Wireless Keyboard & Mouse USB Transceiver  If your purchase includes an optional Wireless Keyboard & Mouse Kit you can use Dongle & USB Ports the USB port located behind the rear top cover to house the USB transceiver. A single USB dongle is pro- Remove the rear cover (see “Removing the Rear Top Cover”...
Page 84: Upgrading The Hard Disk Drive
Upgrading The Computer Upgrading the Hard Disk Drive  The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard HDD System disk drives with a height of 9.5mm (h) (see “Storage” on page C - 3).
Page 85 Upgrading The Computer Slide the hard disk in the direction of arrow , and then slide it in the direction of arrow to remove it. Figure 6 - 6 Hard Disk Assembly Removal Remove the adhesive hard disk cover Figure 6 - 7 Hard Disk Cover Removal Reverse the process to install a new hard disk.
Page 86: Upgrading The System Memory (Ram)
Upgrading The Computer Upgrading the System Memory (RAM)  The computer has two memory sockets for 204 pin Small Outline Dual In-line (SO- Contact Warning DIMM) DDRIII (DDR3) type memory modules (see “Memory” on page C - 3 details of supported module types). Be careful not to touch the metal pins on the The total memory size is automatically detected by the POST routine once you turn...
Page 87 Upgrading The Computer Gently pull the two release latches on the sides of the memory socket in the direction indicated by the arrows ( & Figure 6 - Figure 6 - 9 RAM Module Release The RAM module will pop-up, and you can remove it. Pull the latches to release the second module if necessary.
Page 88 Upgrading The Computer Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory socket (see sidebar note if you are inserting a single module). Figure 6 - 10 RAM Module Removal ...
Page 89: Upgrading The Processor
Upgrading The Computer Upgrading the Processor  If you want to upgrade your computer by replacing the existing processor with a fast- er/new one you will need to contact your customer service representative. We rec- Warranty ommend that you do not do this yourself, since if it is done incorrectly you may The CPU is not a user damage the processor or mainboard.
Page 90 Upgrading The Computer 6 - 12...
Page 91: Modules & Options
Modules & Options Chapter 7: Modules & Options Overview This chapter contains information on the following modules, which may come with your computer, depending on the configuration purchased. If you are unsure please contact your service representative. • PC Camera Module •...
Page 92: Pc Camera Module
Modules & Options PC Camera Module  There are a number of different camera modules available with this computer model PC Camera Screen series. You will have the appropriate application installed for your camera. Make Refresh sure you access the application via the desktop shortcut. The PC Camera module uses the camera application to capture video files.
Page 93: Pc Camera Audio Setup
Modules & Options PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to connect a microphone to either of the microphone ports and then setup the audio recording op- tions in Windows as follows. Click Start, and click Control Panel (or point to Settings and click Control Panel).
Page 94 Modules & Options Figure 7 - 1 Audio Setup for PC Camera Right-click 7 - 4 PC Camera Module...
Page 95 Modules & Options Camera Application The camera application is a video viewer for general purpose video viewing and test- ing, and for capturing video files to .avi format. Run the camera application from the desktop shortcut (it is recommended that you set the capture file before the capture process - see Set Capture File below).
Page 96 Modules & Options Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties).
Page 97 Modules & Options Eliminating Screen Flicker If you find that the video screen in the camera application is flickering, you can try to adjust the setting in the Video Capture Filter options. Run the camera application program from the desktop shortcut. Go to Options and scroll down to select Video Capture Filter..
Page 98 Modules & Options Taking Still Pictures  The camera application allows you to take still pictures. Snapshot Folder Run the camera application from the desktop shortcut. Go to Options and select Take Picture. The Snapshot folder’s The picture (in JPEG format) will be placed in the Snapshot folder on the default location is on the desktop.
Page 99: Wireless Lan Module
Modules & Options Wireless LAN Module If you have included an 802.11b/g/n WLAN module in your purchase option, install the driver as per the procedure overleaf. Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 - 802.11b/g/n Driver Installation 1.
Page 100: Connecting To A Wireless Network In Windows 7
Modules & Options Connecting to a Wireless Network in Windows 7  Make sure the Wireless LAN module is turned on. Network and Click the taskbar wireless icon , and then double-click an access point to con- Sharing Center nect to or click to Open Network and Sharing Center if you do not see a network you want to connect to in the taskbar menu (a list of options will appear allowing You can also use the Net- setting changes, and creating a new network).
Page 101 Modules & Options You may need to enter a security key for any access point to which you are trying to connect. Click to select a network location (e.g. Home, Work or Public). Click “View or change settings in Network and Sharing Center” to access further options for the connection.
Page 102 Modules & Options Click the taskbar icon to see any currently connected networks.  To disconnect from the wireless network you can click the taskbar wireless icon , click the active connection and then click Disconnect (button). Security Enabled Networks You should try to make sure that any network you are connecting to is a se-...
Page 103: Windows Mobility Center
Modules & Options Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on display, audio, power plans used and wireless device status etc. To access the Windows Mobility Center: Click Start, and click Control Panel (or point to Settings and click Control Panel).
Page 104: Bluetooth & Wlan Combo Module
Modules & Options Bluetooth & WLAN Combo Module If your purchase option includes the Combination Wireless LAN & V3.0 Blue- tooth module then install the driver as instructed overleaf. Follow the instructions on page 7 - 20 to configure the Bluetooth settings. ...
Page 105: Bluetooth Combo Driver Installation
Modules & Options Bluetooth Combo Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. 2. Click Option Drivers (button). 3. Click 3.Install Combo BT Driver > Yes. 4. Choose the language you prefer and click OK. 5.
Page 106: Bluetooth & Wlan Combo Settings
Modules & Options Bluetooth & WLAN Combo Settings Double-click the My Bluetooth application on the desktop (or access it from the Programs/All Programs menu) Click My Bluetooth Settings (menu heading). Figure 7 - 7 My Bluetooth Settings 7 - 16 Bluetooth & WLAN Combo Module...
Page 107 Modules & Options Click General Settings to change the computer name that other Bluetooth devices will see, and click the tickbox to Allow Bluetooth devices to find this computer Click OK to confirm the settings. Figure 7 - 8 General Settings Bluetooth &...
Page 108 Modules & Options Click File Transfer Settings to Enable sharing of my files with other Bluetooth devices. Click OK to confirm the settings. Figure 7 - 9 File Transfer Settings 7 - 18 Bluetooth & WLAN Combo Module...
Page 109: Bluetooth Networking Setup
Modules & Options Bluetooth Networking Setup Double-click the My Bluetooth application on the desktop (or access it from the Programs/All Programs menu). Click My Bluetooth Settings (see Figure 7 - 7 on page 7 - 16). Figure 7 - 10 Network Settings Click Network Settings (make sure the Bluetooth module is powered on.
Page 110: Bluetooth & Wlan Combo Module Configuration
Modules & Options Bluetooth & WLAN Combo Module Configuration Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Make the device discoverable (to do this check your device documentation). To Add a Bluetooth Device Double-click the My Bluetooth application on the desktop (or access it from the Programs/All Programs menu).
Page 111 Modules & Options You will then be presented with a menu of options to select from. Figure 7 - 12 Bluetooth Device Options Click the appropriate button to connect to the device. Bluetooth & WLAN Combo Module 7 - 21...
Page 112 Modules & Options You may need to allow the connection from your device, and you will then need to provide a passcode from the device. You can then enter the passcode on the computer and click OK to establish the connection.
Page 113: Touch Screen Module
Modules & Options Touch Screen Module  If you have included a Touch Screen module in your purchase option, you should ob- Touch Screen Input tain a stylus pen to interact with the computer in the same way you would use a Device mouse (use a stylus pen to tap/double-tap on-screen buttons etc.).
Page 114 Modules & Options Tablet PC Options Tablet PC settings (for touch screen input) may be customized from the Tablet PC Settings in Windows 7. To access the control panel click Start, and then click Control Panel. The Tablet PC Settings and Pen and Touch control panel are in the Hardware and Sound category.
Page 115 Modules & Options Click Tablet PC Settings and click Other. Click Go to Input Panel Settings (in Tablet PC Input Panel Options) to configure where and how the Tablet PC Input Panel appears. Figure 7 - 15 Input Panel Settings Touch Screen Module 7 - 25...
Page 116: 7 - 26 Touch Screen Module
Modules & Options Click Go to Pen and Touch (in Tablet PC Input Panel Options) to configure the Pen Options, flicks and handwriting etc. Figure 7 - 16 Pen and Touch Settings When not in use the Tablet PC Input Panel docks at the side of the screen (and may be docked at either side of the screen at any height) with just a small portion visible.
Page 117 Modules & Options Move the pen over the TIC and then tap it to activate it. The input panel allows you to input text without the use of a keyboard. You can use the writing pad (write continuously), character pad (write one character at a time) or touch keyboard to input text.
Page 118: Tv Tuner Module
Modules & Options TV Tuner Module  The optional TV Tuner allows you to watch TV, play music CDs, TV Antenna video conference and capture still images and video on your PC. The TV antenna sup- plied with any TV Tuner If your purchase configuration includes the optional Digital TV module is intended for Tuner module, you will be supplied with a remote control unit and...
Page 119 Modules & Options Windows Media Center  1. This TV Tuner module is fully supported by Windows Media Center in Windows 7 ( not included in Starter or Home Basic versions ). TV Tuner Module 2. Run Windows Media Center directly from the Start menu (Start > Pro- Support grams >...
Page 120: Tv Recording And Power Plans
Modules & Options TV Recording and Power Plans If you intend to use the optional TV Tuner to record live TV, then go to the Power Options control panel and create a power plan (see “Power Plans” on page 3 - to prevent the power saving options from adjusting the computer’s performance lev- Remote Control Unit The remote control unit allows you to remotely start and send the system into a pow-...
Page 121: Troubleshooting
Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Page 122: Basic Hints And Tips
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.
Page 123: Backup And General Maintenance
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.
Page 124: Viruses
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.
Page 125: Upgrading And Adding New Hardware/Software
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
Page 126 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...
Page 127: Problems & Possible Solutions
Troubleshooting Problems & Possible Solutions Problem Possible Cause - Solution The computer feels too Make sure the computer is properly ventilated and the Vent/Fan intakes are not blocked. If this hot. doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
Page 128 Troubleshooting Problem Possible Cause - Solution The compact disc tray The compact disc is not correctly placed in the tray. Gently try to remove the disc using the eject will not open when there hole (see “Loading Discs” on page 2 - is a disc in the tray.
Page 129 Troubleshooting Problem Possible Cause - Solution Wireless The WLAN module is turned off in the Windows Mobility Center. Make sure that Wireless is ON cannot connect to an in the Mobility Center to ensure proper function key behavior (see “Windows Mobility Center” access point.
Page 130: Bluetooth Connection Problems
Troubleshooting Bluetooth Connection Problems If you are experiencing problems connecting to some Bluetooth devices (in particular certain mobile phones and headsets) it maybe necessary to download and install the Windows Mobile Device Center software (for Win- dows Vista and Windows 7). Go to the Microsoft website and search for the Microsoft Windows Device Center Driver for Windows Vista (64-bit or 32-bit) and Windows 7 (64-bit or 32-bit), and then download the driver.
Page 131 Troubleshooting Right-click Bluetooth Peripheral Device and click on Update Driver Software. Click Browse my computer for driver software. Click Let Me pick from a list of device drivers on my computer. Figure 8 - 2 - Browse my computer.../Let me pick from... Select Bluetooth Radios from the list.
Page 132 Troubleshooting 10. A list of drivers will appear with Manufacturer on one side and Model in the other. 11. Choose Microsoft Corporation (make sure you choose the full name Microsoft Corporation and do not choose Microsoft - Note that you must have installed the Microsoft Windows Device Center Driver for Microsoft Corporation to appear in the list).
Page 133 Troubleshooting 15. The Device Manager should now display the Windows Mobile-based device support under Bluetooth Radios. 16. You will need to repeat the process for any other Bluetooth Peripheral Devices listed under Other Devices. Figure 8 - 5 - Device Manager - Bluetooth Radio Bluetooth Connection Problems 8 - 13...
Page 134: Wake On Lan Setup
Troubleshooting Wake On LAN Setup Wake On LAN is an Ethernet computer networking standard that allows a computer to be turned on or woken up by a network message. If you need to have your computer Wake On LAN you will need to enable Computer Management settings as follows.
Page 135 Troubleshooting Click Advanced (tab). Scroll down to the bottom of the Property menu and click to select each of the values listed below.  Property Item Settings for Wake On LAN Set each of the following Property items to En- abled.
Page 136 Troubleshooting 8 - 16...
Page 137: Interface (Ports & Jacks)
Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...
Page 138: Computer Ports And Jacks
Interface (Ports & Jacks) Computer Ports and Jacks Item Description Card Reader Port The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device. COM/Serial Ports The COM/serial is a communication interface for data transfer, through which information transfers in or out one bit at a time.
Page 139: Hdmi-In Port
Interface (Ports & Jacks) Item Description HDMI-In Port The HDMI-In (High-Definition Multimedia Interface) port allows you to display external sources such as Blu-ray players, DVDs, set top boxes and games consoles etc. on your computer screen as long as the computer’s AD/DC adapter is plugged in to a power source (see “HDMI-In Port”...
Page 140: S/Pdif-Out Jack
Interface (Ports & Jacks) Item Description S/PDIF-Out Jack This S/PDIF (Sony/Philips Digital Interface Format) Out Jack allows you to connect your DVD- capable PC to a Dolby AC-3 compatible receiver for “5.1” or ‘dts’ surround sound. USB 2.0/1.1 Ports These USB (Universal Serial Bus) 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high-speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc.
Page 141: Intel Video Driver Controls
Intel Video Driver Controls Appendix B: Intel Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on  page 1 - DVMT Notes Intel Video Driver Installation DVMT is not local video Make sure you install all the drivers in the order indicated in Table 4 - 1, on page 4 - memory.
Page 142: Intel® Graphics & Media Control Panel
Intel Video Driver Controls Intel Graphics & Media Control Panel ®  Advanced video configuration options are provided by the Intel Graphics and ® HDMI-In Port Media Control Panel. To access the control panel: This computer features Click Advanced settings in the Screen Resolution control panel in Windows. an HDMI (High-Defini- Click the Intel(R)...
Page 143 Intel Video Driver Controls You may make changes to any of the graphics properties by clicking the appropriate  menu tab on the left of the menu and adjusting the settings on the right. Options & Support Click Options & Sup- port and select an item from the sub-menu to bring up the help and...
Page 144: Attaching Other Displays
Intel Video Driver Controls Attaching Other Displays  If you prefer to use a monitor or flat panel display, connect it to the external monitor Multiple Display port. At least one other dis- To Clone Displays: play must be attached in Attach your display to the external monitor port and turn it on.
Page 145 Intel Video Driver Controls To Enable Extended Desktop:  Attach your display to the external monitor port and turn it on. Go to the Intel(R) G&M control panel and click Display > Multiple Displays. Display Settings Click Operating Mode and select Extended Desktop from the menu. Extended Desktop Click Apply, and OK to confirm the settings change.
Page 146: Configuring An External Display In Windows 7
Intel Video Driver Controls Configuring an External Display in Windows 7 You can also use the Screen Resolution control panel in Windows 7 to configure an external display. Attach your display to the external monitor port and turn it on. Go to the Screen resolution control panel (see “Video Features - Win 7”...
Page 147 Intel Video Driver Controls You can configure the displays from the Multiple Displays menu. Figure B - 6 Screen Resolution Multiple Display Options (Win 7) • Duplicate these displays - Shows an exact copy of the main display desktop on the other display(s).
Page 148 Intel Video Driver Controls Using the Windows Logo Key + P Key Combination to Switch Displays You can also use the + P key combination to quickly change display configura- tion and modes (this is particularly useful when attaching a projector) in Windows 7. Attach your display to the external monitor port and turn it on.
Page 149: Specifications
Specifications Appendix C: Specifications  Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed or updated due to the manufacturer's release schedule. Check with your service center for details.
Page 150: Processor
Specifications Processor Processor Processor Intel® Core i7 Mobile Processor: Intel® Core i5 Mobile Processor: Intel® Celeron® Processor: =============================== =============================== P4500 (1.86GHz) i7-640M (2.80GHz) i5-450M (2.40GHz) 32nm (32 Nanometer) Process Technology, 2MB L3 Cache & FSB 32nm (32 Nanometer) Process 32nm (32 Nanometer) Process 1066MHz - TDP 35W Technology, 4MB L3 Cache &...
Page 151: Memory
Specifications Memory Storage Interface Dual Channel DDRIII (DDR3) Up to Two Changeable 2.5" 9.5 mm (h) Four USB 2.0 Ports SATA (Serial) Hard Disk Drives One USB 3.0 Port Two 204 Pin SO-DIMM Sockets One eSATA Port Supporting DDRIII (DDR3) 1066MHz/ One 12.7 mm Super Multi/Blu-ray Combo Two (Serial) COM Ports 1333MHz Memory Modules...
Page 152: Card Reader
Specifications Card Reader Communication Power Embedded Multi-In-1 Card Reader Built-In 10/100/100 Mb Base-TX Ethernet Full Range AC/DC Adapter – AC in 100 - 240V, 50 - 60Hz DC Output 19V, 4.74A - MMC / RSMMC (90 Watts) - SD / Mini SD / SDHC / 3rd Party 802.11b/g/n Wireless LAN Half SDXC Compatible Mini-Card Module with PCIe &...
Page 153: Physical Dimensions & Weight
Specifications Physical Dimensions & Weight 450mm (w) * 312mm (d) * 66.5mm (h) 11kg with ODD Specifications C - 5...
Page 154 Specifications C - 6 Specifications...

EUROCOM Multimedia PC User Manual

Quick Start Guide

Features & Components

Drivers & Utilities

BIOS Utilities

Upgrading the Computer

Modules & Options

Troubleshooting

Interface (Ports & Jacks)

Intel Video Driver Controls

Specifications

Power Management

Quick Links

Need help?

Questions and answers

Related Manuals for EUROCOM Multimedia PC

Summary of Contents for EUROCOM Multimedia PC

Table of Contents
