Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
Page 4: Fcc Statement
Preface FCC Statement (Federal Communications Commission) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interfer- ence in a residential installation.
Page 5: Important Safety Instructions
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Page 6: Instructions For Care And Operation
Preface Instructions for Care and Operation The computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Keep it dry, and don’t overheat it.
Page 7: Power Safety
Preface Power Safety The computer has specific power requirements: • When you want to unplug the power cord, be sure to disconnect it by the plug head, not by its wire. • Make sure the socket and any extension cord(s) you use can support the total current Power Safety load of all the connected devices.
Page 8: Cleaning
Preface Cleaning Do not apply cleaner directly to the computer, use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.
Page 9: Ergonomics
Preface Ergonomics We designed your LCD PC system to be functional as well as attractive. To get most out of it, here are some suggestions on how to position and use the computer: • The top third of the LCD (screen) should be at eye-level or slightly below. •...
Page 10 Preface VIII...
Page 11: Table Of Contents
Preface Contents Notice ................I System Map: Left View ..........1-10 FCC Statement ..............II System Map: Right View ...........1-11 Instructions for Care and Operation ......IV System Map: Rear View ..........1-12 Power Safety ............. V Windows XP Start Menu & Control Panel ....1-13 Cleaning ..............
Page 12 Preface Inserting and Removing PC Cards ......2-13 Updating/Reinstalling Individual Drivers ....3-4 Power Management ...........2-14 Driver Installation ............3-5 Power Schemes ............2-15 Service Pack Installation ..........3-6 System Power Options ..........2-16 New Hardware Found ..........3-6 Hibernate Mode vs. Shutdown .......2-16 Manual Driver Installation ........3-6 Standby Mode vs.
Page 13 Preface System Time & Date (Main Menu) ......4-6 Upgrading the Optical Device (Model B) ....5-10 Legacy Diskette A: (Main Menu) ........4-7 Troubleshooting IDE Channel 0/1 Master (Main Menu) .......4-7 System/Extended Memory (Main Menu) ....4-7 Overview ..............6-1 Advanced Menu ............4-8 Basic Hints and Tips ............6-2 Chipset Information Menu (Advanced Menu) ....4-8 Backup and General Maintenance .......6-3 National 392 SIO Control Sub-Menu ......4-8...
Page 14 Preface Specifications Processor Types ............B-2 Core Logic ..............B-2 LCD ................B-2 Memory ..............B-3 Video Controller ............B-3 BIOS ................B-3 Storage ................ B-3 Audio ................B-3 PC Card Sockets ............B-3 Interface ..............B-4 Communication ............B-4 Power Management ............
Page 15: Quick Start Guide
Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...
Page 16: Advanced Users
Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 3 - “BIOS Utilities” on page 4 - 1 “Upgrading The Computer”...
Page 17: Not Included
Quick Start Guide Not Included Operating Systems (e.g. Windows XP etc.) and applications (e.g. word processing, spreadsheet and database pro- grams) have their own manuals, so please consult the appropriate manuals. System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find this manual refers to the following oper- ating systems: •...
Page 18: System Startup
Quick Start Guide System Startup Remove all packing materials, CDs/DVDs, floppy disks, and any PC Cards. Securely attach any peripherals you want to use with the computer (e.g. keyboard and mouse) to their ports. Attach the AC power cord to the AC-In jack on the right of the computer. Then plug the AC power cord into an outlet.
Page 19: Model Types And Design Differences
Quick Start Guide Model Types and Design Differences There two model types (pictured below) in this LCD PC series. The model types differ in physical appearance (Model A’s optical CD/DVD device bay is located on the left side of the computer; Model B’s is at the front) and their specifications.
Page 20: System Map: Front View
Quick Start Guide System Map: Front View LCD Panel Model B Model A Speakers LED Indicators Power Button Optical (CD/DVD) Device Bay (Model B Only - see page 1 - 10 for Model A) Keyboard Holder (Model B Only) CD/DVD Emergency Eject If you need to manually eject a CD/DVD (e.g.
Page 21: Led Indicators
Quick Start Guide LED Indicators Power Button The LED indicators on the computer display helpful When the computer is on, you can use the power but- information about the current status of the computer. ton as a hot-key button when it is pressed for less than 4 seconds.
Page 22: Optical (Cd/Dvd) Device
Quick Start Guide Optical (CD/DVD) Device Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them There is a bay for a 5.25" optical (CD/DVD) device from being damaged. Please follow the advice below (12.7mm height). The actual device will depend on the to make sure that the data stored on your CDs/DVDs model you purchased (see “Storage”...
Page 23: Dvd Regional Codes
Quick Start Guide DVD Regional Codes DVD region detection is device dependent, not OS-dependent. You can select your module’s region code 5 times. The fifth selection is permanent. This cannot be altered even if you change your operating system or you use the module in another computer.
Page 24: System Map: Left View
Quick Start Guide System Map: Left View Figure 1 - 4 - Left View Floppy Disk Drive Module Vent Overheating Hard Disk Drive Bay Optical (CD/DVD) Device Bay To prevent your computer (Model A Only) from overheating make sure nothing blocks the vent/fan intake while the computer is in use.
Page 25: System Map: Right View
Quick Start Guide System Map: Right View Figure 1 - 5 - Right View LCD Brightness Control Knob 7-in-1 Card Reader Formats Volume Control Knob The card reader allows you to use the most popular 7-in-1 Card Reader digital storage card formats (see page 12): PC Card Slot •...
Page 26: System Map: Rear View
Quick Start Guide System Map: Rear View Figure 1 - 6 - Rear View Carrying Handle Handle Warning Headphone-Out Jack Line-In Jack We strongly recommend using both Microphone-In Jack hands to move the computer (one RJ-45 LAN Jack hand gripping the handle and the RJ-11 Phone Jack other gripping the base) to avoid 2 * USB 2.0 Ports...
Page 27: Windows Xp Start Menu & Control Panel
Quick Start Guide Windows XP Start Menu & Control Panel Most of the control panels, utilities and programs within Windows XP (and most other Windows versions) are accessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 28: Video Features
Quick Start Guide Video Features Your computer has built-in Intel on-board video. You can switch display devices, and configure display options, from the Display Properties control panel in Windows as long as the appropriate video driver is installed (see “Advanced Video Controls” on page 2 - To access Display Properties in Windows: Click Start, point to Settings and click Control Panel (or just click Control Panel).
Page 29 Quick Start Guide Figure 1 - 8 - Display Properties Desktop Intel Display Mode Description Single Mode One of the connected displays is used as the display device Twin Mode This mode will drive multiple displays with the same content and resolutions, color quality etc. Intel(R) Dual Display Clone Mode Both connected displays output the same view and may be configured independently Extended Desktop Mode...
Page 30: Power Management Features
Quick Start Guide Power Management Features The Power Options control panel in Windows (see page 13) allows you to configure power management fea- tures for your computer. You may conserve power through individual components such as the monitor or hard disk (by means of Power Schemes), or you may use either Standby or Hibernate mode to conserve power throughout the system (enable Hibernate support from the control panel as pictured in Figure 1 -...
Page 31: Adding A Printer
Quick Start Guide Adding a Printer The most commonly used peripheral is a printer. The following conventions will help you to add a printer, how- ever it is always best to refer to the printer manual for specific instructions and configuration options. USB Printer Most new printers have a USB interface connection.
Page 32 Quick Start Guide 1 - 18...
Page 33: Advanced Controls
Advanced Controls Chapter 2: Advanced Controls Drivers Overview You are unable to use This chapter covers: most advanced con- trols until the neces- • Advanced Video Controls sary drivers • Audio Features utilities are properly in- • 7-in-1 Card Reader stalled.
Page 34: Advanced Video Controls
Advanced Controls Advanced Video Controls This section is about making adjustments for the LCD display, and switching display DVMT Notes devices. The basic settings for configuring the display are outlined in “Video Fea- tures” on page 1 - The default memory setting is 128MB, and this may be adjusted to Dynamic Video Memory Technology...
Page 35: Intel Graphics Properties
Advanced Controls Intel Graphics Properties More advanced video configuration options are provided by the Intel(R) Graphics Taskbar Icon Media Accelerator Driver for Mobile. You can also access the Open Display Properties (see “Video Features” on page 1 - 14) and click controller properties Advanced.
Page 36 Advanced Controls You may make changes to the devices, color, schemes, Hot Keys etc. by clicking the appropriate menu item or button. Click Information (button) to obtain useful in- formation about the graphics properties of the computer, and see the Support tab in Help Menus Information to get weblinks to the latest information on the Intel Website.
Page 37: Scheme Options
Advanced Controls Scheme Options Use Scheme Options to configure quick settings for applications which require spe- cific resolution and color settings in order to run properly e.g. games, multimedia Application.exe programs. To set the scheme options: You will need to locate Open the Intel(R) GMA Driver for Mobile control panel (see “Intel Graphics the actual application...
Page 38: Attaching Other Displays
Advanced Controls Attaching Other Displays Besides the built-in LCD, you can also use an external monitor/flat panel display as Intel Display Note a display device. The following are the display options: The built-in LCD OR an external monitor/flat panel display connected to the exter- Note that the notebook (i.e.
Page 39: Display Modes
Advanced Controls Display Modes Single Display Only one of your attached displays is used. Twin This mode will drive multiple displays with the same content and resolutions, color quality etc. See “Twin Mode Support” on page 2 - 8 for more information. Extended Desktop This mode allows a desktop to span multiple displays and acts as a large workspace.
Page 40 Advanced Controls To Enable Intel(R) Dual Display Clone Mode Attach your external monitor to the external monitor port, and turn it on. Go to the Intel (R) GMA Driver for Mobile control panel (see “Intel Graphics Twin Mode Support Properties” on page 2 - Click to choose Intel(R) Dual Display Clone or Twin from Display Device (tab).
Page 41 Advanced Controls To Enable Extended Desktop Mode: Attach your external monitor to the external monitor port, and turn it on. Go to the Intel (R) GMA Driver for Mobile control panel (see “Intel Graphics Display Settings Properties” on page 2 - Extended Desktop Click to choose Extended Desktop from Display Device (tab).
Page 42 Advanced Controls To Enable Extended Desktop (Display Properties) Attach your external monitor to the external monitor port, and turn it on. Click Start, point to Settings (or click Control Panel) and click Control Panel (if Display Settings you are in Category View choose Appearance and Themes). Extended Desktop Double-click Display (icon).
Page 43: Audio Features
Advanced Controls Audio Features You can configure the audio options on your computer from the Sounds and Audio Sound Volume Devices Windows control panel (see Figure 1 - 7 on page 1 - 13), or from the Adjustment Realtek HD Audio Manager icon in the taskbar/control panel (this will bring up How high the sound the Realtek Audio Configuration menus).
Page 44: 7-In-1 Card Reader
Advanced Controls 7-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Page 45: Pc Card Slot
Advanced Controls PC Card Slot The computer is equipped with a PCMCIA 3.3V/5V slot for one type II PCMCIA PC Card Slot Cover CardBus PC Card Slot. Make sure you install the PCMCIA/Card Reader driver (see “PCMCIA/Card Reader” on page 3 - Make sure you keep the cover in the PC Card Inserting and Removing PC Cards...
Page 46: Power Management
Advanced Controls Power Management The computer uses the ACPI power management system to conserve power by con- Shutdown trolling individual components of the computer (the monitor and hard disk drive) or the whole system. Note that you should always shut your com- puter down by choos- Using some form of power management greatly increases the life span of the ing the Shut Down/...
Page 47: Power Schemes
Advanced Controls Power Schemes You can set your computer to conserve power through individual components by means of Power Schemes. You can also adjust the settings for each scheme to set Resuming the monitor to turn off after a specified time, and the computer's hard disk motor to Operation turn off if the hard disk drive has not been accessed for a specified period of time (if The system can re-...
Page 48: System Power Options
Advanced Controls System Power Options You can use the system power options to stop the computer’s operation and restart where you left off. This system features Standby and Hibernate sleep mode levels Power Button as Standby or (Hibernate mode will need to be enabled by clicking the option in the Hibernate Hibernate Button tab in the Power Options control panel - Figure 2 - 13 on page 2 -...
Page 49: Standby
Advanced Controls Standby Standby saves the least amount of power, but takes the shortest time to return to full operation. During Standby the hard disk is turned off, and the CPU is made to idle System Resume at its slowest speed. All open applications are retained in memory. When you are not The system can resume using your computer for a certain length of time, which you specify in the operating from Standby mode by:...
Page 50: Configuring The Power Button
Advanced Controls Configuring the Power Button The power button may be set to send the computer in to either Standby or Hiber- nate mode (Figure 2 - 14). In Standby mode, the Power LED will flash orange. In Hibernate mode the Power LED will be off. Figure 2 - 14 Power Options (Advanced - Power...
Page 51: Intel Pro/Wireless Wlan Module
Advanced Controls Intel PRO/Wireless WLAN Module If you have included an Intel PRO/Wireless 3945ABG (802.11a/b/g) PCIe WLAN module in your purchase option, make sure you install the drivers in the order indicated in Table 3 - 1, on page 3 - To get help on the network settings you can view the User Guide from the Intel PROSet / Wireless menu.
Page 52: Intel Wlan Driver Installation
Advanced Controls Intel WLAN Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual CD-ROM into the CD/DVD drive. User Guide 2. Click Optional > Yes. You can view the User 3. Click 1.Install Wireless Lan Driver > Yes. Guides from the Device Drivers &...
Page 53: B/G Wlan Module
Advanced Controls 802.11b/g WLAN Module If your purchase option includes the 802.11b/g Wireless LAN module, follow the procedure below for driver installation instructions. You can then configure the op- tions from the Wireless Configuration Utility by clicking the icon in the Windows control panel, or in the taskbar.
Page 54 Advanced Controls Network Connection Use the Windows Net- work Connections con- trol panel access available wireless net- works (Start > Settings > Network Connections or Start > Connect To > Show all Connections). Figure 2 - 17 Wireless Network Control Panels 2 - 22 802.11b/g WLAN Module...
Page 55: Bluetooth Module
Advanced Controls Bluetooth Module If your purchase option includes the Bluetooth module, follow the procedure below for driver installation instructions. Bluetooth Driver Installation 1. Insert the Device Drivers & Utilities + User’s Manual CD-ROM into the CD/DVD drive. 2. Click Optional > Yes. 3.
Page 56 Advanced Controls User Guide Send To Bluetooth View BlueSoleil Right-Click to select User Guides from the any file and scroll down Help Menu (or press the to Send To... Bluetooth F1 key) in the IVT Cor- Device. poration BlueSoleil - Main Window.
Page 57: Touch Panel Module
Advanced Controls Touch Panel Module If your purchase option includes the Touch Panel module, follow the procedure be- Touch Panel Pointing low for driver installation instructions. Device Do not use any sharp or The Touch Panel is a device for pointing (controlling input positioning) on the com- pointed objects as your puter’s display screen by sensing finger movement, and downward pressure.
Page 58: Calibrating The Touch Panel
Advanced Controls Calibrating the Touch Panel Configure the settings from the TouchSet Utility control panel (Start > Programs/ All Programs > TouchSet Touch Panel), or double-click the desktop icon Help Guide Click the Calibration tab and click the Calibrating Now button. Use the input device to touch the cross at the different positions on screen.
Page 59: Drivers & Utilities
Drivers & Utilities Chapter 3: Drivers & Utilities What to Install This chapter deals with installing the drivers and utili- ties essential to the operation or improvement of some The Device Drivers & Utilities + User’s Manual CD- of the computer’s subsystems. The system takes ad- ROM contains the drivers and utilities necessary for vantage of some newer hardware components for the proper operation of the computer.
Page 60 Drivers & Utilities Navigate (Browse..) to D: You will notice that many of the instructions for driver installation require you to “Navigate (Browse) to D:”. We assume that you will install all drivers and utilities from the built-in CD device and it is assigned to “Drive D:”.
Page 61: Service Packs
Drivers & Utilities Service Packs Check the warnings on the following pages regarding installation of the appropriate Service Pack for your Windows XP Service Pack 2 Windows XP OS. Make sure you have installed the ap- Make sure you install Windows XP Service Pack 2 propriate Service Pack before installing all the drivers.
Page 62: Authorized Driver Message
Drivers & Utilities Authorized Driver Message Updating/Reinstalling Individual Driv- If you receive a message telling you that the driver you are installing is not authorized (Digital Signature Not If you wish to update/reinstall individual drivers it Found), just click Yes or Continue Anyway to ignore may be necessary to uninstall the original driver.To do the message and continue the installation procedure.
Page 63: Driver Installation
Drivers & Utilities Driver Installation Check the driver installation order from Table 3 - 1 on page 3 - 6 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the CD-ROM and click Install WinXP Drivers (button) >...
Page 64: Service Pack Installation
Drivers & Utilities Service Pack Installation WinXP SP2 Driver Page # Make sure you install the appropriate service pack for your operating system before installing any drivers Install the appropriate Service Pack for WinXP Page 3 - 3 (see “Windows XP Service Pack 2” on page 3 - Chipset Page 3 - 7 Video...
Page 65: Chipset
Drivers & Utilities Chipset Audio 1. Click Install WinXP Drivers > Yes. 1. Click Install WinXP Drivers > Yes. 2. Click 1.Install Chipset Driver > Yes. 2. Click 3.Install Audio Driver > Yes. Navigate (Browse..) to Navigate (Browse..) to D:\Drivers\00Chipset\Setup.exe and click D:\Drivers\02Audio\Setup.exe and click OK.
Page 66: Modem
Drivers & Utilities Modem 1. Click Install WinXP Drivers > Yes. 1. Click Install WinXP Drivers > Yes. 2. Click 4.Install Modem Driver > Yes. 2. Click 5.Install LAN Driver > Yes. Navigate (Browse...) to Navigate (Browse...) to D:\Drivers\03Modem\setup.exe and click D:\Drivers\04Lan\setup.exe and click OK.
Page 67: Wireless Lan
Drivers & Utilities Wireless LAN Touch Panel See the installation procedure in “Intel WLAN Driver See the installation procedure in “Touch Panel Driver Installation” on page 2 - 20 “Wireless LAN Installation” on page 2 - (802.11b/g) Driver Installation” on page 2 - Bluetooth See the installation procedure in “Bluetooth Driver...
Page 68 Drivers & Utilities 3 - 10...
Page 69: Bios Utilities
BIOS Utilities Chapter 4: BIOS Utilities BIOS Settings Overview Warning This chapter gives a brief introduction to the computer’s built-in software: Incorrect settings can cause your system to Diagnostics: The POST (Power-On Self Test) malfunction. To correct mistakes, return Setup and restore the Configuration: The PhoenixBIOS Setup Utility Setup Defaults with <F9>.
Page 70: The Power-On Self Test (Post)
BIOS Utilities The Power-On Self Test (POST) Each time you turn on the computer, the system takes a few seconds to conduct a POST Screen POST, including a quick test of the on-board RAM (memory). 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. If 2.CPU type there is a problem that prevents the system from booting, it will display a system 3.Memory status...
Page 71: Failing The Post
BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non-fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or au- thorized service center as soon as possible.
Page 72: The Setup Program
BIOS Utilities The Setup Program The PhoenixBIOS Setup Utility tells the system how to configure itself and man- age basic features and subsystems (e.g. port configuration). Entering Setup To enter the PhoenixBIOS Setup Utility, turn on the computer and press F2 dur- ing the POST.
Page 73: Setup Screens
BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with five (5) menu headings. When you Setup menus select a heading, a new screen appears. Scroll through the features listed on each shown in this section screen to make changes to Setup.
Page 74: Main Menu
BIOS Utilities Main Menu PhoenixBIOS Setup Utility Figure 4 - 2 Main Main Advanced Security Boot Exit Main Menu Item Specific Help System Time: [22:11:05] System Date: [08/31/2006] Legacy Diskette A: [1.44/1.25 MB 3½"] <Tab>, <Shift Tab>, or IDE Channel 0 Master [82348MB SATA1] <Enter>...
Page 75: Legacy Diskette A: (Main Menu)
BIOS Utilities Legacy Diskette A: (Main Menu) This control allows you to enable/reconfigure the internal floppy disk drive. IDE Channel 0/1 Master (Main Menu) Press Enter here to open the sub-menu to show the configuration of hard disks and CD/DVD device(s) on the computer’s IDE Channels. Use the Auto (Type:) setting to have the items configured automatically for you.
Page 76: Advanced Menu
BIOS Utilities Advanced Menu Figure 4 - 3 PhoenixBIOS Setup Utility Advanced Menu Main Advanced Advanced Security Boot Exit Item Specific Help Chipset Information Menu Display Chipset Infomation required National 392 SIO Control Sub-Menu Reset Configuration Data: [No] Legacy USB Support: [Enabled] Boot-time Diagnostic Screen: [Enabled]...
Page 77: Reset Configuration Data: (Advanced Menu)
BIOS Utilities Reset Configuration Data: (Advanced Menu) This item is set to “No” as default. You can change the setting to “Yes” if you have installed a new add-on which has reconfigured the system, resulting in such a serious system conflict that the operating system is unable to boot. Legacy USB Support: (Advanced Menu) Choose “Enabled”...
Page 78: Security Menu
BIOS Utilities Security Menu PhoenixBIOS Setup Utility Security Menu Main Advanced Security Boot Exit changes Item Specific Help make here affect the Supervisor Password Is: Clear access to the Setup utility itself, and also Set Supervisor Password [E E nter] Supervisor Password access to your ma- controls access to the...
Page 79: Password On Boot: (Security Menu)
BIOS Utilities Password on boot: (Security Menu) Specify whether or not a password should be entered to boot the computer. If “En- abled” is selected, only users who enter a correct password can boot the system Password Warning (see the warning in the sidebar). The default setting is “Disabled”. If you set a boot pass- word (Password on boot Note: To clear existing passwords press Enter and type the existing password,...
Page 80: Boot Menu
BIOS Utilities Boot Menu PhoenixBIOS Setup Utility Figure 4 - 5 Main Advanced Security Boot Exit Boot Menu Item Specific Help Boot priority order: Legacy Floppy Drives Keys used to view or USB KEY: configure devices: IDE CD: TSSTcorpCD/DVDW TS-L632D-( IDE HDD: HDS722580VLSA80-(S1) Up and Down arrows...
Page 81: Exit Menu
BIOS Utilities Exit Menu Figure 4 - 6 PhoenixBIOS Setup Utility Exit Menu Main Advanced Security Boot Exit Item Specific Help Exit Saving Changes Exit Discarding Changes Exit System Setup and Load Setup Defaults save your changes to CMOS. Discard Changes Save Changes Help Select Item...
Page 82 BIOS Utilities 4 - 14...
Page 83: Upgrading The Computer
Upgrading The Computer Chapter 5: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps out- Warranty Warning lined to make the desired upgrades. If you have any trouble or problems you can con- tact your service representative for further help. Before you begin you will need: Please check with your service representative •...
Page 84: When Not To Upgrade
Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replac- ing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake any upgrade proce- • Your system is still under warranty or a service contract dures, make sure that you have turned off the •...
Page 85: Upgrading The Hard Disk Drive
Upgrading The Computer Upgrading the Hard Disk Drive The hard disk drive is used to store your data internally in the computer. It is mount- HDD System ed at the left side and can be taken out to accommodate other 3.5" IDE hard disk Warning drives of the same or higher capacity.
Page 86 Upgrading The Computer Pull the HDD assembly out of the bay and disconnect cables & Figure 5 - 2 Hard Disk Drive Assembly Removal Remove screws , and lift the hard disk out of the case. Figure 5 - 3 Hard Disk Drive Assembly Screws Insert the new hard disk, and reverse the removal procedures to install the new...
Page 87: Upgrading The System Memory (Ram)
Upgrading The Computer Upgrading the System Memory (RAM) The computer can accommodate up to 2GB of memory in two DIMM sockets. See Warranty Warning “Memory” on page B - 3 for more details. Note that the procedure to Unplug the power cord and disconnect all peripheral cables (including the phone upgrade or replace the line) from the computer.
Page 88 Upgrading The Computer Carefully remove the rear cover and set it aside. The memory sockets will now be visible at point on the mainboard. Figure 5 - 5 Rear Case Removal Model A Model B Model A Carefully push the two latches ( ) toward the sides of the socket to release the module.
Page 89 Upgrading The Computer 10. Insert the new module. The module will only fit one way as defined by the pin alignment. 11. Make sure the module is seated as far into the slot as it will go (DO NOT FORCE IT).
Page 90: Upgrading The Optical Device (Model A)
Upgrading The Computer Upgrading the Optical Device (Model A) Unplug the power cord and disconnect all peripheral cables (including the phone line) from the computer. Turn off the computer. Place the computer with its LCD display facing down on a clean, dry, level surface. Remove screws from the rear of the computer.
Page 91 Upgrading The Computer Carefully remove the rear cover and set it aside. The optical device will now be visible at point on the mainboard. Figure 5 - 9 Model A Rear Case Removal Remove screws , and disconnect cable , from the optical device. Remove the optical device, and remove the screws in order to separate the optical device from the bracket.
Page 92: Upgrading The Optical Device (Model B)
Upgrading The Computer Upgrading the Optical Device (Model B) Unplug the power cord and disconnect all peripheral cables (including the phone line) from the computer. Locate the optical device eject switch and remove screw Push the optical device eject switch to slide the optical device assembly out of the bay.
Page 93: Troubleshooting
Troubleshooting Chapter 6: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Page 94: Basic Hints And Tips
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.
Page 95: Backup And General Maintenance
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.
Page 96: Viruses
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.
Page 97: Upgrading And Adding New Hardware/Software
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
Page 98 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...
Page 99: Problems & Possible Solutions
Troubleshooting Problems & Possible Solutions Problem Possible Cause - Solution Nothing appears The screen saver is activated. Press any key or move the mouse to return to your display. screen. The system is in a power saving mode. Press the power button for less than 4 seconds. If the computer does not turn on again then it was most likely shut down, or has no power source.
Page 100 Troubleshooting Problem Possible Cause - Solution The CD/DVD cannot be The CD/DVD is dirty. Clean it with a CD-ROM cleaner kit. read. The CD/DVD disc tray The CD/DVD disc is not correctly placed in the tray. Gently try to remove the disc using the eject will not open when there hole (see “Loading Discs”...
Page 101: Interface (Ports & Jacks)
Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc. Item Description External Monitor Port Connect an external display to this port to allow dual video or simultaneous display on the...
Page 102: Ieee 1394A Port
Interface (Ports & Jacks) Item Description IEEE 1394a Port This port will allow high speed connection to various peripheral devices, e.g. external disk drives and digital cameras (see note below). IEEE 1394 The IEEE 1394a port only supports SELF POWERED IEEE 1394 devices. Printer/Parallel Port This parallel printer port supports ECP (Extended Capabilities Port) and EPP (Enhanced Parallel Port) mode.
Page 103: Serial Port
Interface (Ports & Jacks) Item Description Serial Port Connect a serial type mouse to this port. USB 2.0/1.1 Ports These USB 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high-speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc.
Page 104 Interface (Ports & Jacks) A - 4...
Page 105: Specifications
Specifications Appendix B: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly proces- sor types/speeds and CD/DVD device types) may be changed or updated due to the manufacturer's release sched- ule.
Page 106: Processor Types
Specifications Feature Specification Processor Types Intel® Core™ 2 Duo Processor 65nm (65 Nanometer) Process Technology (478-pin) Micro-FC-PGA Package 4MB On-die L2 Cache & 667MHz FSB T7200/ T7400/ T7600 2.0/ 2.16/ 2.33 GHz Intel® Core™ 2 Duo Processor 65nm (65 Nanometer) Process Technology (478-pin) Micro-FC-PGA Package 2MB On-die L2 Cache &...
Page 107: Memory
Specifications Feature Specification Security Security (Kensington® Type) Lock Slot BIOS Password Memory Two 200 Pin SO-DIMM Sockets Supporting DDRII (DDR2) 533/667 MHz 64-bit Wide DDRII (DDR2) Data Channels Memory Expandable up to 2GB (256/ 512/ 1024 MB DDRII Modules) (Note: Do Not Use Other Module Types) Video Controller Intel 945GM Integration Intel®...
Page 108: Interface
Specifications Feature Specification Interface One Serial Port Four USB 2.0 Ports One Parallel Port One RJ-45 Jack for LAN One External Monitor Port One RJ-11 Jack for Modem One Headphone-Out Jack One AC-In Jack One Microphone-In Jack One IEEE 1394a Port (Un-Powered) One Line-In Jack Communication 1GB PCIe Ethernet LAN...
Page 109: Optional
Specifications Feature Specification Optional Optical Drive Module Options: Intel PRO/Wireless 3945ABG PCIe Interface Combo Drive Module Wireless LAN Module DVD-Dual Drive Module DVD Super Multi Drive Module 802.11 b/g Wireless LAN Module Touch Panel (Factory Option) USB (2.0) Bluetooth Module (Factory Option) Hard Glass (Factory Option) Specifications B - 5...
Page 110 Specifications B - 6...
