Introduction

Introduction

Document history

Version Date
0.9 18.12.2003
0.91 09.01.2004
1.0 20.01.2004
1.1 07.09.2004
1.2 08.10.2004
1.3 23.02.2005
1.31 12.04.2005
1.4 24.08.2005
2.0.0 10.03.2006
2.1.0 10.04.2006
This MARLIN Technical Manual describes in depth the technical specifica-
tions, dimensions, all camera features (IIDC standard and AVT smart fea-
tures) and their registers, trigger features, all video and color formats, band-
width and frame rate calculation.
For information on hardware installation, safety warnings, pin assignments
on I/O connectors and 1394b connectors read the Hardware Installation
Guide.
Note Please read through this manual carefully.
We assume that you have read already the Hardware
Installation Guide and that you have installed the hard-
ware and software on your PC or laptop (FireWire card,
cables).
Remarks
First issue
Typos corrected, minor changes, spectral sensitivity of IR cut
filter added
Wording checked, MARLIN W90/270 added
MARLIN F-131C added, added features to make manual compli-
ant with firmware 2.05, wording checked, impulse diagrams
corrected
Manual compliant to firmware 2.06
For MARLINS with serial numbers xx/yy-6zzzzzzz
Color: firmware 20050321, CMOS included
Added MARLIN F-146, all: class B compliant
Added MARLIN F-201, manual compliant to firmware 3.03,
added features secure image signature (SIS) and user profiles,
minor corrections
Time stamp changed
to be continued on next page
Table 1: Document history
