Camera interfaces
Register Name
0xF0F00534 TRIGGER_DELAY_INQUIRY Presence_Inq

Trigger delay

Since firmware version 2.03, the cameras feature various ways to delay image
capture based on external trigger.
With IIDC V1.31 there is a standard CSR at Register F0F00534/834h to control
a delay up to FFFh x timebase value. The following table explains the inquiry
register and the meaning of the various bits.
Field
Abs_Control_Inq
-
One_Push_Inq
Readout_Inq
ON_OFF
Auto_Inq
Manual_Inq
Min_Value
Max_Value
Table 20: Trigger delay inquiry register
Bit Description
[0] Indicates presence of this
feature (read only)
[1] Capability of control with
absolute value
[2] Reserved
[3] One-push auto mode (con-
trolled automatically by the
camera once)
[4] Capability of reading out the
value of this feature
[5] Capability of switching this
feature ON and OFF
[6] Auto Mode (controlled auto-
matically by the camera)
[7] Manual mode (controlled by
user)
[8..19] Minimum value for this fea-
ture
[20..31] Maximum value for this fea-
ture
