Specifications

MARLIN F-046B/C

Feature
Image device
Chip size
Cell size
Picture size (max.)
Lens mount
ADC
Color modes
Frame rates
Gain control
Shutter speed
External trigger shutter
Internal FIFO memory
Number of look-up tables
Smart functions
Transfer rate
Digital interface
Power requirements
Power consumption
Dimensions
Mass
Operating temperature
Storage temperature
Regulations
Standard accessories
Optional accessories
Specification
Type 1/2 (diag. 8 mm) progressive scan SONY CCD ICX-415AL/AQ
with HAD microlens
7.48 mm x 6.15 mm
8.3 µm x 8.3 µm
780 x 582 (Format_7 Mode_0)
C-Mount: 17.526 mm (in air); Ø 25.4 mm (32 tpi)
mechanical flange back to filter distance: 8.2 mm
12 bit
Only color: Raw8, RGB8, YUV422, YUV411
3.75 fps; 7.5 fps; 15 fps; 30 fps; up to 52.81 fps in Format_7
Manual: 0-24 dB (0.035 dB/step); auto gain (select. AOI)
32 µs ...67.108.864 µs (~67s); auto shutter (select. AOI)
Trigger_Mode_0, Trigger_Mode_1, advanced feature:
Trigger_Mode_15 (bulk); image transfer by command; trigger delay
Up to 13 frames
One, user-programmable (10 bit
Real-time shading correction image sequencing, image mirror (L-R
R-L), binning, secure image signature (SIS), user profiles
Two configurable inputs, two configurable outputs
RS-232 port (serial port, IIDC V1.31)
100 Mbit/s, 200 Mbit/s, 400 Mbit/s
IEEE 1394 IIDC V1.3
DC 8 V - 36 V via IEEE 1394 cable or 12-pin HIROSE
Less than 3 watt (@ 12 V DC)
72 mm x 44 mm x 29 mm (L x W x H); without tripod and lens
<120 g (without lens)
+5 ... +45 °Celsius
-10 ... +60 °Celsius
CE, FCC Class B, RoHS (2002/95/EC)
b/w and color: IR cut filter
b/w: IR cut filter, IR pass filter
color: protection glass
Table 9: Specification MARLIN F-046B/C
8 bit); gamma (0.5)
