How does bandwidth affect the frame rate?
Mono8 (raw data)
Figure 83: Bayer-coded test image
The color camera outputs Bayer-coded raw data in Mono8 instead of (as
described in IIDC V1.3) a real Y signal.
Note
The first pixel of the image is always the red pixel from the
sensor. (Mirror must be switched off.)
MARLIN Technical Manual V2.4.0
170
