  • Page 1 V12.1.00...
  • Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.

  • Page 4: Eup-Standby And Off Mode Power Consumption Statement

    Preface R&TTE Directive This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Direc- tive 1999/5/EC. This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Lux- embourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland, United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slov- enia.
  • Page 5 Preface CE Marking This device has been tested to and conforms to the regulatory requirements of the European Union and has at- tained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies to products regulated by certain European health, safety and environmental protection legislation.

  • Page 6: Fcc Statement

    Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 7: Fcc Rf Radiation Exposure Statement

    Preface FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.

  • Page 8: Important Safety Instructions

    Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.

  • Page 9: Instructions For Care And Operation

    Preface Instructions for Care and Operation The computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Keep it dry, and don’t overheat it.

  • Page 10: Power Safety

    Preface Power Safety The computer has specific power requirements: •When you want to unplug the power cord, be sure to disconnect it by the plug head, not by  its wire. •Make sure the socket and any extension cord(s) you use can support the total current load Power Safety of all the connected devices.

  • Page 11: Polymer Battery Precautions

    Preface Polymer Battery Precautions Note the following information which is specific to polymer batteries only, and where applicable, this overrides the general battery precaution information overleaf. • Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mecha- nism and is not a cause for concern.

  • Page 12: Battery Precautions

    Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.

  • Page 13: Cleaning

    Preface Cleaning Do not apply cleaner directly to the computer, use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.

  • Page 14: Ergonomics

    Preface Ergonomics We designed your Multimedia PC system to be functional as well as attractive. To get most out of it, here are some suggestions on how to position and use the computer: • The top third of the LCD (screen) should be at eye-level or slightly below. •...
  • Page 15 Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...

  • Page 16: Wall Mounting Information

    Preface Wall Mounting Information The computer may be mounted on a wall for display. The system meets VESA MIS-D Standard (100mm * 100mm) for wall mounting. However if you intend to wall mount the system please contact your service center for information in order to avoid personal injury, or damage to the computer.

  • Page 17: Table Of Contents

    Preface Contents Notice ................................I EuP-Standby and Off Mode Power Consumption Statement: ..............II FCC Statement ............................IV FCC RF Radiation Exposure Statement: ..................... V Instructions for Care and Operation ......................VII Power Safety ............................VIII Polymer Battery Precautions ........................IX Battery Precautions ............................X Cleaning ..............................XI Servicing ..............................XI Ergonomics ...............................
  • Page 18 Preface Tilting the LCD Screen ..........................1-6 Buttons & LED Indicators .........................1-8 On Screen Display Indicators/Buttons .......................1-9 System Map: Left View ...........................1-10 HDMI-In Port ............................1-11 Mode Toggle ............................1-11 System Map: Right View .........................1-13 System Map: Rear View ..........................1-14 Optional Keyboard & Mouse Kit ......................1-15 Wireless Keyboard &...
  • Page 19 Preface ExpressCard Slot ............................2-7 Inserting and Removing ExpressCards ......................2-7 Audio Features ............................2-8 Setup for Audio Recording ........................2-9 Power Management Overview ..............................3-1 The Power Sources ............................3-2 AC/DC Adapter ............................3-2 Battery ................................3-2 Turning On the Computer ..........................3-3 Power Plans ...............................3-4 Power-Saving States ..........................3-6 Sleep ................................3-6 Hibernate ..............................3-7 Shut down ..............................3-7...
  • Page 20 Preface New Battery .............................3-13 Recharging the Battery with the AC/DC Adapter ...................3-13 Proper handling of the Battery Pack ......................3-14 Battery FAQ .............................3-15 Drivers & Utilities What to Install ............................4-1 Driver Installation ............................4-2 Updating/Reinstalling Individual Drivers ....................4-4 User Account Control ..........................4-5 Windows Security Message ........................4-5 New Hardware Found ..........................4-5 Driver Installation Procedure ........................4-6...
  • Page 21 Preface Optional Drivers ............................4-9 BIOS Utilities Overview ..............................5-1 The Setup Utility ............................5-2 Failing the POST ............................5-3 Fatal Errors ..............................5-3 Non-Fatal Errors ............................5-3 Setup Screens .............................5-4 Main Menu ..............................5-5 System Time & Date (Main Menu) ......................5-5 SATA Port # (Main Menu) ........................5-6 System/Extended Memory: (Main Menu) ....................5-6 MB Series / BIOS Revision / KBC/EC firmware Revision ..............5-6 Advanced Menu ............................5-7...
  • Page 22 Preface Super IO Configuration (Advanced Menu) ....................5-9 Security Menu ............................5-10 Password on boot (Security Menu) ......................5-10 Set Supervisor Password (Security Menu) ....................5-11 Set User Password (Security Menu) ......................5-11 Interface Items (Security Menu) ......................5-11 Secure Boot (Advanced Menu) .......................5-12 Configuration (Security Menu) ........................5-12 Boot Menu ...............................5-13 Fast Boot / UEFI Boot (Boot Menu) .......................5-14 Boot Option Priorities (Boot Menu) ......................5-14...
  • Page 23 Preface Removing the 3.5" (88.9mm) HDD ......................6-10 Replacing the Brackets & Screws in the 3.5" (88.9mm) HDD ...............6-12 Removing the 2.5" (63.5mm) HDD or SSD ....................6-14 Upgrading the Optical (CD/DVD) Device Drive ..................6-17 Upgrading the System Memory (RAM) ....................6-18 Upgrading the Processor ..........................6-21 Modules &...
  • Page 24 Preface Intel® Wireless Music Driver Installation ....................7-32 Intel® WiDi Application Configuration ....................7-33 Bluetooth & WLAN Combo Module ......................7-36 3rd Party Bluetooth (V4.0) Combo Driver Installation ................7-37 Intel Bluetooth Combo Driver Installation ....................7-38 Standard Bluetooth Configuration in Windows 7 ...................7-39 Trusted Platform (Security) Module ......................7-43 Enabling &...
  • Page 25 Preface Computer Ports and Jacks .........................A-2 Card Reader Port ............................A-2 DC-In Jack ..............................A-2 HDMI-In Port ............................A-2 HDMI-Out Port ............................A-2 Headphone-Out Jack ..........................A-2 Microphone-In Jack ..........................A-3 PS/2 Type Keyboard & Mouse Ports ......................A-3 RJ-45 LAN Jack ............................A-3 RS-232 COM/Serial Ports ........................A-3 Security Lock Slot ............................A-4 USB 2.0/1.1 Ports .............................A-4 USB 3.0 Port .............................A-4...
  • Page 26 Preface HDMI Audio Configuration ........................B-10 Processor ..............................C-2 Core Logic ..............................C-2 Display ..............................C-2 Memory ..............................C-2 Video Adapter ............................C-3 BIOS .................................C-3 Storage ..............................C-3 Audio ................................C-3 Keyboard & Pointing Device ........................C-3 Interface ..............................C-3 Card Reader ..............................C-3 Slots ................................C-3 Communication ............................C-3 Power Management ..........................C-4 Power ................................C-4 Security ..............................C-4 Operating System ............................C-4...

  • Page 27: Quick Start Guide Overview

    Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...

  • Page 28: Advanced Users

    Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...

  • Page 29: Not Included

    Quick Start Guide Not Included Operating Systems (e.g. Windows 7) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals.  Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers listed in “Drivers &...

  • Page 30: System Startup

    Quick Start Guide System Startup Remove all packing materials, CDs/DVDs and floppy disks etc. Securely attach any peripherals you want to use with the computer to their ports (e.g keyboard and mouse etc.) Attach the AC/DC adapter to the DC-In jack at the rear of the LCD, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.

  • Page 31: System Map: Front View

    Quick Start Guide System Map: Front View Optional Built-In PC Camera PC Camera LED Built-In Microphone Power Button Function Buttons Power & System Activity LED Indicators Speakers Figure 1 - 2 - Front View System Map: Front View 1 - 5...

  • Page 32: Tilting The Lcd Screen

    Quick Start Guide Tilting the LCD Screen It is possible to tilt the LCD screen in order to get the best possible viewing angle of the screen without glare etc. Place one hand at the top of the computer , and use the other to open the stand to an angle of around 15 degrees from the vertical position (the stand will allow you to adjust to the appropriate angle if you pull it out and let it spring back).
  • Page 33 Quick Start Guide Apply pressure with one hand at the top (at point ) of the computer (while holding on to the side with the other hand) to carefully push the LCD screen down in order to tilt it to the appropriate viewing angle (up to 50 degrees from the vertical position).

  • Page 34: Buttons & Led Indicators

    Quick Start Guide Buttons & LED Indicators The LED indicators on the computer display helpful information about the current status of the computer. The buttons located under the front panel icons allow you to make screen and input adjustments. Icon Color Description Orange...

  • Page 35: On Screen Display Indicators/Buttons

    Quick Start Guide On Screen Display Indicators/Buttons Press the function menu button for about two seconds (see Table 1 - 1, on page 1 - 8) to bring up the On Screen Display. The OSD provides visual indicators for brightness, volume, camera power toggle and WLAN/ Bluetooth power toggle (the camera, WLAN and Bluetooth power indicators will only display if the modules are included in your purchase configuration) when the Hotkey AP is installed (see page OSD Icon...

  • Page 36: System Map: Left View

    Quick Start Guide System Map: Left View Figure 1 - 6 Left View  Stand Multi-in-1 Card HDMI-In Port Reader ExpressCard Slot Note that the HDMI-In Port supports video (see page and audio signals from attached HDMI 2 * USB 3.0 Ports devices.

  • Page 37: Hdmi-In Port

    Quick Start Guide HDMI-In Port This computer features an HDMI (High-Definition Multimedia Interface) input port that allows you to display external sources such as Blu-ray players, DVDs, set top boxes and games consoles etc. on your computer screen. The computer itself does not need to be powered on to display video and audio from external HDMI input sources.
  • Page 38 Quick Start Guide The following table indicates the functions when an HDMI cable is plugged in to the HDMI-In port. Computer Power Mode Toggle Button Mode Toggle Button HDMI Icon Status (Press & Hold) (Quick Press) The computer is Indicates battery charge status Toggles between computer powered on (using the Toggles the display on/off...

  • Page 39: System Map: Right View

    Quick Start Guide System Map: Right View Figure 1 - 7 - Right View  Optical Device Drive Bay (for CD/DVD Device - see Changing DVD Regional Codes page 2 - 3 Go to the Control Panel and double-click Headphone-Out Jack Device Manager (Hardware and Sound), Microphone-In Jack then click the + next to DVD/CD-ROM...

  • Page 40: System Map: Rear View

    Quick Start Guide System Map: Rear View Figure 1 - 8 Rear View  1. Rear Component USB Port for Cover Wireless 2. Stand Transceiver 3. Vent/Fan Intake 4. Carrying Handle Note that the USB Area port for the wireless 5.

  • Page 41: Optional Keyboard & Mouse Kit

    Quick Start Guide Optional Keyboard & Mouse Kit There is an optional RF wireless USB keyboard and mouse kit available for this computer series. A USB port located at the bottom of the rear cover (see “System Map: Rear View” on page 1 - 14) is designed to house the transceiver for the USB wireless keyboard &...

  • Page 42: Wireless Keyboard & Mouse Usb Transceiver

    Quick Start Guide Wireless Keyboard & Mouse USB Transceiver  If your purchase includes the optional wireless keyboard & mouse kit you can use USB Port for the USB port located at the bottom left of the rear cover to house the USB transceiver Wireless (do not use this port for any other device, see sidebar).

  • Page 43: Windows 7 Start Menu & Control Panel

    Quick Start Guide Windows 7 Start Menu & Control Panel Most of the control panels, utilities and programs within Windows 7 (and most other Windows versions) are ac- cessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.

  • Page 44: Video Features

    Quick Start Guide Video Features You can configure display options from the Display (Control Panel) and Screen Resolution in Windows. For more detailed video information see Chapter B“Intel Video Driver Controls” from page B - To access Display (Control Panel) and Screen Resolution in Windows: Click Start and click Control Panel.
  • Page 45 Quick Start Guide To access the Intel(R) Graphics Media Accelerator Driver for mobile control panel: Click Advanced settings (Figure 1 - 12 on page 1 - 18) in the Screen Resolution control panel in Win- dows. Click the Intel(R)... tab and click Graphics Properties (button) (Figure 1 - 13 on page 1 - 19) .

  • Page 46: Power Options

    Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 17) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, display and sleep mode from the left menu. Note that the power saver plan may have an affect on computer performance.

  • Page 47: Features & Components Overview

    Features & Components Chapter 2: Features & Components Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical (CD/DVD) Device • Multi-in-1 Card Reader • ExpressCard Slot •...

  • Page 48: Hard Disk Drive

    Features & Components Hard Disk Drive  The hard disk drive is used to store your data in the computer. The hard disk can be Power Safety taken out to accommodate other 2.5" or 3.5" (pictured below) serial (SATA) hard disk drives with a height of 9.5 mm.

  • Page 49: Optical (Cd/Dvd) Device

    Features & Components Optical (CD/DVD) Device  There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the module you purchased (see “Storage” on page C - 3). The Adjustment optical device is usually labeled “Drive D:”...

  • Page 50: Handling Cds Or Dvds

    Features & Components Handling CDs or DVDs  Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed. If you need to manually eject a CD (e.g.

  • Page 51: Dvd Regional Codes

    Features & Components DVD Regional Codes  To change the DVD regional codes: DVD Region Note Go to the Control Panel Double-click Device Manager (Hardware and Sound), then click the + next to DVD region detection is DVD/CD-ROM drives. device dependent, not Double-click on the DVD-ROM device to bring up the Properties dialog box, and OS-dependent.

  • Page 52: Multi-In-1 Card Reader

    Features & Components Multi-in-1 Card Reader  The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).

  • Page 53: Expresscard Slot

    Features & Components ExpressCard Slot  The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/ ExpressCard Slot 34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC Cover Cards). Make sure you keep the ExpressCard/54 is used for applications which re- cover in the Express- quire a larger interface slot, e.g.

  • Page 54: Audio Features

    Features & Components Audio Features  You can configure the audio options on your computer from the Sound control Volume Adjustment panel in Windows, or from the Realtek HD Audio Manager icon in the notifi- The sound volume level cation area/control panel (right-click the taskbar notification area icon to bring up is set using the volume an audio menu).

  • Page 55: Setup For Audio Recording

    Features & Components Setup for Audio Recording To record audio sources on your computer at optimum quality follow the instruc- tions below: Click Start, and click Control Panel (or point to Settings and click Control Panel) and make sure you are in Classic View. Click Realtek HD Audio Manager (or right-click the taskbar icon and select Sound Manager).
  • Page 56 Features & Components 2 - 10...

  • Page 57: Power Management Overview

    Power Management Chapter 3: Power Management  Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.

  • Page 58: The Power Sources

    Power Management The Power Sources The computer can be powered by either the AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components. Attach the AC/DC adapter to the DC-In jack at the rear of the computer.

  • Page 59: Turning On The Computer

    Power Management Turning On the Computer  Now you are ready to begin using your computer. To turn it on simply press the pow- Forced Off er button on the front panel. If the system “hangs”, When the computer is on, you can use the power button as a Stand by/Hibernate/ and the Ctrl + Alt + Del Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and key combination doesn’t...

  • Page 60: Power Plans

    Power Management Power Plans  The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
  • Page 61 Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance (you may need to click Show additional plans to view the High performance plan) for maximum performance when the computer is pow- ered from an AC power source.

  • Page 62: Power-Saving States

    Power Management Power-Saving States You can use power-saving states to stop the computer’s operation and restart where you left off. Win 7 uses the Sleep, Hibernate and Shut Down power-saving states. Sleep In Sleep all of your work, settings and preferences are saved to memory before the system sleeps.

  • Page 63: Hibernate

    Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost.

  • Page 64: Configuring The Power Buttons

    Power Management Configuring the Power Buttons  The power button may be set to send the computer in to either Sleep or Hibernate. Password In Sleep, the LED will blink green. In Hibernate the LED will be orange. If Protection only the display is turned off, the LED will remain green.

  • Page 65: Resuming Operation

    Power Management Resuming Operation You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (see your keyboard documentation). Power Status Icon Color To Resume Table 3 - 1 Power Off Press the Power Button Resuming Press the Power Button...

  • Page 66: Energy Star Power Saving

    Power Management Energy Star Power Saving This system supports Energy Star power management features that place comput- ers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period of inactivity. If you want to enable Energy Star power saving then follow these in- structions: Right-click the taskbar icon (see sidebar).

  • Page 67: Battery Information

    Power Management Battery Information  Follow these simple guidelines to get the best use out of your battery. Low Battery Battery Power Warning Your computer’s battery power is dependent upon many factors, including the pro- When the battery is criti- grams you are running, and peripheral devices attached.

  • Page 68: Conserving Battery Power

    Power Management Conserving Battery Power  • Use a power plan that conserves power (e.g Power saver), however note that this may have an affect on computer performance. Windows Mobility Center • Lower the brightness level of the LCD display. The system will decrease LCD The Windows Mobility brightness slightly to save power when it is not powered by the AC/DC adapter.

  • Page 69: Battery Life

    Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason (e.g.

  • Page 70: Proper Handling Of The Battery Pack

    Power Management Proper handling of the Battery Pack  • DO NOT disassemble the battery pack under any circumstances. • DO NOT expose the battery to fire or high temperatures, it may explode. Caution • DO NOT connect the metal terminals (+, -) to each other. Danger of explosion if battery is incorrectly re- ...

  • Page 71: Battery Faq

    Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
  • Page 72 Power Management Click Change plan settings (after creating it) and click Change plan settings > Change advanced power settings. Figure 3 - 9 Change Plan Settings / Change Advanced Power Settings 3 - 16 Battery Information...
  • Page 73 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 10 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
  • Page 74 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.

  • Page 75: Drivers & Utilities

    Drivers & Utilities Chapter 4: Drivers & Utilities This chapter deals with installing the drivers and utilities essential to the operation or improvement of some of the computer’s subsystems. The system takes advantage of some newer hardware components for which the lat- est versions of most available operating systems haven’t built in drivers and utilities.

  • Page 76: Driver Installation

    Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the disc into the DVD drive and click Install Drivers/Op- Drivers Installer menu below.
  • Page 77 Drivers & Utilities Driver for Windows 7 with Service Pack 1 Page # Driver for Windows 7 with Service Pack 1 Page # Chipset Page 4 - 6 PC Camera Module Page 7 - 2 Video Page 4 - 6 Wireless LAN Module Page 7 - 10 Page 4 - 6...

  • Page 78: Updating/Reinstalling Individual Drivers

    Drivers & Utilities Manual Driver Installation Updating/Reinstalling Individual Drivers Click Browse CD/DVD (button) in the Drivers Install- If you wish to update/reinstall individual drivers it er application and browse to the executable file in the may be necessary to uninstall the original driver.To do appropriate driver folder.

  • Page 79: User Account Control

    Drivers & Utilities User Account Control New Hardware Found If a User Account Control prompt appears as part of If you see the message “New Hardware Found” dur- the driver installation procedure, click Continue or ing the installation procedure (other than when out- Allow, and follow the installation procedure as direct- lined in the driver install procedure), click Cancel to close the window, and follow the installation proce-...

  • Page 80: Driver Installation Procedure

    Drivers & Utilities Driver Installation Procedure Insert the Device Drivers & Utilities + User’s Manual 1. Click 3.Install LAN Driver > Yes. disc into your DVD drive and click Install Drivers 2. Click Install Drivers and Software > Next. (button). 3.

  • Page 81: Usb 3.0

    Drivers & Utilities USB 3.0 Note that after installing the audio driver the system will not return to the Drivers Installer screen. To in- 1. Click 6.Install USB 3.0 Driver > Yes. stall any of the optional drivers listed overleaf, eject 2.

  • Page 82: Windows Experience Index

    Drivers & Utilities Windows Experience Index  After the drivers are installed follow this procedure to ensure an accurate rating from the Windows Experi- Windows 7 Update ence Index: After installing all the drivers make sure you enable Win- dows Update in order to get all the latest security up- 1.

  • Page 83: Optional Drivers

    Drivers & Utilities Optional Drivers See the pages indicated in Table 4 - 1, on page 4 - 3 for the driver installation procedures for any modules in- cluded in your purchase option. Insert the Device Drivers & Utilities + User’s Manual disc and click Option Drivers (button) to access the optional driver menu.
  • Page 84 Drivers & Utilities 4 - 10...

  • Page 85: Bios Utilities Overview

    BIOS Utilities Chapter 5: BIOS Utilities  BIOS Screens Overview Note that BIOS This chapter gives a brief introduction to the computer’s built-in software: screens pictured these pages are intend- If your computer has never been set up, or you are making important changes to the ed for guidance in set- ting up your system’s system (e.g.

  • Page 86: The Setup Utility

    BIOS Utilities The Setup Utility Each time you turn on the computer the system takes a few seconds to conduct a POST, including a quick test of the on-board RAM (memory). As the POST proceeds, the computer will tell you if there is anything wrong. If there is a problem that prevents the system from booting, it will display a system summary and prompt you to run Setup.

  • Page 87: Failing The Post

    BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized distributor/supplier as soon as possible.

  • Page 88: Setup Screens

    BIOS Utilities Setup Screens  The following pages contain additional advice on portions of the Setup. Along the top of the screen is a menu bar with menu headings. When you select a heading, a Setup Menus new screen appears. Scroll through the features listed on each screen to make chang- Setup menus es to Setup.

  • Page 89: Main Menu

    BIOS Utilities Main Menu Figure 5 - 2 Main Menu System Time & Date (Main Menu) The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you can change the date and time settings in your operating system, you will also change these settings.

  • Page 90: Sata Port # (Main Menu)

    BIOS Utilities SATA Port # (Main Menu) Pressing Enter opens the sub-menu to show the configuration of a optical Device/ HDD on the computer’s SATA Ports. System/Extended Memory: (Main Menu) This item contains information on the system memory, and is not user configurable. The system will auto detect the amount of memory installed.

  • Page 91: Advanced Menu

    BIOS Utilities Advanced Menu Figure 5 - 3 Advanced Menu Advanced Chipset Control (Advanced Menu) The sub-menu here allows you to adjust the Bluetooth Power Setting and Total Graphics Memory. Advanced Menu 5 - 7...

  • Page 92: Bluetooth Power Setting (Advanced Menu > Advanced Chipset Control)

    BIOS Utilities Bluetooth Power Setting (Advanced Menu > Advanced Chipset Control)  You can adjust the Bluetooth module power setting to your preference. The default setting (Disabled) will see the Bluetooth module powered off when the system is SATA Mode started up or restarted.

  • Page 93: Boot Logo (Advanced Menu)

    BIOS Utilities Boot Logo (Advanced Menu) Use this menu item to enable/disable the Boot Logo screen at system startup. If you disable the Boot Logo you will not see the F2 Enter Setup or F7 Boot Options prompts on the screen, however you can still press these keys, while the boot screen is displayed, to perform the Enter Setup or Boot Option functions.

  • Page 94: Security Menu

    BIOS Utilities Security Menu  Security Menu The changes you make here affect the access to the Setup utility itself, and also access to your machine as it boots up after you turn it on. These settings do not affect your machine or network passwords which will be set in your...

  • Page 95: Set Supervisor Password (Security Menu)

    BIOS Utilities Set Supervisor Password (Security Menu)  You can set a password for access to the Aptio Setup Utility. This will not affect access to the computer OS (only the Aptio Setup Utility). If you set a supervisor Password Warning password you can then add a user password.

  • Page 96: Secure Boot (Advanced Menu)

    BIOS Utilities Secure Boot (Advanced Menu) Enable/disable Secure Boot from this menu. The Secure Boot specification pro- vides a clean interface between operating systems and platform firmware at boot time. In contrast to BIOS, Secure Boot defines a set of standard boot and runtime services.

  • Page 97: Boot Menu

    BIOS Utilities Boot Menu Figure 5 - 5 Boot Menu  BIOS Screens Note that BIOS screens pictured these pages are intend- ed for guidance in set- ting up your system’s BIOS. BIOS versions are sub- ject to constant change and revision, therefore your computer’s actual When you turn the computer on it will look for an operating system (e.g.

  • Page 98: Fast Boot / Uefi Boot (Boot Menu)

    BIOS Utilities Fast Boot / UEFI Boot (Boot Menu) Fast Boot will enable a boot with the minimal set of devices required (the sub-menus will allow you to choose to skip the EFI VGA driver, USB devices and/or PS/2 de- vices.

  • Page 99: Exit Menu

    BIOS Utilities Exit Menu Figure 5 - 6 Exit Menu Click Save Changes and Reset to save all changes made. Choosing to Discard Changes, or Exit Discarding Changes, will wipe out any changes you have made to the Setup. You can also choose Load Setup Defaults to restore the original Setup defaults and return the Setup to its original state, and erase any previous changes you have made in a previous session.
  • Page 100 BIOS Utilities 5 - 16...

  • Page 101: Upgrading The Computer Overview

    Upgrading The Computer Chapter 6: Upgrading The Computer Overview  This chapter contains information on upgrading the computer. Follow the steps out- Warranty Warning lined to make the desired upgrades. If you have any trouble or problems you can con- tact your service representative for further help.

  • Page 102: When Not To Upgrade

    Upgrading The Computer When Not to Upgrade  These procedures involve opening the system’s case, adding and sometimes replac- ing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake upgrade proce- • Your system is still under warranty or a service contract dures, make sure that •...

  • Page 103: Removing The Battery

    Upgrading The Computer Removing the Battery  If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Before removing the battery disconnect the AC/ DC adapter from the computer first. Please check with your service representative...
  • Page 104 Upgrading The Computer Raise the battery up out of the bay Remove the battery Figure 6 - 2 Battery Removal 6 - 4 Removing the Battery...

  • Page 105: Inserting The Battery

    Upgrading The Computer Inserting the Battery Insert the battery at an angle and slide it firmly into the battery bay until con- nected. Insert the battery bay cover by angling it to fit on the right at first, and then click the left side into place Slide the cover in the direction of the arrow until the top marker of the battery...

  • Page 106: Removing The Rear Component Cover

    Upgrading The Computer Removing the Rear Component Cover Before undertaking any upgrade procedure it is necessary to remove the rear cover component cover to access the components. Turn off the computer and disconnect all cables and peripherals. Carefully place the computer flat with the LCD facing down (make sure you cover the LCD to avoid scratches) so that you may access the rear cover.
  • Page 107 Upgrading The Computer Slide the rear cover up in the direction of the arrow , until the bottom marker of the rear cover icon is aligned with the marker on the side of the computer Figure 6 - 5 Rear Cover Unlock Carefully remove the rear cover , and set it aside.

  • Page 108: Inserting The Rear Cover

    Upgrading The Computer Inserting the Rear Cover Carefully slide the rear cover on to the computer until the marker of the rear cover icon is aligned with the marker on the side of the computer Replace screws & Figure 6 - 7 Inserting the Rear Cover 6 - 8 Removing the Rear Component Cover...

  • Page 109: Upgrading The Hard Disk Drive/Ssd

    Upgrading The Computer Upgrading the Hard Disk Drive/SSD  The hard disk drive can be taken out to accommodate other 2.5"(63.5mm) or HDD System 3.5"(88.9mm) serial (SATA) hard disk drives (see “Storage” on page C - 3), or a Warning Solid State Drive (SSD).

  • Page 110: Removing The 3.5" (88.9Mm) Hdd

    Upgrading The Computer Removing the 3.5" (88.9mm) HDD Remove the battery and rear cover (see pages 6 - 3 & The hard disk is located at point Remove screws from the hard disk bracket. Slide the HDD assembly in the direction of arrow Life the HDD assembly out of the computer.
  • Page 111 Upgrading The Computer Remove screws from the hard disk bracket Remove the left and right side brackets from the HDD.  Screwdriver Types Make sure you use a small manual screw- driver, and not an elec- trical screwdriver, in the course of the up- grade/disassembly pro- cedures outlined here, due to the delicate na-...

  • Page 112: Replacing The Brackets & Screws In The 3.5" (88.9Mm) Hdd

    Upgrading The Computer Replacing the Brackets & Screws in the 3.5" (88.9mm) HDD  Before replacing the brackets and screws for any new HDD, it is important to note that there are left and right brackets for the side of the assembly, and the Screw Types screws need to be inserted in the appropriate order.
  • Page 113 Upgrading The Computer It is important to set the screws (for screwing the HDD assembly to the case) in place in the HDD assembly before sliding the assembly into the  case. Screwdriver Types Once the screws are set in place slide the whole assembly including the screws into place as per Figure 6 - 8 on page 6 - Make sure you use a...

  • Page 114: Removing The 2.5" (63.5Mm) Hdd Or Ssd

    Upgrading The Computer Removing the 2.5" (63.5mm) HDD or SSD  Remove the battery and rear cover (see pages 6 - 3 & The hard disk or solid state drive is located at point Foam Insert for Remove screws & from the bracket (make sure you use a small manual SSDs screwdriver and not an electrical screwdriver to do this, due to the delicate nature...
  • Page 115 Upgrading The Computer Removing the 2.5" (63.5mm) HDD from the Bracket. Remove screws & and separate the bracket from the HDD Reverse the process to install a new hard disk. Figure 6 - 13 2.5" Hard Disk Assembly Brackets & Screws Upgrading the Hard Disk Drive/SSD 6 - 15...
  • Page 116 Upgrading The Computer Removing the SSD from the Bracket. Remove screws & and separate the bracket and sponge assembly from the HDD Separate the bracket from the sponge Make sure you insert the sponge when installing a new HDD. Reverse the process to install a new hard disk. Figure 6 - 14 SSD Assembly Brackets, Screws &...

  • Page 117: Upgrading The Optical (Cd/Dvd) Device Drive

    Upgrading The Computer Upgrading the Optical (CD/DVD) Device Drive Remove the battery and rear cover (see pages 6 - 3 & The ODD is located at point Remove the screw , and use a screwdriver to carefully push out the optical device out in the direction of the arrow at point Reverse the process to install any new optical device.

  • Page 118: Upgrading The System Memory (Ram)

    Upgrading The Computer Upgrading the System Memory (RAM)  The computer has two memory sockets for 204 pin Small Outline Dual In-line (SO- Contact Warning DIMM) DDRIII (DDR3) type memory modules (see “Memory” on page C - 2 Be careful not to touch details of supported module types).
  • Page 119 Upgrading The Computer Gently pull the two release latches on the sides of the memory socket in the direction indicated by the arrows ( & Figure 6 - Figure 6 - 17 RAM Module Release The RAM module will pop-up, and you can remove it. Pull the latches to release the second module if necessary.
  • Page 120 Upgrading The Computer Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory socket (see sidebar note if you are inserting a single module). Figure 6 - 18 RAM Module Removal ...

  • Page 121: Upgrading The Processor

    Upgrading The Computer Upgrading the Processor  If you want to upgrade your computer by replacing the existing processor with a fast- er/new one you will need to contact your customer service representative. We rec- Warranty ommend that you do not do this yourself, since if it is done incorrectly you may The CPU is not a user damage the processor or mainboard.
  • Page 122 Upgrading The Computer 6 - 22...

  • Page 123: Modules & Options Overview

    Modules & Options Chapter 7: Modules & Options Overview This chapter contains information on the following modules, which may come with your computer, depending on the configuration purchased. If you are unsure please contact your service representative. • PC Camera Module •...

  • Page 124: Pc Camera Module

    Modules & Options PC Camera Module  Before installing the driver, make sure the PC Camera is on. Use the On Screen Dis- Latest PC Camera play button ( see page 1 - 9 ) to toggle power to the PC Camera module. When the PC Driver Information Camera application is run the LED indicator to the left of the camera will be illumi- Check the Device Driv-...

  • Page 125: Pc Camera Driver Installation

    Modules & Options PC Camera Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. 2. Make sure the camera module is on before beginning the installation process (use the On Screen Display to toggle power to the camera module - see page 3.

  • Page 126: Pc Camera Audio Setup

    Modules & Options PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
  • Page 127 Modules & Options Figure 7 - 1 Audio Setup for PC Camera Right-click PC Camera Module 7 - 5...
  • Page 128 Modules & Options Camera Application The camera application is a video viewer for general purpose video viewing and test- ing, and for capturing video files to .avi format. Run the camera application from the desktop shortcut (it is recommended that you set the capture file before the capture process - see below).
  • Page 129 Modules & Options Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties).
  • Page 130 Modules & Options Eliminating Screen Flicker  If you find that the video screen in the camera program is flickering, you can try to adjust the setting in the Video Capture Filter options. Latest PC Camera Driver Information Run the camera application from the desktop shortcut. Go to Options and scroll down to select Video Capture Filter..
  • Page 131 Modules & Options Taking Still Pictures  The camera application allows you to take still pictures. Snapshot Folder Run the camera application from the desktop shortcut. Go to Options and select Take Picture. The Snapshot folder’s The picture (in JPEG format) will be placed in the Snapshot folder on the default location is on the desktop.

  • Page 132: Wireless Lan Module

    Modules & Options Wireless LAN Module If you have included an Intel® or 3rd Party module in your purchase option use the On Screen Display button ( see page 1 - 9 ) to toggle power to the Wireless LAN mod- ule, and make sure that the module is on before installing the driver.

  • Page 133: 3Rd Party 802.11B/G/N Driver Installation (For Wlan Module Only)

    Modules & Options 3rd Party 802.11b/g/n Driver Installation (for WLAN Module Only) See over for information on installing the drivers for the 3rd party WLAN & Blue- tooth combo module. If you see the message “Found New Hardware” click Cancel to close the window. 1.

  • Page 134: 3Rd Party 802.11B/G/N Driver Installation (For Combo Modules)

    Modules & Options 3rd Party 802.11b/g/n Driver Installation (for Combo Modules) If you see the message “Found New Hardware” click Cancel to close the window. 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual disc into an attached DVD drive. 2.

  • Page 135: Intel® Wlan Driver Installation

    Modules & Options Intel® WLAN Driver Installation For a standard Intel® WLAN driver installation and configuration choose the Typ- ical Installation below and use the Windows OS for Wireless LAN control (see overleaf). If you want to use Intel® PROSet/Wireless WiFi Connection Utility as your WLAN interface, and/or add Intel®...
  • Page 136 Modules & Options Custom Installation (for Intel® ProSet and/or Intel® MyWiFi Technology): Note that if you wish to install Intel® MyWiFi you will need to install Micro- soft.net Framework 4.0 (or later version) before installing the driver as per the procedure below.
  • Page 137 Modules & Options Figure 7 - 3 Install Intel® MyWiFi Technology & Intel® PROSet/Wireless WiFi Connection Utility Wireless LAN Module 7 - 15...

  • Page 138: Connecting To A Wireless Network In Windows 7

    Modules & Options Connecting to a Wireless Network in Windows 7  Make sure the Wireless LAN module is turned on. Network and Click the taskbar wireless icon , and then double-click an access point to con- Sharing Center nect to or click to Open Network and Sharing Center if you do not see a network you want to connect to in the taskbar menu (a list of options will appear allowing You can also use the Net- setting changes, and creating a new network).
  • Page 139 Modules & Options You may need to enter a security key for any access point to which you are trying to connect. Click to select a network location (e.g. Home, Work or Public). Click “View or change settings in Network and Sharing Center” to access further options for the connection.
  • Page 140 Modules & Options Click the taskbar icon to see any currently connected networks.  To disconnect from the wireless network you can click the taskbar wireless icon click the active connection and then click Disconnect (button). Security Enabled Networks You should try to make sure that any network you are connecting to is a se- cure network.

  • Page 141: Connecting To A Wireless Network Using Intel® Proset Wireless

    Modules & Options Intel Connecting to a Wireless Network Using ® PROSet Wireless (For Intel® WLAN Modules Only) Make sure the Wireless LAN module is on. Access the Intel® WiFi Connection Utility from the Start menu (Start > All Programs > Intel PROSet Wireless > WiFi Connection Utility). Click to select a network from the found list WiFi network access points, or click Refresh to update the list.
  • Page 142 Modules & Options Click Connect to connect to the select WiFi network access point. If the access point is encrypted then you will need to enter the password and click Figure 7 - 8 Intel® PROSet/ Wireless WiFi Connection Utility (Connecting &...

  • Page 143: Intel® My Wifi Configuration

    Modules & Options Intel My WiFi Configuration ®  (For Intel® WLAN Modules Only) Intel® My WiFi Technology (Intel® MWT) uses your WLAN to transform your Intel® My WiFi Help system into a Wi-Fi Personal Area Network, and enables you wirelessly share your To get help on Intel®...
  • Page 144 Modules & Options Intel® My WiFi Configuration You can configure the My WiFi settings as follows. Make sure the Wireless LAN module is on. Access the Intel® WiFi Connection Utility from the Start menu (Start > All Programs > Intel PROSet Wireless > Intel(R) My WiFi Dashboard), or click the icon in the notification area of the taskbar (or right-click and select Open Dashboard).
  • Page 145 Modules & Options Intel® My WiFi Interface Help Wireless ON/OFF Configuration Options & Preferences Figure 7 - 10 Intel® My WiFi Utility - Interface Your Computer Wireless LAN Module 7 - 23...
  • Page 146 Modules & Options Intel® My WiFi Help Click the Help icon in the dashboard to bring up the Help menu and select and item from the Contents menu to obtain the help information. Help Figure 7 - 11 Intel® My WiFi Utility - Help Your 7 - 24 Wireless LAN Module...
  • Page 147 Modules & Options Preferences Click the Options icon and select Preferences to configure the options. Help Figure 7 - 12 Intel® My WiFi Utility - Preferences Your Computer Wireless LAN Module 7 - 25...
  • Page 148 Modules & Options Hotspot You can turn the computer into a hotspot to allow other devices to connect to it (and any locally connected devices), and also (if available) the internet. Click the Hotspot icon to turn the Hotspot on. The Hotspot settings tab shows the SSID and password (you will need to enter this information when accessing the Hotspot from the client computer/device).
  • Page 149 Modules & Options Finding Devices You can find any Nearby Devices by clicking the Refresh button in the main window. Click again at any time to update the list. If a lot of devices are found they will be listed on multiple pages and you can use the left or right buttons to turn the pages.
  • Page 150 Modules & Options Favorite Devices The Favorite Devices tab is where you keep devices to which you connect most of- ten, and this is particularly useful in environments where many devices are listed nearby. A favorite device will display the icon To make any device a favorite just click to select it and select Add Favorite.
  • Page 151 Modules & Options Connect to a Device Click the device you want to connect to, and click the connect icon An invitation will be sent to the target device. The user must then accept the invitation. After the invitation is accepted the connection will be made. Use the Windows Network and Sharing Center to set permissions for viewing and sharing the resources on your computer with another connected computer.

  • Page 152: Windows Mobility Center

    Modules & Options Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. To access the Windows Mobility Center: Click Start, and click Control Panel (or point to Settings and click Control Panel).

  • Page 153: Intel® Wireless Display Application

    Modules & Options Intel Wireless Display Application ®  The Intel ® Wireless Display Application (requires Intel® Centrino WLAN/ Compatible Combo module), in conjunction with a compatible video adapter (purchased sep- Adapters arately), allows you to display the contents of the notebook display on another dis- play (e.g.

  • Page 154: Intel® Widi Application Installation

    Modules & Options Intel WiDi Application Installation ® 1. Insert the Device Drivers & Utilities + User’s Manual disc into an attached DVD drive. 2. Click Option Drivers (button). 3. Click 3.Install WiDi AP > Yes. 4. Click Next. 5. Click the button to accept the license and click Next. 6.

  • Page 155: Intel® Widi Application Configuration

    Modules & Options Intel WiDi Application Configuration ® Click Start > All Programs > Intel Corporation > Intel(R) Wireless Display > Intel(R) Wireless Display, or double click the icon on the desktop. Click I agree to the terms of this license (button). The application will scan for any connected compatible adapters (or you can click the Scan for available adapters button to enable Intel My WiFi Technology).
  • Page 156 Modules & Options Click to select any detected adapters, and click Connect. The system will then prompt you to enter the 4-digit security code which will be displayed on the external TV Screen (or press the connect button on the wireless speaker adapter).
  • Page 157 Modules & Options You will then be prompted to enter a name for the video adapter and click  Continue. Click Finished to complete the setup. Test Audio Adapter To verify a successful au- dio connection (for Intel® Wireless Music), select the “Test your audio connection”...

  • Page 158: Bluetooth & Wlan Combo Module

    Modules & Options Bluetooth & WLAN Combo Module  If your purchase option includes the Combination Wireless LAN & Bluetooth mod- Bluetooth Data ule (either Intel® or 3rd Party) then install the driver as instructed from the appro- Transfer priate page (see below). Note that the transfer of data between the com- ...

  • Page 159: 3Rd Party Bluetooth (V4.0) Combo Driver Installation

    Modules & Options 3rd Party Bluetooth (V4.0) Combo Driver Installation  Note this driver is required for the 3rd Party combo Bluetooth and WLAN module (Bluetooth V4.0) only. High Speed Bluetooth Data Transfer 1. Before installing the driver make sure the Bluetooth module is powered The Combination Wire- on ( use the On Screen Display button to toggle power to the module), then less LAN &...

  • Page 160: Intel Bluetooth Combo Driver Installation

    Modules & Options Intel Bluetooth Combo Driver Installation  Note this driver is required only for the Intel combo Bluetooth and WLAN module only. High Speed Bluetooth Data Transfer 1. Before installing the driver make sure the Bluetooth module is powered The Combination Wire- on (use the On Screen Display button ), then insert the Device Drivers &...

  • Page 161: Standard Bluetooth Configuration In Windows 7

    Modules & Options Standard Bluetooth Configuration in Windows 7  Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Add a Device Make the device discoverable (to do this check your device documentation). Click Start, and click Con- trol Panel and then click De- To Turn the Bluetooth Module On...
  • Page 162 Modules & Options To Add a Bluetooth Device  Access the Bluetooth Devices control panel and click Add a device. Double-click the device you want to pair with the computer. Pairing Options If a device has been pre- viously connected then the pairing option menu will appear when you at- tempt subsequent con-...
  • Page 163 Modules & Options Enter the code into your Bluetooth enabled device and follow any on-screen instructions to complete the pairing.  Figure 7 - 21 Pairing Codes Pairing Code Example The example outlined here shows a connection to a mobile device. Other devices e.g. computers, may have a slightly different connection proce- dure, and may require you to confirm a pairing code is correct on both devices.
  • Page 164 Modules & Options To Change Settings for the Bluetooth Device  Click the taskbar icon and select Show Bluetooth Devices. Right-click on the device you want to change and click Properties to: Bluetooth Help • Change the name of the device (click Bluetooth, type a new name and click OK). •...

  • Page 165: Trusted Platform (Security) Module

    Modules & Options Trusted Platform (Security) Module The TPM security chip allows you to create and manage digital certificates for user and platform authentication. This type of security is usually administered within large enterprises and organizations, and therefore requires implementation by a sys- tem administrator before users can access security features.

  • Page 166: Enabling & Activating Tpm

    Modules & Options Enabling & Activating TPM Restart the computer. Enter the Aptio Setup Utility pressing F2 during the POST/startup. Use the arrow keys to select the Security menu. Select Configuration and press Enter to access the sub-menu. Press Enter to access the Security Device Support menu and select Enable to display the full TPM configuration menu.
  • Page 167 Modules & Options Select Pending operation, press Enter and select the option you require (if you are initializing TPM you should select Enable Take Ownership). You will then need to press F4 to save the changes and restart the computer. Figure 7 - 25 Pending operation (Enable Take...

  • Page 168: Trusted Platform Module (Tpm) Driver Installation

    Modules & Options Trusted Platform Module (TPM) Driver Installation 1. Make sure you have enabled and activated the TPM in the BIOS before installing the driver (if you do not do see the note below). 2. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive.

  • Page 169: Initializing Tpm

    Modules & Options Initializing TPM Run the application from the Infineon Security Platform Solution > Manage Security Platform item in the Start > Programs menu. Click User Settings (tab) and click Yes, or right-click the icon in the notification area of the taskbar, and select Security Platform Initialization (or click the Security Platform State taskbar bubble).
  • Page 170 Modules & Options Choose the Security Platform Features you want to use by clicking the  appropriate tickbox. Enter a Basic User Password (and re-type to confirm it) and click Next. Help Right-click the icon the notification area of the taskbar to bring up the menu to select Help or How to use the Security Platform Fea-...

  • Page 171: Infineon Security Platform Settings Tool

    Modules & Options Infineon Security Platform Settings Tool  The Infineon Security Platform Settings Tool allows you to manage and check the TPM state, manage your password information, and to backup and restore the TPM Menus data. As TPM is usually administered within large enterprises and organizations, Note that not all the your system administrator will need to assist you in managing the information here.
  • Page 172 Modules & Options User Settings This page allows the settings to be configured for the currently logged in Infineon Security Platform user including the ability to change the password, configure se- cure e-mail, file and folder encryption and Enhanced Authentication. You can also import or delete certificates protected by the security platform.
  • Page 173 Modules & Options Backup Here you can configure backup and restore operations. Backup files contain the computer identification and user identification information which is used to match the machine name and user name with the current machine and user during restora- tion.
  • Page 174 Modules & Options Migration The Migration tab is used to help securely transfer keys and certificates from one platform to another. Figure 7 - 32 Infineon Security Platform Settings Tool (Migration) 7 - 52 Trusted Platform (Security) Module...
  • Page 175 Modules & Options Password Reset Use Password Reset to reset basic user passwords when required. Figure 7 - 33 Infineon Security Platform Settings Tool (Password Reset) Trusted Platform (Security) Module 7 - 53...
  • Page 176 Modules & Options BitLocker BitLocker Drive Encryption can be used in conjunction with the TPM to encrypt data on the disk and is done via the Microsoft BitLocker Control Panel Applet. Click Configure and select a drive to be encrypted and then follow the Wizard to begin the encryption process.
  • Page 177 Modules & Options Access the Microsoft BitLocker Drive Encryption control panel applet from the Windows control panel (System and Security). Figure 7 - 35 BitLocker Drive Encryption Trusted Platform (Security) Module 7 - 55...
  • Page 178 Modules & Options Advanced Configure all the Security Platform owner and policy settings from the Advanced tab. The settings that can be changed are for the local computer only. Figure 7 - 36 Infineon Security Platform Settings Tool (Advanced) 7 - 56 Trusted Platform (Security) Module...

  • Page 179: Troubleshooting Overview

    Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.

  • Page 180: Basic Hints And Tips

    Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.

  • Page 181: Backup And General Maintenance

    Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.

  • Page 182: Viruses

    Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.

  • Page 183: Upgrading And Adding New Hardware/Software

    Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
  • Page 184 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...

  • Page 185: Problems & Possible Solutions

    Troubleshooting Problems & Possible Solutions Problem Possible Cause - Solution The Battery LED power Low Battery. Plug in the AC power source. If the computer doesn’t start up immediately, turn it off indicator then on again. blinking orange. You are losing battery The system is using too much power.
  • Page 186 Troubleshooting Problem Possible Cause - Solution Nothing appears The system is in a power saving mode. Press the power button or any configured sleep/resume screen. key combination. The screen controls need to be adjusted. Press the brightness buttons to adjust the settings. If you’re connected to an external monitor, make sure it’s plugged in and turned on.
  • Page 187 Troubleshooting Problem Possible Cause - Solution The Optical Disk Drive The compact disc is not correctly placed in the tray. Gently try to remove the disc using the eject tray will not open when hole (see “Loading Discs” on page 2 - there is a disc in the tray.
  • Page 188 Troubleshooting Problem Possible Cause - Solution Wireless LAN/ The modules are off. Press the function menu button for about two seconds (see Table 1 - 3, Bluetooth/PC Camera on page 1 - 9) to bring up the On Screen Display. Check the appropriate OSD to see if it is on or modules cannot off.

  • Page 189: Bluetooth Connection Problems

    Troubleshooting Bluetooth Connection Problems If you are experiencing problems connecting to some Bluetooth devices (in particular certain mobile phones and headsets) it maybe necessary to download and install the Windows Mobile Device Center software (for Win- dows Vista and Windows 7). Go to the Microsoft website and search for the Microsoft Windows Device Center Driver for Windows Vista (64-bit or 32-bit) and Windows 7 (64-bit or 32-bit), and then download the driver.
  • Page 190 Troubleshooting Right-click Bluetooth Peripheral Device and click on Update Driver Software. Click Browse my computer for driver software. Click Let Me pick from a list of device drivers on my computer. Figure 8 - 2 - Browse my computer.../Let me pick from... Select Bluetooth Radios from the list.
  • Page 191 Troubleshooting 10. A list of drivers will appear with Manufacturer on one side and Model in the other. 11. Choose Microsoft Corporation (make sure you choose the full name Microsoft Corporation and do not choose Microsoft - Note that you must have installed the Microsoft Windows Device Center Driver for Microsoft Corporation to appear in the list).
  • Page 192 Troubleshooting 15. The Device Manager should now display the Windows Mobile-based device support under Bluetooth Radios. 16. You will need to repeat the process for any other Bluetooth Peripheral Devices listed under Other Devices. Figure 8 - 5 - Device Manager - Bluetooth Radio 8 - 14 Bluetooth Connection Problems...

  • Page 193: Interface (Ports & Jacks) Overview

    Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...

  • Page 194: Computer Ports And Jacks

    Interface (Ports & Jacks) Computer Ports and Jacks Item Description Card Reader Port The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device. DC-In Jack Plug the supplied AC/DC adapter into this jack to power your computer.

  • Page 195: Microphone-In Jack

    Interface (Ports & Jacks) Item Description Microphone-In Jack Plug an external microphone in to this jack to record on your computer. PS/2 Type Keyboard & Connect an external PS/2 type mouse or keyboard to these ports. Mouse Ports  Port Warning The computer can only accept one keyboard at a time.

  • Page 196: Security Lock Slot

    Interface (Ports & Jacks) Item Description Security Lock Slot To prevent possible theft, a Kensington-type lock can be attached to this slot. Locks can be purchased at any computer store. USB 2.0/1.1 Ports These USB (Universal Serial Bus) 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high-speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc.

  • Page 197: Intel Video Driver Controls

    Intel Video Driver Controls Appendix B: Intel Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on  page 1 - DVMT Notes Intel Video Driver Installation DVMT is not local video memory. Make sure you install all the drivers in the order indicated in Table 4 - 1, on page 4 - DVMT is not user-con- Video...

  • Page 198: Intel® Graphics & Media Control Panel

    Intel Video Driver Controls Intel Graphics & Media Control Panel ®  Advanced video configuration options are provided by the Intel Graphics and ® HDMI-In Port Media Control Panel. To access the control panel: This computer features Click Advanced settings in the Screen Resolution control panel in Windows. an HDMI (High-Defini- Click the Intel(R)...
  • Page 199 Intel Video Driver Controls You may make changes to any of the graphics properties by clicking the appropriate  menu tab on the left of the menu and adjusting the settings on the right. Options & Support Click Options & Sup- port and select an item from the sub-menu to bring up the help and...

  • Page 200: Display Devices & Options

    Intel Video Driver Controls Display Devices & Options  Besides the built-in LCD you can also use an external monitor/flat panel display/TV Default Display Mode connected to the HDMI-Out port (High-Definition Multimedia Interface) as your display device. The table below outlines the display options. The initial default dis- play mode when first at- ...

  • Page 201: Attaching Other Displays

    Intel Video Driver Controls Attaching Other Displays  If you prefer to use a monitor or flat panel display, connect it to the external monitor Multiple Display port. At least one other dis- To Clone Displays: play must be attached in Attach your display to the HDMI-Out port and turn it on.
  • Page 202 Intel Video Driver Controls To Enable Extended Desktop:  Attach your display to the external monitor port and turn it on. Go to the Intel(R) G&M control panel and click Display > Multiple Displays. Display Settings Click Operating Mode and select Extended Desktop from the menu. Extended Desktop Click Apply, and OK to confirm the settings change.

  • Page 203: Configuring An External Display In Windows 7

    Intel Video Driver Controls Configuring an External Display in Windows 7 You can also use the Screen Resolution control panel in Windows 7 to configure an external display. Attach your display to the external monitor port and turn it on. Go to the Screen resolution control panel (see “Video Features”...
  • Page 204 Intel Video Driver Controls You can configure the displays from the Multiple Displays menu. Figure B - 6 Screen Resolution Multiple Display Options (Win 7) • Duplicate these displays - Shows an exact copy of the main display desktop on the other display(s).
  • Page 205 Intel Video Driver Controls Using the Windows Logo Key + P Key Combination to Switch Displays You can also use the + P key combination to quickly change display configura- tion and modes (this is particularly useful when attaching a projector) in Windows 7. Attach your display to the external monitor port and turn it on.

  • Page 206: Hdmi Audio Configuration

    Intel Video Driver Controls HDMI Audio Configuration  HDMI (High-Definition Multimedia Interface) carries both audio and video signals. Volume Indicator In some cases it will be necessary to go to the Sound control panel and manually configure the HDMI audio output as per the instructions below. Click the taskbar volume indicator when an...
  • Page 207 Intel Video Driver Controls Adjust the HDMI settings from the control panel tabs. Click OK to close the Sound control panel. Figure B - 9 HDMI Device Properties HDMI Audio Configuration B - 11...
  • Page 208 Intel Video Driver Controls HDMI Notes  • Connect a device with HDMI support to the HDMI-Out port BEFORE attempt- ing to play audio/video sources through the device. Other Applications • To play audio sources through your external display’s (TV or LCD) speakers If you are using a third you will need to go to the audio configuration control panel on the display and party...
  • Page 209 Specifications Appendix C: Specifications  Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed or updated due to the manufacturer's release schedule. Check with your distributor/supplier for details.

  • Page 210: Processor

    Specifications Processor Intel® Core™ i5-3470S Processor Core Logic (2.90GHz) Intel® Core™ i7-3770S Processor Intel® H61 Express Chipset 22nm (22 Nanometer) Process (3.10GHz) Technology, DDR3-1600MHz, 6MB L3 Display 22nm (22 Nanometer) Process Cache - TDP 65W Technology, DDR3-1600MHz, 8MB L3 21.5"(54.61cm) FHD (1920 * 1080) 16:9 Intel®...

  • Page 211: Video Adapter

    Specifications Video Adapter Audio Card Reader Intel® Integrated GPU (Intel® HD High Definition Audio Embedded Multi-In-1 Push-Push Card Graphics / Intel® HD Graphics 2500 / Reader Built-In Microphone Intel® HD Graphics 4000): - MMC/ RS MMC 2 Built-In Two 3W Speakers Dynamic Frequency - SD/ Mini SD / SDHC/ SDXC Keyboard &...

  • Page 212: Power Management

    Specifications Intel® Centrino® Wireless-N 2230 2*2 Security Physical Dimensions & Weight (802.11 b/g/n) Half Mini-Card PCIe WLAN + Security (Kensington® Type) Lock Slot 525mm (w) * 49mm (d) * 418mm (h) Bluetooth V4.0+HS Combo Module BIOS Password 7Kg with ODD (Factory Option) Trusted Platform Module 1.2 802.11b/g/n WLAN Half Mini-Card...

This manual is also suitable for:

V12.1.00

Table of Contents
