and begins from when the call/enter button is pressed. The default time is 40 seconds. The
following messages are used to set/check the maximum call time.
1111SPTnnn
1111SPTnnn?
1111SPT?

SET RELAY TIME (RLT)

The relay time can be from 001 – 255 seconds or latching (Set the relay time to 000 for
latched mode. In latch mode, the relay will stay energised until the command is send
again).
1111RLTnnn
1111RLTnnn?
1111RLT?

SET AO (AUXILIARY OUTPUT) TIME (FOR AOM = 1 ONLY) (AOT)

The AO time can be from 001 – 255 seconds or latching (Set the AO time to 000 for
latched mode). This option is only relevant for aux mode 1.
1111AOTnnn
1111AOTnnn?
1111AOT?

SET AO (AUXILIARY OUTPUT) MODE (AOM)

There are three modes of operation for the AO terminal:-
User activated: n= 1; To activate the AO terminal either short g to 5 (Auxiliary 1 input) or
press 6 on the telephone during a call.
Call activated: n= 0; AO will activate when a call begins and deactivate when the call ends.
Call activated (Timed): n = 2; AO will activate when a call begins and deactivate when the
AUX TIME expires.
1111AOMn
1111AOMn?
1111AOM?
PAGE 23 of 32
Store the time nnn (e.g. nnn = 001 - 255 seconds).
Store the time nnn (e.g. nnn = 001 - 255 seconds). Also
send a confirmation text back to the sender.
Query the current stored time. A text message will be
sent to the sender showing the stored time.
Store the time, nnn = time in seconds.
Store the time nnn = time in seconds. Also send a
confirmation text back to the sender.
Query the current stored time. A text message will be
sent to the sender showing the stored time.
Store the time nnn = time in seconds.
Store the time nnn = time in seconds. Also send a
confirmation text back to the sender.
Query the current stored time. A text message will be
sent to the sender showing the stored time.
Store the mode n = 0 - 2.
Store the mode n = 0 - 2. Also send a confirmation
text back to the sender.
Query the current stored mode. A text message will be
sent to the sender showing the stored mode.
