Quick Guide
All inputs, outputs, circuits, DC supplies and relay contacts are galvanically isolated from the supply voltage (PELV) and
other high-voltage terminals.
Surroundings
Enclosure
Enclosure kit available
Vibration test
Max. relative humidity
Aggressive environment (IEC 60721-3-3), coated (standard) frame H1-H5
Aggressive environment (IEC 60721-3-3), non-coated frame H6-H10
Aggressive environment (IEC 60721-3-3), coated (optional) frame H6-H10
Test method according to IEC 60068-2-43 H2S (10 days)
Ambient temperature
Derating for high ambient temperature, see 1.7.6 Surroundings
Minimum ambient temperature during full-scale operation
Minimum ambient temperature at reduced performance, enclosure frame H1-H5
Minimum ambient temperature at reduced performance, enclosure frame H6-H10
Temperature during storage/transport
Maximum altitude above sea level without derating
Maximum altitude above sea level with derating
Derating for high altitude, see 1.7.6 Surroundings
Safety standards
EMC standards, Emission
EMC standards, Immunity

1.8 Special Conditions

1.8.1 Derating for Ambient Temperature
and Switching Frequency
The ambient temperature measured over 24 hours should
be at least 5°C lower than the max. ambient temperature.
If the frequency converter is operated at high ambient
temperature, the continuous output current should be
decreased. For derating curve, see VLT
Guide MG18C.

1.8.2 Derating for Low Air Pressure

The cooling capability of air is decreased at low air
pressure. For altitudes above 2000 m, contact Danfoss
regarding PELV. Below 1000 m altitude no de-rating is
necessary, but above 1000 m the ambient temperature or
the maximum output current should be decreased.
Decrease the output by 1% per 100 m altitude above 1000
m or reduce the max. ambient temperature by 1° per 200
m.
1.9 Options for VLT ®
HVAC Basic Drive FC
101
®
For options, see the VLT HVAC Basic Design Guide MG18C.
®
VLT HVAC Basic Drive Quick Guide
5%-95% (IEC 60721-3-3; Class 3K3 (non-condensing) during operation
See max. output current at 40/50 °C in the tables mains supply
EN 61800-3, EN 61000-3-12, EN 61000-6-1/2, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN
®
HVAC Basic Design
®

MG18A402 - VLT

is a registered Danfoss trademark
EN 61800-3, EN 61000-6-3/4, EN 55011, IEC 61800-3

1.10 MCT 10 Support

MCT 10 information is available at: www.danfoss.com/
BusinessAreas/DrivesSolutions/fc101driveupdates
IP20
IP21, TYPE 1
1.0 g
Class 3C3
Class 3C2
Class 3C3
0 °C
-20 °C
-10 °C
-30 to +65/70 °C
1000 m
3000 m
EN/IEC 61800-5-1, UL 508C
61000-4-5, EN 61000-4-6
43
1 1
