Quick Guide
Power [kW]
Frame IP class 3x525-600 V
H9 IP20 2.2-7.5
H10 IP20 11-15
H6 IP20 18.5-30
H7 IP20 37-55
H8 IP20 75-90
Table 1.13 Details of Tightening Torques
≤ 95 mm
1 2
Cable dimensions
2 Cable dimensions >95 mm 2

1.3.5 Connecting to Mains and Motor

The frequency converter is designed to operate all
standard three-phased asynchronous motors. For
maximum cross-section on wires see 1.6 General Specifi-
cations.
•
Use a shielded/armored motor cable to comply
with EMC emission specifications, and connect
this cable to both the decoupling plate and the
motor metal.
•
Keep motor cable as short as possible to reduce
the noise level and leakage currents.
•
For further details on mounting of the
decoupling plate, see FC 101 De-coupling Plate
Mounting Instruction MI02Q.
•
Also see EMC-Correct Installation in the VLT
Basic Design Guide, MG18C.
1. Mount the earth wires to earth terminal.
2. Connect motor to terminals U, V and W.
3. Mount mains supply to terminals L1, L2 and L3
and tighten.
®
VLT HVAC Basic Drive Quick Guide
Line Motor DC connection
1.8 1.8
recommended
1.8 1.8
recommended
4.5 4.5
10 10
1 1
14/24 14/24
3
®
HVAC
Illustration 1.3 H1-H5 Frame
IP20 200-240 V 0.25-11 kW and IP20 380-480 V 0.37-22 kW.
1
2
3
4
Table 1.14
®
MG18A402 - VLT is a registered Danfoss trademark
Torque [Nm]
Control
terminals
not 0.5
not 0.5
- 0.5
- 0.5
- 0.5
1
2
U
V W
-DC +DC
2
Line
Earth
Motor
Relays
Earth Relay
3 0.6
3 0.6
3 0.5
3 0.5
3 0.5
4
7
1 1
