Easy Access Transmitter Coding; Remotely Coding Transmitters - Automatic Technology GDO-6v3 EasyRoller Installation Instructions Manual

Coding Transmitters
fi g 23
fi g 24
fi g 25
20 GDO-6v3 EasyRoller ® Owner Installation Instructions
Step 11 - Easy Access Transmitter Coding
Press and hold the DOOR CODE button (Fig. 23).
a.
b. Press the EAT's button two (2) seconds, pause for
two (2) seconds, then press the button again for
two (2) seconds (Fig. 24).
c. Release the DOOR CODE button.
d. Press the transmitter button to test.
Step 12 - Remotely Coding Transmitters
Using this method transmitters can be coded without
access to the opener's control panel as long as a pre-
coded transmitter is available.
IMPORTANT NOTE: The door or courtesy light
must activate when the steps below are performed.
This indicates that the pre-coded transmitter is in
range of the opener, and the correct button has
been pressed.
a. Take any pre-coded transmitter. Press the button
for the function to be duplicated and release.
b. Using a small needle, press and hold fi rmly for
two seconds through the Coding Hole (Fig. 25).
c. WITHIN 10 SECONDS take the additional
transmitter you wish to code.
button that you want to activate the function to
be duplicated (e.g. activate the door, or turn on
the courtesy light)
d. Hold the new transmitter's button for two
seconds, pause for two seconds, hold again for
two seconds and then release.
e. Wait for 10 seconds and then press the new
transmitter's button to test.
Decide which
