Seagull Models Ultimate Instruction Manual page 10

ULTIMATE.
6) When satisfied with the alignment of
the stopper assembly tighten the 3 x 20mm
machine screw until the rubber stopper ex-
pands and seals the tank opening. Do not
overtighten the assembly as this could cause
the tank to split.
Attach the silicone fuel and pressure pipes
to the tank. The lower pipe is the 'feed' and the
upper two the 'pressure and fill'. The fill pipe is
the next pipe.
Plastic tape.
You should mark which tube is the vent
and which is the fuel pickup when you attach
fuel tubing to the tubes in the stopper. Once
the tank is installed inside the fuselage, it may
be difficult to determine which is which.
Rubber band.
10
Fuel pick-up tube.
the fuel lines have not become kinked inside
the fuel tank compartment. Air should flow
through easily.
as shown in the following pictures.
installation:
Wheel Collar.
Axle.
Fuel tank.
Instruction Manual.
Blow through one of the lines to ensure
WHEEL AND WHEEL PANTS.
1) Assemble and mounting the wheel pants
2) Follow diagram below for wheel pant
Nut.
Wheel.
Vent tube.
Fuel fill tube.
(2) Washer.
Nut.
Landing Gear.
Wheel Pant.
