Allied Vision Technologies GX1050 Technical Manual

Gigabit ethernet camera

Hide thumbs Also See for GX1050:

Technical manual (77 pages)

Table Of Contents

Quick Links

Download this manual See also: Technical Manual

700056A

April 7, 2010

Allied Vision Technologies Canada

Inc.

101-3750 North Fraser Way

Burnaby, BC

V5J 5E9 / Canada

Table of Contents

Need help?

Do you have a question about the GX1050 and is the answer not in the manual?

Questions and answers

Summary of Contents for Allied Vision Technologies GX1050

Page 1 700056A April 7, 2010 Allied Vision Technologies Canada Inc. 101-3750 North Fraser Way Burnaby, BC V5J 5E9 / Canada...
Page 2: Table Of Contents
GX IO Schematic ... 27 User Trigger Circuit Example ... 28 TV Zoom Lens Connection ... 29 Video Iris Connection ... 30 Trigger Timing Diagram ... 31 Notes on Triggering ... 32 Camera Controls ... 34 GX1050 Technical Manual Page 2...
Page 3: Warranty
All text, pictures and graphics are protected by copyright and other laws protecting intellectual property. It is not permitted to copy or modify them for trade use or transfer, nor may they be used on web sites. Allied Vision Technologies Canada Inc. 1/2010 All rights reserved. GX1050 Technical Manual Page 3...
Page 4 Burnaby, BC, V5J 5E9, Canada Tel: +1 604-875-8855 Fax: +1 604-875-8856 e-mail: info@alliedvisiontec.com Allied Vision Technologies Inc. 38 Washington Street Newburyport, MA 01950, USA Toll Free number +1-877-USA-1394 Tel.: +1 978-225-2030 Fax: +1 978-225-2029 e-mail: info@alliedvisiontec.com GX1050 Technical Manual Page 4...
Page 5: Specifications
The GX1050 series of cameras are sensitive, 112 frames per second, 1 megapixel, Gigabit Ethernet cameras based on the Kodak KAI-01050 CCD sensor. These cameras support the use of 1 or 2 gigabit Ethernet ports in a LAG configuration for higher bandwidth requirements.
Page 6 Canada Inc. will not warranty parts which have been damaged through the obvious misuse of this product. GX1050 Technical Manual Page 6...
Page 7: Mechanical
CAMERA IS TO BE OPERATED IN A WARM ENVIRONMENT, IT IS SUGGESTED THAT THE CAMERA BE MOUNTED ON A HEAT SINK SUCH AS A METAL BRACKET AND THAT THERE IS SUFFICIENT AIR FLOW. GX1050 Technical Manual Kodak KAI-01050 Progressive Interline 1024 x 1024 pixels 5.5µm x 5.5µm...
Page 8 1 to 8 pixels Vertical Binning 1 to 8 rows Pixel Formats Mono8, Mono16*, Bayer8, Bayer16, Rgb24, Yuv444, Bgr24, Rgba32, Bgra32, Bayer12Packed Sync Out Modes trigger ready, trigger input, exposing, readout, imaging, strobe, GPO *On monochrome versions only. GX1050 Technical Manual Page 8...
Page 9 GX C-MOUNT GX1050 Technical Manual Page 9...
Page 10: Connections
GX CONNECTION DIAGRAM GX1050 Technical Manual Page 10...
Page 11: Gigabit Ethernet Ports
For best performance the connection for POWER GROUND should be physically close to the EXTERNAL POWER connection. GX1050 Technical Manual Cable lengths up to 100m are supported. For higher FUNCTION...
Page 12: External Power
These signals can be driven from 5V to 24V with a current load of 5mA. VDD+3.3 TO CAMERA LOGIC HCPL-063L GX1050 Technical Manual 180R 1/10W MMBF4393LT1G 180R 1/10W MMBF4393LT1G...
Page 13 Various USER VCC values and load values for the above circuit are indicated in the following table: USER USER LOAD 5V 4.8mA 1K 12V 9.2mA 1.2K 12V 4.9mA 2.4K 24V 9.5mA 2.4K 5mA 4.8K GX1050 Technical Manual PIN 10. USER VCC TLP281-4GB V LOAD R POWER DISSIPATION 1.5µs 6.5µs 2µs 14µs 4.1V 32mW 4.8V 23mW 1.5µs...
Page 14: Sync Output
See the SYNC OUTPUT connection should be physically close to the used SYNC OUT signals and USER GROUND. GX1050 Technical Manual It is also recommended that this ground connection be section for more detail. To prevent parasitic coupling this Page 14...
Page 15: Lens Control Port
The lens control connector is a Hirose 3260-8S3. The mating cable connector is Hirose 3240-8P-C(50). This connector can be purchased from AVT Canada Inc. or from http://www.digikey.com. See Addendum for more detail. GX1050 Technical Manual CAMERA The camera can be configured to FUNCTION...
Page 16 Repeat this process until the debris is gone. If this process fails to remove the debris, then contact AVT Canada Inc. GX1050 Technical Manual If the debris is still there, repeat this process. Repeat the...
Page 17 The distance required will depend on the lens used but typically 30 to 50 feet should suffice. Make sure the lens is firmly threaded onto the c-mount ring. Rotate the lens and c-mount ring until the image is focused. Carefully tighten locking ring. Recheck focus. GX1050 Technical Manual Page 17...
Page 18 (a) select “Jumbo Frames” and change the value to 9014 bytes or higher. (b) select “Receive Descriptors” on the same list and change the value to 512 (c) select "Performance Options" and set "Interrupt Moderate Rate" to "Extreme" GX1050 Technical Manual Page 18...
Page 19 10. Select the “Teaming” tab (analogous to LAG), enable “Team this adapter with other adapters and click on the “New Team” button. 11. Specify a name for the Team (Link Aggregate Group). This should be something that will distinguish this GX1050 Technical Manual Page 19...
Page 20 13. Choose “Static Link Aggregation”. Click “Next” to continue. 14. The LAG group will now be configured. You may be asked to permit the “AVT_Prosilica GigE Vision Filter Miniport” installation on the new LAG adapter. Click “Continue Anyway”. GX1050 Technical Manual Page 20...
Page 21 15. Once completed the properties of the TEAM (LAG) that has just been created will appear. A new Network Connections Icon corresponding to the LAG group is created. You have now completed the Link Aggregate Group configuration. 16. Reboot the system and install GigE Sample Viewer. GX1050 Technical Manual Page 21...
Page 22: Gx1050 Technical Manual
Camera Controls Addendum for description of each setting. Select the eye icon to stream images. If the camera is not imaging, see the Trouble Shooting section of this document. Figure 1. GigE Viewer application window. GX1050 Technical Manual Page 22...
Page 23 Camera is listed: Your camera and NIC must be on the same subnet, e.g.: NIC: IP 169.254.23.2 Subnet Mask: 255.255.0.0, Camera IP: 169.254.43.3 Subnet Mask: 255.255.0.0. GX1050 Technical Manual (Start>Programs>Prosilica>GigEIPConfig A camera in DHCP (AutoIP fallback) mode. C:\Program...
Page 24 Ipconfig /all screenshot Is the camera listed in SampleViewer but can t acquire images? Reset your camera settings to factory default: with ConfigFileIndex = Factory, click the ConfigFileLoad button. While streaming, check your Stats: GX1050 Technical Manual Page 24...
Page 25 ExposureMode, and be sure your scene is suitably lit. If you are still having problems acquiring images, please send your camera settings file (click on the disk icon in SampleViewer) to support@alliedvisiontec.com. GX1050 Technical Manual All stats 0 while streaming. Firewall likely blocking traffic Saving camera setting file...
Page 26 GX1050 Technical Manual Page 26...
Page 27 VDD+3.3 VDD+3.3 4.7K CAMERA LOGIC SY NC IN 1 CAMERA LOGIC SY NC IN 2 NC7WZ14P6X 3.3V LOGIC CAMERA LOGIC SYNC OUT 1 100K CAMERA LOGIC SYNC OUT 2 100K CAMERA LOGIC SYNC OUT 3 100K CAMERA LOGIC SYNC OUT 4 100K VDD+3.3 4.7K...
Page 28 CAMERA POWER VDD+5 5V POWER CIRCUIT USER LOGIC SY NC IN 1 1Y 1 1Y 2 USER LOGIC SY NC IN 2 1Y 3 1Y 4 USER LOGIC SY NC OUT 1 2Y 1 USER LOGIC SY NC OUT 2 2Y 2 USER LOGIC SY NC OUT 3 2Y 3...
Page 29 ZOOM+ ZOOM- FOCUS+ TV ZOOM LENS BIPOLAR TYPE FOCUS- IRIS+ IRIS- COMMON ZOOM TV ZOOM LENS FOCUS UNIPOLAR TYPE IRIS COMMON NOTES: 1. CURRENT CAPACITY PER AXIS = 50mA. 2. VERIFY LENS VOLTAGE SETTING ON CAMERA DOES NOT EXCEED LENS VOLTAGE SPECIFICATION. IRIS+ IRIS- FOCUS+...
Page 30 POWER GROUND 12V_POWER VIDEO AUTO-IRIS LENS JEITA CONNECTOR POWER GROUND 12V POWER LENS POWER VIDEO SIGNAL LENS GROUND HIROSE HR10A-10P-12S HIROSE 3240-8P-C(50)
Page 31 GX1050 Technical Manual Page 31...
Page 32 For applications requiring the shortest possible Trigger Latency and the smallest possible Trigger Jitter the User Trigger signal should be applied when Imaging is false and Idle is true. o In this case, Trigger Latency and Trigger Jitter are as indicated in the Specifications section. GX1050 Technical Manual Page 32...
Page 33 Trigger Ready is detected. o In this case, Trigger Latency and Trigger Jitter can be up to 1 line time since Exposure must always begin on an Interline boundary. GX1050 Technical Manual Page 33...
Page 34 For the latest, up to date camera controls, see AVT Camera and Driver Attributes.pdf at http://www.alliedvisiontec.com GX1050 Technical Manual Page 34...
