Replacing the TPM module (select models)

the TPM module (select models)" on page 66
Tools you need to complete this task:
v
Screws removed during this task:
To replace the TPM module:
1
2
3
4
www.gateway.com
Important
If the TPM module is located in the wireless bay, use the procedure found in
Flat-blade driver
Phillips #0 screwdriver
1 black 2.5*8.0 (Optional
bay module security
screw)
4 or 6 black 2.5*8.0 (LCD
hinge to notebook)
3 chrome 2.0-0.4*2.0
(palm rest-modular
drive bay)
2 black 2.0*2.5 (TPM
module)
Complete the steps in "Preparing the convertible notebook" on page
Remove the bay module by following the instructions in
If the convertible notebook has wireless networking built in, unplug the wireless antennas
by following the steps in
Remove the hard drive by following the instructions in
to replace the TPM module.
- OR -
1 chrome 2.5*5.0 (Hard
drive)
14-16 black 2.5*8.0
(palm rest-bottom)
1 black 2.5*8.0 (palm
rest-top)
"Replacing the IEEE 802.11 wireless card" on page
"Replacing
Scribe or non-marring tool
5.0 mm hex nutdriver
2 black 2.5*8.0
(Keyboard)
2 chrome 2.0*5.0
(palm rest-hard drive
bay)
2-4 black 2.5*5.0 (System
board)
5.
"Replacing a bay module" on page
16.
"Replacing the hard drive" on page
7.
21.
67
