SECTION 7: Cavitron JET Plus Combination System Description

7.1 System Controls

Ultrasonic Power Level Control
Turn knob to select the ultrasonic power level for operation. Turning the knob clockwise
increases the distance the insert tip moves (stroke) without changing the frequency;
turning the knob counterclockwise decreases the distance the insert tip moves (stroke)
without changing the frequency.
The Blue Zone is a low-power range for effective subgingival debridement and improved
patient comfort during definitive therapy.
Rinse
Turn the ultrasonic power level control knob fully counterclockwise until a "click" is heard.
Rinse mode is for use during an ultrasonic scaling procedure when lavage is desired with
minimal cavitation.
Powder Flow Control
Rotate clear Powder Flow
Control to adjust powder
flow rates. For minimum
powder flow turn control
clockwise to "L". For
maximum flow turn to "H".
Dual Position Foot Control
Operates the system in Boost
and normal power modes.
See Section 7.6
Main Power ON/OFF Switch
ON/OFF Switch located at the center front underside of the
system.
10
JET-Mate™
Handpiece
Accepts all
Cavitron
®
30K
Ultrasonic inserts
and Cavitron
JET Air Polishing
Inserts. Auto-
matically selects
air polishing or
scaling mode.
See Section 7.3
Diagnostic
Display
See Section
7.2
Handpiece Holder
Securely holds the
system's handpiece,
or cable connector
when handpiece is not
installed. Handpiece
must be oriented as
shown and pressed
gently into position.
