Advanced features (AVT-specific)

Register Register name
0XF1000010 VERSION_INFO
0XF1000040 ADV_INQ_1
0XF1000044 ADV_INQ_2
0XF1000200 MAX_RESOLUTION
0XF1000208 TIMEBASE
0XF100020C EXTD_SHUTTER
0XF1000210 TEST_IMAGE
0XF1000220 SEQUENCE_CTRL
0XF1000224 SEQUENCE_PARAM
0XF1000240 LUT_CTRL
0XF1000244 LUT_MEM_CTRL
0XF1000248 LUT_INFO
0XF1000250 SHDG_CTRL
0XF1000254 SHDG_MEM_CTRL
0XF1000258 SHDG_INFO
The camera has a variety of extended features going beyond the possibilities
described in IIDC V1.3. The following chapter summarizes all available
advanced features in ascending register order.
Note This chapter is a reference guide for advanced registers
and does not explain the advanced features itself. For
detailed description of the theoretical background see
• Chapter
• Links given in the table below

Advanced registers summary

The following table gives an overview of all available advanced registers:
Table 97: Advanced registers summary
Description of the data path
Description
Table 98: Advanced register: Version information
on page 204
See Table 100: Advanced register: Advanced fea-
ture inquiry on page 206
See Table 101: Advanced register: Maximum reso-
lution inquiry on page 207
See Table 102: Advanced register: Time base
page 208
See Table 104: Advanced register: Extended shut-
ter on page 210
See Table 105: Advanced register: Test image
page 211
except MARLIN F-131x
See Table 51: Advanced register: Sequence mode
on page 131
See Table 107: Advanced register: LUT
213
See Table 108: Advanced register: Shading
page 214
MARLIN Technical Manual V2.4.0
on page 65
on
on
on page
on
201
