Configuration of the camera
Definition
Register Name
0xF1000550 USER_PROFILE

User profiles

Within the IIDC specification user profiles are called memory channels.
Often they are called user sets. In fact these are different expressions for
the following: storing camera settings into a non-volatile memory inside the
camera.
With firmware 3.03 (MARLIN CCD) and firmware 3.45 (MARLIN CMOS) cam-
eras, can store up to three user profiles (plus the factory default) nonvolatile
in the camera.
User profiles can be programmed with the following advanced feature regis-
ter:
Field
Presence_Inq
---
SaveProfile
RestoreProfile
SetDefaultID
---
ErrorCode
---
ProfileID
Table 128: Advanced register: User profiles
In general this advanced register is a wrapper around the standard memory
channel registers with some extensions. In order to query the number of
available user profiles please check the Memory_Channel field of the
BASIC_FUNC_INQ register at offset 0x400 (see IIDC V1.3x for details).
The ProfileID is equivalent to the memory channel number and specifies the
profile number to store settings to or to restore settings from. In any case
profile #0 is the hard-coded factory profile and cannot be overwritten.
After an initialization command, startup or reset of the camera, the ProfileID
also indicates which profile was loaded on startup, reset or initialization.
Bit Description
[0] Indicates presence of this
feature (read only)
[1..7] Reserved
[8] Save settings to profile
[9] Load settings from profile
[10] Set profile ID as default
[11..19] Reserved
[20..23] Error code
See Table 129: User profile:
Error codes
[24..27] Reserved
[28..31] ProfileID (memory channel)
MARLIN Technical Manual V2.4.0
on page 232.
