Configuration of the camera
Register Name
0xF1000258 SHDG_INFO
Register Name
0xF1000260 DEFERRED_TRANS
Field
Presence_Inq
---
MaxImageSize
Table 108: Advanced register: Shading

Deferred image transport

Using the register, the sequence of recording and the transfer of the images
can be paused. Setting HoldImg prevents transfer of the image. The images
are stored in ImageFIFO.
The images indicated by NumOfImages are sent by setting the SendImage
bit.
When FastCapture is set (in Format_7 only), images are recorded at the high-
est possible frame rate.
Field
Presence_Inq
---
SendImage
HoldImg
FastCapture
---
FiFoSize
NumOfImages
Table 109: Advanced register: Deferred image transport
Bit Description
[0] Indicates presence of this
feature (read only)
[1..7] Reserved
[8..31] Maximum shading image size
(in bytes)
Bit Description
[0] Indicates presence of this
feature (read only)
[1..4] Reserved
[5] Send NumOfImages now
(auto reset)
[6] Enable/Disable deferred
transport mode
[7] Enable/disable fast capture
mode
[8..15] Reserved
[16..23] Size of FIFO in number of
images (read only)
[24..31] Write: Number of images to
send
Read: Number of images in
buffer
