TESTING, POWER UP AND RESET

After connecting the power supply, antenna, lock output and auxiliary devices as shown in
this manual and before powering up a SIM card must be installed. The SIM holder can be
found on the back of the module under the label 'SIM'. A SIM card from any supplier can
be used. Simply push the SIM card in (It will only fit one way). IMPORTANT: Replace the
label over the SIM hole.
- Check all the connections have been made correctly and then power up the system.
- The GSM intercom requires approximately 30 seconds too initialise properly. We
recommend not sending SMS messages or pressing buttons during this time.
- From power up; the panel display will first show the software version number for a few
seconds and then 'WAIT'. After a delay the display will show the standby message.
- Once initialised, you can begin programming.

RESET TO FACTORY DEFAULTS

There are two reset modes available. The first will reset the master code only and the
second will reset everything and clear all stored telephone numbers.
RESET THE MASTER CODE TO 1111
1. Power down the intercom panel
2. Hold down the 'Enter' button (on VR4802 or 4802) or the '4' button (on 4802R)
3. Power up continuing to hold the button
4. Wait for the display to revert to the standby message
5. The master code is now reset to 1111
FULL RESET (WARNING: THIS WILL COMPLETELY FORMAT THE MEMORY)
1. Power down the intercom panel
2. Hold down the '9' button (on VR4802 or 4802) or the '3' button (on 4802R)
3. Power up continuing to hold the button
4. When the display shows 'WAIT' release the button
5. After a delay, all settings are returned to factory defaults
The panel software is the same for both Alpha (VR4802, 4802) and scroll (4802R) style
panels. To initially set the panel, power up with the '7' (on VR4802 or 4802) or power up
with the '2' pressed (on 4802R). Keep the button pressed until the display reverts to the
standby message.

PROGRAMMING

Programming can be carried out either by the panel keypad & display or by PC.
Additionally, programming can be carried out via SMS text messages.

PROGRAMMING BY THE KEYPAD AND DISPLAY

The programming menu is protected by a 4 digit engineer's code. The factory default is
1111. To enter programming mode, press '0' followed by the 4 digit code and then press
enter. The programming flow chart is on the following page. An explanation of each
programming option can be found on the pages that follow.
