Your Fury 55 kit will require a number of different supplies and tools to ensure the best final result. They are
as follows:
required lubricants and compounds:
1. Medium Strength Thread Locking Compound - X-Cell Super Lock Blue (MA3200-20)
2. Tri-Flow Oil (MA3200-02)
3. Tri-Flow Synthetic Grease (MA3200-06)
4. Medium Cyanoacrylate (CA)
5. Retaining Compound - X-Cell Super Lock Green (MA3200-22)

required tools:

1. m4 Nut Driver
2. m5 Nut Driver
3. m5.5 Nut Driver
4. m7 Nut Driver
5. 1.5mm Allen Driver
6. 2.0mm Allen Driver
7. 2.5mm Allen Driver
8. 3.0mm Allen Driver
9. Needle Nose Pliers
10. Phillips Screwdriver #1
11. Flat Screwdriver 2.5mm
12. Razor Knife (X-acto)
13. Snap Ring Pliers

optional tools:

1. Swashplate Leveling Tool (MA3000-10)
2. Pitch Gauge (MA3000-06)
3. Flybar Alignment Gauge (MA3000-08)
4. Crankshaft Locking Tool (MA3000-34)
5. Fury 55 Head Set Up Tool (MA3000-02)
6. Optical Heli Tachometer (MA3000-50)

other required components:

The X-Cell Fury 55 is an airframe kit. To complete the model, several other items are required but are not
included with the kit. There are many choices for these other required components, and any competent hobby
retailer with R/C helicopter experience will be happy to make suggestions. You will need:
1. E ngine, "50" size (there are various sizes available that are considered "50" size, all will work in the
Fury 55.
2. Helicopter style muffler suited to the engine you choose.
3. C yclic servos (Miniature Aircraft USA recommends high quality cyclic servos with no less than
80 oz. in. of torque).
4. Throttle servo (Miniature Aircraft USA recommends a high quality ball bearing servo)
5. Main rotor blades of 600-620mm in length.
6. R/C helicopter transmitter with at least 6 channels, and eCCPM capabilities.
7. R/C helicopter gyro (Miniature Aircraft USA recommends a "heading hold style gyro).
8. R/C helicopter starting and fueling equipment.
9. R/C helicopter engine governor (optional).
