Video formats, modes and bandwidth
Format Mode Resolution
0 1392 x 1040
1392 x 1038
1 696 x 1040
7
1392 x 1040
2 1392 x 520
696 x 518
3 696 x 520
Table 61: Video Format_7 default modes Marlin F-146B /
Color mode
Mono8
Mono16
YUV411
YUV422
RGB8
RAW8
Mono8
Mono16
Mono8 (RAW)
Mono16
YUV411
YUV422
RGB8
RAW8
Mono8
Mono16
Owing to color interpolation, the maximum height is 1038 pixels in YUV
modes and the first and last one or two pixel columns contain incorrect color
information.
In Format_7 maximum frame rates are given. Precise lowering is possible
with lower packet size setting.
Maximal S400 frame rates for Format_7 modes
17.43 fps
11.32 fps
15.1 fps
11.3 fps
7.55 fps
17.47 fps
17.43 fps H-binning
17.43 fps H-binning
17.43 fps
22.6 fps V-binning
17.51 fps H+V sub-sampling
17.47 fps H+V sub-sampling
17.51 fps H+V sub-sampling
17.47 fps H+V sub-sampling
28.57 fps H+V binning
28.57 fps H+V binning
