Appendix E: Challenge VMEbus Implementation
138
Table E-2 P2 VME Pin Assignments
Pin Row A
(Note: This row is
user-defined.)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
Row B Row C
(Note: This row is
user-defined).
+5V
GND
RESERVED
A24
A25
A26
A27
A28
A29
A30
A31
GND
+5V
D16
D17
D18
D19
D20
D21
D22
D23
GND
