Installing and Configuring Additional FLDs
The service person must follow the guidelines in Table 4-1 to make a SCSI
drive work in a deskside system.
Table 4-1 Overview of Drive Installation Guidelines
Drive Sled Board SCSI Rack
Channel Backplane
Configuration Configuration
All jumpers in A22P50 jumper in
TRMPWR jumper in
A26P52 jumper in
Not applicable Not applicable
Middle jumpers in All jumpers in
All jumpers in
The Challenge deskside chassis uses both half-height and full-height
front-loading devices. The power must be off to install or remove storage
devices.
FLDs are easily removed and replaced, allowing flexible and secure data
management.
Be careful not to push the drive ID selector when moving the sled
Note:
release lever to the right. An incorrect SCSI device ID may cause SCSI bus
failure. FLDs can be installed and removed with the front door closed and
only the drive door open.
Caution: Use proper handling and storage procedures to minimize the loss
of data and equipment. In particular, do not remove disk drives while they
are operating. Always power off the system before removing an FLD. Be
sure to use standard electrostatic discharge prevention precautions when
removing, storing, transporting, or replacing an FLD.

Installing and Configuring Additional FLDs

IO4 Configuration Transfer Rate
Jumpers on SCSI
Adapter Board
Bus set to Both jumpers in
single-ended
Bus set to Both jumpers out
single-ended
Bus set to Not applicable
differential
Bus set to Not applicable
differential
43
