Description of the data path
Register Name
0xF0F0081C SHUTTER
To configure this feature in control and status register (CSR):
Field Bit
Presence_Inq [0]
Abs_Control [1]
--- [2..4]
One_Push [5]
ON_OFF [6]
A_M_MODE [7]
--- [8..19]
Value [20..31]
Table 30: CSR: Shutter
Note Configuration
To configure this feature in an advanced register: See
115: Advanced register: Auto shutter control
Description
Presence of this feature:
0: N/A
1: Available
Absolute value control
O: Control with value in the Value field
1: Control with value in the Absolute value
CSR
If this bit= 1 the value in the Value field will
be ignored.
Reserved
Write 1: begin to work (self-cleared after oper-
ation)
Read:
1: in operation
0: not in operation
If A_M_Mode = 1, this bit will be ignored.
Write: ON or OFF this feature
Read: read a status
0: OFF
1: ON
Write: set mode
Read: read current mode
0: MANUAL
1: AUTO
Reserved
Read/Write Value
This field is ignored when writing the value in
Auto or OFF mode.
If readout capability is not available, reading
this field has no meaning.
