Warning:
To avoid electric shock and/or a fire hazard, do not
disassemble the Challenge deskside system chassis. No user-serviceable
parts are located inside the unit.
Before connecting or disconnecting any terminal, peripheral, or
Note:
front-loading drive, be sure the system is powered off and the primary
power source is disconnected. The system power connection should be
unplugged at the wall or back of the chassis before you open either door.

Opening the Front Door

To access the I/O panel, you must first open the front door by using the
following information:
1. Be sure that the system power is turned off, according to the procedures
in this section.
2. Open the drive door to expose the drives and front panel retainer
latches.
3. Release the two retainer latches by fully depressing and releasing each
latch with a pointed object, such as the tip of a Phillips screwdriver; be
careful not to mar the surface. The pointed object must be narrow
enough to depress the inner button completely; Figure 3-2 shows the
latch location and operation.
The chassis front door is released and can be pivoted on the hinge pins
located on the left side of the door.
4. To close the front door, swing it to the closed position, then use a
pointed object to fully depress and release the retainer latches.
Chassis Components
