Ref.
Qty.
Description
29
7
IDC
2PIN_JUMPER_
SHORT
30
1
PWR .65MM
CON045
31
1
5A RESETABLE
FUS005
32
4
MOMENTARY
SWT024
33
2
IDC 25x2
IDC25x2_SMTA
34
1
IDC 35x2
IDC35x2_SMTA
35
1
IDC 2X1
IDC2X1_SMT
36
1
POWER 2X1
CON064
37
1
SPDT SWT026
38
1
IDC 3X1
IDC3X1_SMT
39
1
ROTARY
SWT027
40
4
YELLOW
LED001
41
3
100 1/10W 5%
0805
42
8
600 100MHZ
200MA 0603
43
2
600 100MHZ
500MA 1206
ADSP-BF592 EZ-KIT Lite Evaluation System Manual
ADSP-BF592 EZ-KIT Lite Bill Of Materials
Reference
Manufacturer
Designator
SJ1-2,SJ4-5,SJ7-9
P9
F2
SW7-9,SW11
P4-5
P6
JP2
P3
SW3
JP1
SW4
LED1-3,LED7
R62-63,R118
FER1-7,FER10
FER12-13
Part Number
DIGI-KEY
S9001-ND
DIG
CP1-023-ND
MOUSER
650-RGEF500
PANASONIC
EVQ-Q2K03W
SAMTEC
TSSH-125-01-L-
DV-A
SAMTEC
TSSH-135-01-L-
DV-A
SAMTEC
TSM-102-01-T-SV
WEIDMULLER
1824420000
NKK SWITCHES
CS12ANW03
SAMTEC
TSM-103-01-T-SV
COPAL
S-8110
DIGI-KEY
P512TR-ND
VISHAY
CRCW0805100RJNE
A
DIGI-KEY
490-1014-2-ND
STEWARD
HZ1206B601R-10
A-3
