Gateway Convertible Service Manual page 43

8
Remove the two screws that connect the tablet button board to the front of the LCD panel
assembly, then remove the board.
Screw
9
Install the new tablet button board.
10
Replace the screws that were removed in
11
Press the LCD panel front and back together. Press the two halves together in several places
until they click in place. You should find no loose spots or spots where the two halves do
not meet.
12
Replace the LCD panel assembly screws removed in
13
Replace the inserts removed in
Caution
The larger rubber inserts go across the top of the panel.
14
Replace the keyboard cover by following the steps in
page 27.
www.gateway.com
Screw
Step 8, then reconnect the cable.
Step 4.
Step 5.
"Replacing the keyboard cover" on
39
