This chapter describes the hardware design of the ADSP-BF592 EZ-KIT
Lite board.
The following topics are covered.
• "System Architecture" on page 2-2
Describes the board's configuration and explains how the board
components interface with the processor.
• "Programmable Flags" on page 2-3
Shows the locations and describes the programmable flags (PFs).
• "Push Buttons and Switches" on page 2-6
Shows the locations and describes the push buttons and switches.
• "Jumpers" on page 2-12
Shows the locations and describes the configuration jumpers.
• "LEDs" on page 2-16
Shows the locations and describes the LEDs.
• "Connectors" on page 2-19
Shows the locations and provides part numbers for the on-board
connectors. In addition, the manufacturer and part number infor-
mation is provided for the mating parts.
ADSP-BF592 EZ-KIT Lite Evaluation System Manual 2-1
