Programmable Flags
Table 2-1. Port F Programmable Flag Connections (Cont'd)
Processor Pin Other Processor Function
PF6 TSCLK1/PPI14
PF7 TFS1/PPI15
PF8 TMR2/SPI0SSEL2/WAKEN0
PF9 TMR0/PPI_FS1/SPI0SSEL3
PF10 TMR1/PPI_FS2
PF11 UART_TX/SPI0SSEL4
PF12 UART_RX/SPI0SSEL7/TACI2_0
PF13 SPI0MOSI/SPI1SSEL3
PF14 SPI0MISO/SPI1SSEL4
PF15 SPI0SCK/SPI1SSEL5
Table 2-2. Port G Programmable Flag Connections
Processor Pin Other Processor Function
PG0 DRSEC0/SPI0SSEL1/SPI0SS
PG1 DRPRI0/SPI1SSEL1/WAKEN3
PG2 RSCLK0/SPI0SSEL5
PG3 RFS0/PPI_FS3
2-4 ADSP-BF592 EZ-KIT Lite Evaluation System Manual
EZ-KIT Lite Function
Default: Not used.
Land grid array, expansion interface II
Default: Not used.
Land grid array, expansion interface II
Default: .
SPI0SSEL2
Land grid array, expansion interface II
Default: .
UART_CTS
Land grid array, expansion interface II
Default: .
UART_RTS
Land grid array, expansion interface II
Default: .
UART_TX
Land grid array, expansion interface II
Default: .
UART_RX
Land grid array, expansion interface II
Default: .
SPI0MOSI
Land grid array, expansion interface II
Default: .
SPI0MISO
Land grid array, expansion interface II
Default: .
SPI0SCK
Land grid array, expansion interface II
EZ-Kit Lite Function
Default: Not used.
Land grid array, expansion interface II
Default: .
DRPRI0
Land grid array, expansion interface II
Default: .
RSCLK0
Land grid array, expansion interface II
Default: .
RFS0
Land grid array, expansion interface II
