Quick Guide
1 1
Motor Set-up
The Quick Menu Motor Set-up guides through the needed
motor parameters.
No & Name
0-03 Regional
Settings
0-06 GridType [0] -[132] see
1-10 Motor
Construction
1-20 Motor
Power
1-22 Motor
Voltage
1-23 Motor
Frequency
1-24 Motor
Current
1-25 Motor
Nominal
Speed
1-26 Motor
Cont. Rated
Torque
1-30 Stator
Resistance (Rs)
28
VLT
Range Default Function
[0] Interna- 0
tional
[1] US
Size selected Select operating
start -up mode for restart
wizard for upon
open loop reconnection of
application the drive to
mains voltage
after power
down
*[0] Motor [0]
construction Asynchron
[1] PM, non
salient SPM
0.12-110 kW/ Size related Enter motor
0.16-150 hp power from
nameplate data
50.0-1000.0 V Size related Enter motor
voltage from
nameplate data
20.0-400.0 Hz Size related Enter motor
frequency from
nameplate data
0.01-10000.00 Size related Enter motor
A current from
nameplate data
100.0-9999.0 Size related Enter motor
RPM nominal speed
from nameplate
data
0.1-1000.0 Size related This parameter is
available only
when 1-10 Motor
Construction
Design is set to
[1] PM, non-
salient SPM.
NOTE
Changing this
parameter
affects settings
of other
parameters
0.000-99.990 Size related Set the stator
resistance value
MG18A402 - VLT
®
HVAC Basic Drive Quick Guide
No & Name
1-37 d-axis
Inductance
(Ld)
1-39 Motor
Poles
1-40 Back EMF
at 1000 RPM
1-73 Flying
Start
3-41 Ramp 1
Ramp Up
Time
3-42 Ramp 1
Ramp Down
Time
4-12 Motor
Speed Low
Limit [Hz]
4-14 Motor
Speed High
Limit [Hz]
4-19 Max
Output
Frequency
Table 1.28
®
is a registered Danfoss trademark
Range Default Function
0-1000 Size related Enter the value
of the d-axis
inductance.
Obtain the value
from the
permanent
magnet motor
data sheet. The
de-axis
inductance
cannot be found
by performing an
AMA.
2-100 4 Enter the number
of motor poles
10-9000 Size related Line-Line RMS
back EMF voltage
at 1000 RPM
[0] Disabled 0 Select Enable to
[1] Enabled enable the
frequency
converter to
catch a spinning
motor
0.05-3600.0 s Size related Ramp up time
from 0 to rated
1-23 Motor
Frequency
0.05-3600.0 s Size related Ramp down time
from rated
1-23 Motor
Frequency to 0
0.0-400 Hz 0.0 Hz Enter the
minimum limit
for low speed
0.0-400 Hz 65 Enter the
maximum limit
for high speed
0-400 Size related Enter the
maximum output
frequency value
